Pointek ULS200

WARNING: Changes or modifications not expressly approved by Siemens
Milltronics could void the user's authority to operate the equipment.
Notes:
• Pointek ULS200 is to be used only in the manner outlined in this manual, otherwise
protection provided by the equipment may be impaired.
• This product is intended for use in industrial areas. Operation of this equipment in a
residential area may cause interference to several frequency based
communications.
Pointek ULS200 is an ultrasonic based process level switch providing high or low switch action
on liquids or solids. The sensor is ETFE or PVDF, allowing it to be used in a wide variety of
industries. Pointek ULS200 is used to measure liquids, slurries, and fluid materials, as well as
chemicals and plugged chute detection.
Pointek ULS200 contains an ultrasonic transducer and temperature sensing element. The
transducer emits a series of ultrasonic pulses. Each pulse is reflected as an echo from the
material and sensed by the transducer. Pointek ULS200 processes the echo using Siemens'
proven Sonic Intelligence®techniques. Filtering is applied to help discriminate between the
true echo from the material and the false echoes from acoustical and electrical noises and
agitator blades in motion. The time for the pulse to travel to the material and back is
temperature compensated and then converted into distance for display and relay actuation.
The Pointek ULS200 is an excellent primary detection device, but should not be used as a
backup device. For backup devices use a contacting technology such as the Pointek CLS 200.
Page EN-2 Pointek ULS200 – QUICK START MANUAL 7ML19981XB83
