Caution!
Danger of injury: The following parts are hot or may become hot:
Area of the valves
•
Steam wand and hot water wand
•
Brew group
•
Portafilter
•
Body (upper part and side frames)
•
4

MACHINE INSTALLATION

The installation is to be carried out exclusively by qualified specialists, according to the
following instructions and in compliance with valid laws and local regulations.

4.1 Preparation for installation

• Place the machine on an even and stable surface.
• Never place the machine on hot surfaces.
• Make sure that the machine is on a water-resistant surface in case of water spillage or
leakage.

4.2 Electrical connection

• Make sure that the local main voltage supply corresponds to the information given on
the type plate on the front panel of the espresso machine.
• Make sure that you use the correct power plug for your country.
• Plug the machine into a grounded socket only and do not leave it unattended.
• Do not roll or bend the power cord.
• Do not use an extension cord / do not use a multiple socket.

4.3 Water supply connection

Important
Make sure that the fixed water connection of your machine is connected to a potable water
supply having an operating pressure at least 100 kPa and does not exceed 200 kPa. We
recommend using a pressure regulator and a shut-off valve in case the operating pressure
exceeds 200 kPa or frequently fluctuates.
The shut-off valve should be easily accessible, so that the water flow may be stopped at any
time. Make sure that the shut-off valve is closed or turned off when the machine is not in
use to prevent any possible water leakage.
Position "0": water tank
waterconnection

4.3.1 Machine in use with a direct water connection

The water connecting hose is to be connected to the water supply adapter (image 1) at the bottom panel of
the machine.
Always use the hose supplied with the machine to connect the machine to the water supply system, even if
an old hose is already present.
When using the machine with direct water supply, the valve has to be turned towards the opposite side of the
water supply adapter opening (image 1). The water supply adapter is located in the rear part of the bottom
panel (image 1). Additionally, place the switch behind the drip tray into position "1" (image 2). Before use,
please make sure that your water tap is always open during water-connection usage so that the machine
never runs out of water!
Translation of the German original user manual
Position "1": direct
