Thru-wall version (optional)
A)
B)
C)
Fig.3
Mod.
GM1
GM2
GM3
Mod.
GM1
GM2
GM3
76-504-0914
Prepare the hole in the cold room wall - see fig. 3.
Position the unit onto the cold room wall inserting the evaporator
section through the prepared hole.
Fix unit to wall using the supplied screws - see fig. 4
A B
735 264
830 264
830 364
Fig.4
Description
Self tapping screws
AB 4,8x22
UNI 6954-71
C D
280 110
280 110
350 110
Code
3VTE049
E F G
400 335 373
400 335 590
522 440 590
Qty.
4
6
6
H
100
100
100
15
