Engine Controls
ENGINE CONTROLS
A. Choke Control Knob — Used to start a cold engine (see Figure
6).
B. Electric Start Button — Used to start the engine using the electric
starter.
C. Primer Button — Used to inject fuel directly into the carburetor
manifold to ensure fast starts in cool weather.
D. Safety Key — Must be inserted to start engine. Pull out to stop. Do
not turn safety key.
E. Starter Cord Handle — Used to start the engine manually.
FEATURES AND CONTROLS
H
I
E
F. Throttle Control Lever — Used to control engine speed. For best
performance, the throttle control should be set to the FAST position.
Use the SLOW position only for warming the engine.
G. Fuel Shut-Off Valve — Used to turn the fuel supply off for out-of-
season storage.
H. Fuel Tank and Cap — Fill the fuel tank to approximately 1-1/2 in.
(38 mm) below the top of the neck to allow for fuel expansion.
I. Oil Fill Cap (Extended Dipstick)
B
Figure 6
