AVENTICS | AS-i | R499050017–BDL–001–AE
6.1.4

AS-i 4DO dimensions

30,3
A
21
Fig. 9: Dimensioned drawing of the HF03 LG or HF04 valve terminal
with AS-i 4DO module, example
The AS-i 4DO module extends the valve system by
21 mm + 9.3 mm (E end plate).
B
63
Assembly
67
22,3
