curing light could be reduced significantly.
4) Remove the light guide and check that the LED is clean
and undamaged. Clean it with a dry air jet if necessary.
5) Never apply ultrasonic cleaning on the Mini L.E.D. SP
and its accessories.
6) The lamp o'rings should be changed every two years.
8 – TROUBLESHOOTING
If a problem appears, before calling your dealer's after
sales service:
1) Check that the base station is connected properly to
the mains to ensure that the battery recharges
normally. If the LED is not lit up in spite of proper
connection, contact the after sales service.
1) Intensive use of the lamp will generally cause a rise
in its external temperature that can be felt by the
hand holding it. In this case, an automatic safety
mechanism will prevent the lamp from operating and
the thermic indicator will turn red. After a period of
15 mins the lamp should have cooled down
sufficiently to recommence normal operation.
2) Some water leakage is not unusual if the generator's
irrigation system has not been turned off before using
Mini L.E.D. SP. This is simply due to water trapped in
the cord and is of no consequence. However, if the
water is flowing, this could damage the lamp. It is
therefore recommended to turn off the irrigation
when using the Mini L.E.D. SP.
3) In the event of reduced power, clean the light guide
to remove any possible traces of composite material
and try again. If the problem persists, check the light
guide for damage, or change it if necessary.
9 – TECHNICAL SERVICE
Your dealer's after sales service is at your disposal to
help with any technical problem.
10 – SPECIFICATIONS
Device
Model:
Weight:
Size:
Classification:
Optical specifications
Wavelength:
Intensity (Ø7.5mm): 1100mW/cm² ±10%
Temperatures:
Operating: +10°C to +40°C
Storage: -20°C to +70°C
Humidity:
Operating: 30% to 75%
Storage: 10% to 100% including condensation
11 - ELECTROMAGNETIC
COMPATIBILITY
Important: Mini L.E.D. SP conforms to the
electromagnetic compatibility standards currently in
force within the following configuration:
• Ferrite magnet – see wiring instructions.
• Conversion module
• Length of Mini L.E.D. SP cord = max. 3m.
• Power supply voltage : 24VAC.
• Mini L.E.D. SP
Mini L.E.D. SP requires special precautions to be taken
with regard to electromagnetic compatibility. It must be
installed and prepared for use as described in chapter 3.
Certain types of mobile telecommunication devices such
as mobile telephones are likely to interfere with the
Mini L.E.D. SP.
The recommended separation distances in this
paragraph must therefore be complied with.
The Mini L.E.D. SP must not be used near or on top of
another device. If this cannot be avoided, its operation
8
Mini L.E.D. SP
115g
Ø23 x 180mm
Class I
Type BF
Continuous service
IPX0
420-480nm
