INSTALLATION – PRODUCT OPERATION
EQUIPMENT DESCRIPTION (FIG-1)
The SPOT ARCPULL 200 is a single-phase inverter welding machine with arc-pull technology making is suitable to weld
pulling rings and threaded studs on steel or aluminium based materials. It has a synergic mode and a manual mode.
Generator SPOT ARCPULL 200
1- Keypad
2- On/Off switch
3- Positive dinse connector for gun cable
4- Negative dinse connector for gun cable
5- Base for gun control cable connector
Automatic gun SPOT ARCPULL 200
1- Trigger
2- Electrode holder locking nut
3- Studs locking scrollwheel
4- Gun control cable connector
5- Positive dinse
INTERFACE (MMI) (FIG-2)
1- Display
2- Button G+
3- Button G-
4- Button D+
POWER SUPPLY AND POWER UP
This machine is fitted with a 16A socket type CEE7/7 which must be connected to a single-phase 230V (50 - 60 Hz)
power supply fitted with three wires and one earthed neutral. The SPOT ARCPULL is equipped with «Flexible voltage»
technology, needs to be installed on a electrical installation with earth, between 110V and 240V (50-60Hz) The absorbed
current (I1eff) is indicated on the device, for its maximum setting. Check that the power supply and its protection (fuse
and/or circuit breaker) are compatible with the current needed by the machine. In some countries, it may be necessary
to change the plug to allow the use at maximum settings. The user has to make sure that the plug can be reached.
• The device is switched on by pressing the « I » on/off button
• The device turns into protection mode if the power supply tension is over 265V. If this is the case, the machine displays
POWER DEFAULT Normal functioning comes back once the power supply is under 265V.
WORKING OFF A GENERATOR
The machine can work with generators as long as the auxiliary power matches these requirements :
- The voltage must be AC, always set as specified, and the peak voltage below 400V,
- The frequency must be between 50 and 60 Hz.
It is imperative to check these requirements as many generators generate high voltage peaks that can damage the
machine.
GAS PROTECTION
This machine can be used with or without gas protection.
However it is recommended to connect a bottle of pure Argon to be able to use the full specifications of the machine.
The gas flow must be set between 10 and 12L/min.
Do not set the torque over 5 N.m when tightening the gas input cou-
pling.
18
IMS SPOT ARCPULL 200
6- Gas outlet for gun cable
7- Gas input connected to the bottle (15 l/min) (G1/4 D6)
8- Transport handle
9- USB port protection cap
10 - Power supply cable
6- Negative dinse
7- Gas connector
8- LED ON (green)
9- LED contact (blue)
10- LED fault (red)
5- Button D-
6- Button Menu/Validate
7- Return button
