____________________(EN)____________________
INSTRUCTION MANUAL

GENERAL INFORMATION

A truly portable starter with battery. Ideal for anyone
needing a starter . Applications include boats, cars,
trucks, tractors, generators and more.
Full compatible with any 12 volt starting system.
SPEED START utilizes a MAINTENANCE FREE
SEALED BATTERY which allows the unit to be stored in
any position, anywhere, without fear of leakage.
The SPEED START also has a special switch that must
be turned on deliberately before using the starter.
This starter conveniently stores under or behind a seat
or where is handy.
Save this Manual
You will need the manual for the safety warnings and
precautions, operating and maintenance procedures,
parts list and specifications.
Keep the manual in a safe and dry place for future
reference.
READ ALL INSTRUCTION BEFORE USING THIS
STARTER!
SAFETY WARNINGS AND PRECAUTIONS
Warning: When using this starter, basic safety
precautions should always be followed to reduce the
risk of personal injury and damage to equipment.
1- Wear eye protection. When working on or
around
protection.
2- Avoid contact with battery acid. If splashed,
immediatly wash affected area with clean
water. Continue washing area until medical
help arrives.
3- Connect cables to proper polarities:
Connect the red charge clamp to the positive
terminal of the battery (+ symbol).
Connect the black charge clamp to the vehicle
chassis, far away from the battery and from the fuel
pipe.
- Use this starter in well ventilated areas. Do not
attempt to jump start vehicle around flammable
gases or liquids.
- Do not allow the black and red clamps to touch. If
this happens, clamps or other metal objects may
melt. Place clamps only on the corresponding
terminals.
4- 12 VOLT SYSTEMS ONLY. Use only with vehicles
and boats with 12 volt electrical systems.
5- For emergency use only. Do not use this starter in
the place of a vehicle battery. Only use to start your
vehicle.
6- Avoid working alone. If an accident happens, an
assistant can bring help.
7- Avoid electrical shock. Use extreme caution
when clamping
conductors or bus bars. Prevent body
contact with grounded surfaces such as pipes,
radiators and cabinet enclosures when testing
voltages.
8- Keep work area clean. Cluttered areas invire injuries.
9- Avoid damaging speed start system. Use only as
specified in this manual.
10- Observe work area conditions. Do not use in damp
lead-acid always wear
around uninsulated
or wet location. Do not expose to rain. Keep work
area well lighted.
11- Do not places this unit in direct sunlight , direct heat
or moisture.
12- Keep children away. Children must never be
allowed in the work area. Do not let them
handle machines, tools, or extension cords.
13- Store idle equipment. When not in use, the starter
must be stored in a dry location to inhibit rust. Always
lock it up and keep out of reach of childern.
14-
electrically non conductive clothes and nonskid
footwear are recommended when working. Wear
restrictive hair covering to contain long hair.
15- Repair should be carried out by experts only
otherwise it may cause considerable danger for user.
16- Replacement
servicing, use only identical replacement parts. Use
of any other parts will void the warranty.
17- Do not overreach. Keep proper footing and balance
at all times. Do not reach over or across electrical
cables or frames.
18- Maintain this starter with care. Inspect starter cords
periodically and if damaged have them repaired by
an autorized technician.
19- Check for damaged parts. Before using this starter
any part that appears damaged should be carrefully
checked to determine that it will operate properly and
perform its intended function. Check for alignment
and binding of moving parts, any broken parts or
mounting fixtures, and any other condition that may
affect proper operation. Any part that is damaged
should be properly repaired or replaced by a qualified
technician. Do not use this starter if any switch does
eye not turn On and Off properly.

OPERATION

Warning: Electrical shock can use death or injury.
Avoid touching exposed conductors of electricity.
The SPEED START system is designed for use with
vehicle or boats. You will not need a host vehicle or
230VAC power supply.
You can also use this system as a portable power source
of 12 VDC in remote areas or emergencies.
Using the SPEED START to start a vehicle:
WARNING:
meticulously, always in the order given below!
- Make sure that the starter is switched off: the switch in
fig. A-5 must be in the OFF position.
- Make sure that the vehicle or boat to be started is
switched off (switch or ignition key in the OFF position).
- First connect the red clamp (+) to the positive terminal
on the vehicle battery.
- Then connect the black clamp (-) to a non-movable
metal part of the engine; do not connect the clamp to
the negative terminal of the battery.
WARNING:
Never ever turn the starter switch on unless you are
absolutely sure that you have connected the cables
to the correct polarities of the vehicle and its battery.
3
Dress properly. Do not wear loose
clothing or jewelry as they can be
caught in moving parts. Protective,
parts and accessories.
follow the
DANGER!
When
instructions
