ASSEMBLY

TOOLS REQUIRED FOR ASSEMBLY
1 – Knife
2 – 1/2" Wrenches (or adjustable wrenches)
1 – 7/16" Wrenches (or adjustable wrenches)
1 – Wrench (or adjustable wrench)
1 – Pair pliers or screw driver (to spread cotter pin)
1 – Hammer
1 – Pry Bar
PARTS BAG CONTENTS
1 – Tie, Self-Locking
NOTE: "Right" and "Left" are from the Operating Position.
WARNING: Always wear safety glasses or eye shields
when assembling the snowthrower.
UNPACK THE SNOWTHROWER
1. Using knife, cut along the dotted lines around the top of the carton.
Then remove top of carton as shown in Figure 2.
2. Using knife, cut along the dotted lines around the bottom of the
carton.
3. Push snowthrower off the bottom of the carton to proceed with
assembly.
CHECK CABLE CONNECTION AND ADJUSTMENT
The traction control cable and auger control cable are adjusted at the
factory and no adjustment should be necessary.
If the cables become stretched, unattached or begin to sag, adjustment
will be necessary. See MAINTENANCE section of this manual.
INSTALL THE DISCHARGE CHUTE
1. Place discharge chute (A A , Figure 3) over tabs on chute ring (B B ) as
shown.
2. Secure discharge chute with three carriage bolts (C C ) and nuts (D D ).
3. Tighten hardware to 66 in-lbs (7.6 Nm).
NOTE: Check all bolts and nuts in flange for tightness. Do not
over-tighten.
NOTE: If the chute rotation is slow or binding, loosen the
chute rotation screw 1/4 turn.
16
INSTALL THE DRIFT CUTTERS
Drift cutters are used to cut a path through snow deeper than the auger
housing.
1. On each side of the auger housing, insert carriage bolt (A A , Figure 4)
through upper hole.
2. Insert lower tab of drift cutter (B B ) into lower hole.
3. Secure with wing nuts (C C ).
CHECK THE TIRES
Check tires for damage. Check the air pressure in the tires with an
accurate gauge. See the sidewall of the tire for the proper inflation.
CAUTION: Avoid Injury! Explosive separation of tire
and rim parts is possible when they are serviced
incorrectly.
• Do not attempt to mount a tire without the proper
equipment and experience to perform the job.
• Do not inflate the tires above the recommended
pressure.
• Do not weld or heat a wheel and tire assembly. Heat can
cause an increase in air pressure resulting in an
explosion. Welding can structurally weaken or deform
the wheel.
• Do not stand in front or over the tire assembly when
inflating. Use appropriate tool that allows you to stand
to one side.
NOTICE: Check side of tire for maximum tire pressure. DO
NOT exceed maximum.
