____________________(EN)____________________
INSTRUCTION HANDBOOK

GENERAL INFORMATION

A real, portable, battery-powered starter. Ideal for anyone
needing a starter. Its applications include boats, cars,
trucks, power generators, and much more.
Fully compatible with any 12 volt starter system.
The starter uses SEALED MAINTENANCE-FREE
BATTERIES, which means that the unit can be installed
in any position, in any location, without the fear of any
acid leaks.
The starter is also equipped with a switch that must be
activated on purpose to allow starting.
The starter can easily be placed under or behind a seat or
kept within arm's reach.
Keep this manual.
The manual should be read, paying attention to all the
warnings and safety precautions to be taken when using
and maintaining the device, the list of components and all
technical specifications.
Please keep this manual in a secure and dry place for
future reference.
PLEASE READ ALL THE INSTRUCTIONS BEFORE
USING THE STARTER!
WARNINGS AND SAFETY PRECAUTIONS
Warning: in order to reduce the risk of personal injury
and damage to equipment, it is highly recommended
to comply with all essential safety measures and
precautions when using the starter.
1- Protect the eyes. Always wear protective
goggles when using acid lead accumulators.
2-
Avoid contact with battery acid. If an operator
should be sprayed or come into contact with
the acid, rinse the relative parts immediately
under clean running water. Continue to rinse the
area until the physician arrives.
3- It is important to connect the cables with the
poles in the right direction:
First connect the red clamp to the positive
terminal on the vehicle battery (+ symbol).
Connect the black clamp to the machine chassis, at
a distance from the vehicle battery and the fuel pipe.
- Use the starter in well ventilated areas. Do not
attempt to use the starter when there are gas or
inflammable liquids in the vicinity.
- Make sure that the black and red clamps never
come into contact with each other as this could
cause them to fuse together or with other metal
objects. Return the clamps to their respective
housing.
4- FOR 12 VOLT SYSTEMS ONLY! This device is
destined for use on boats and vehicles running on
12 Volt electrical systems only.
5- USE ONLY IN EMERGENCIES: do not use the
starter instead of the vehicle battery. Use it during
start-up operations only.
6- Do not work alone. If there is an accident, the
assistant can be of assistance to the operator.
7-
Prevent electrical shocks. Be very cautious
when applying the clamps to non-insulated
conductors or bus bars. Avoid all body
contact with surfaces of tubes, radiators, and metal
power substations whilst testing the voltage.
8-
Keep the work area clean at all times. Untidy
cumbersome areas can lead to injuries.
9- Protect the starter appropriately from all possible
damage. It must only be used as indicated in this
Instruction Manual.
10- Ensure compliance with the indications in the work
area. Do not use in humid or wet facilities. Never
leave it out in the rain. Always work in well lit areas.
11- Do not expose to direct sunlight, heat sources or
humidity.
12-
Keep out of children's reach: they must
never be allowed to access work areas or
handle any machines, instructions or
extensions.
13- When the starter is not being operated, it must be
stored in a dry area to prevent rust from forming.
always store the starter under lock and key and keep
out of reach of children.
14-
in moving
electrically insulated protection clothing and
non-slip boots must be worn at all times. Persons
with long hair must tie it back and wear a hair net.
15- Only experts are allowed to do repair work on the
machine as it involves significant risk levels for
inexperienced workers.
16- Replacing parts and accessories. When performing
maintenance operations, replace with identical spare
parts only. Use of non-original spare parts invalidates
all warranties.
17- Make sure that the device is always positioned in a
stable and well supported manner. Never climb over
cables or electrical structures.
18- Careful attention must be paid when maintaining the
starter. Check the condition of cables on a regular
basis and if any damage is detected, have the same
repaired by an authorised technician.
19- Check there are no damaged parts. Before using
this starter, carefully check that all seemingly
damaged parts and assess whether or not they
can operate correctly. Check that the cables are
securely fastened to the starter. Remember that only
qualified technicians are allowed to repair or replace
damaged parts. Never use the starter if any of the
switches malfunction when turned to the ON /OFF
positions.

OPERATING PROCEDURES

WARNING: Electric shocks may cause
injury or death. Do not touch bare
electrical conductors.
The starter is designed for use on vehicles or boats. It
does not need another vehicle or a 230VAC power supply
socket.
This starter can also be used as a portable 12V DC power
supply for remote areas or in emergencies.
The USB port can also be used to supply 5V DC to
devices that require less than 500mA.
How to use the starter:
ATTENTION:
meticulously, and always in the order given
below!
- Make sure that the vehicle or boat to be started is
switched off (switch or ignition key in the OFF position).
- First connect the red clamp (+) to the positive terminal
on the vehicle battery.
- Then connect the black clamp (-) to a non-movable
metal part of the engine; do not connect the clamp to
3
Always wear suitable clothing.
Never wear baggy clothing or
jewellery that can get caught up
parts. During all
follow these
operations,
instructions
