4

MACHINE INSTALLATION

The installation is to be carried out by qualified specialists and according to the following
instructions and in compliance with valid laws and local regulations.

4.1 Preparation for installation

• Place the machine on an even and stable surface.
• Make sure that the machine is on a water-resistant surface in case of water spillage or leakage.
• Never place the machine on hot surfaces.

4.2 Electrical connection

• Make sure that the local main supply voltage corresponds to the information given on the model
plate on the front panel of the espresso machine.
• Plug the machine into a grounded socket only and do not leave it unattended.
• Do not roll or bend the power cord.
• Do not use an extension cord / do not use a multi-socket power board.

4.3 Water supply connection

Important
Make sure that the machine is on a water-resistant surface in case of water spillage or leakage.
Make sure that the fixed water connection of your machine is connected to a potable water supply
having an operating pressure ranging between 0 and 1.5 bars. We recommend to use a pressure
regulator and a shut-off valve in case the operating pressure exceeds 1.5 bars or frequently fluctuates.
The shut-off valve should be easily accessible, so that the water flow may be stopped at any time.
Make sure that the shut-off valve is closed or turned off when the machine is not in use to prevent any
possible water leakage.

4.3.1 Machine in use with direct water connection

The water connecting hose is to be connected to the water supply adapter under the machine (image 1).
When using the machine with direct water supply, the valve has to be turned towards water supply adapter (image
1). The water supply adapter is located in the rear part of the bottom panel (image 1). Additionally, place the switch
behind the drip tray into position "1" (image 2).
Please make sure that your water tap is always open during water-connection usage so that the machine does not
run out of water!
Position "0": water tank
image 1
Instruction manual TECHNIKA V Profi PID
Place switch into position "1" for
direct water connection
Valve in position for operating
machine with direct water
connection (facing towards the rear
of the machine)
Water supply adapter
24
Position "1": direct water connection
image 2
ENGLISH
