LR-Cal PYROS 140-2L Bedienungsanleitung Seite 28

PYROS Temperaturkalibratoren
MANUAL
PYROS Dry Block Temperature Calibrators
1. General informa on
2. Safety
2.1 Intended use
2.2 Personnel qualifica on
2.3 Personal protec ve equipment (P.P.E.)
2.4 Special hazards
2.5 Instrument specific hazards
3. Specifica ons
4. Posi oning of temperature probes in the dry block
4.1 Descrip on of the instrument
5. Transport, packaging and storage
5.1 Transport
5.2 Packaging
5.3 Storage
6. Commissioning, opera on
6.1 Unpacking the temperature calibrator
6.2 Environmental requirement
6.3 Posi oning the instrument
6.4 Power supply
6.5 Descrip on of the instrument
6.5.1 Thermoregulator
6.5.2 Main switch
6.5.3 Metal equalising block
6.5.4 Hea ng resistances / Pel er elements
6.5.5 Built-in reference temperature sensor
6.5.6 Safety thermostat
6.5.7 Fan
6.6 Commissioning
6.7 Opera on
6.7.1 Tes ng switch-point of thermostats
6.7.2 Serial interface RS232
7. Maintenance
8. Faults
9. Return and disposal
9.1 Return
9.2 Disposal
10. Op onal accessories
Appendix A
A.1 Func ons of the thermoregulator
A.2 Opera on scheme of the thermoregulator
A.3 Menu level 1
A.4 Menu level 2
A.5 Menu level 3
A.6 Menu level 4
Appendix B
Recalibra on of the internal reference sensor
Appendix C
RS232 communica on protocol
Declara on of conformity
