62 AVENTICS | AS-i | R499050017–BDL–001–AE
Assembly
6.1.3

AS-i 8DO dimensions

30,3
21
Fig. 8: Dimensioned drawing of the HF03 LG or HF04 valve terminal
with AS-i 8DO module, example
The AS-i 8DO module extends the valve system by
21 mm + 9.3 mm (E end plate).
A
B
70
67
22
