Accessories

The air conditioning system comes with the following accessories. Use all of the installation parts
and accessories to install the air conditioner. Improper installation may result in water leakage,
electrical shock and fire, or equipment failure.
Tubing & Fittings
Drainpipe Fittings
(for cooling & heating)
EMC Magnetic Ring
(some models)
Others

Optional accessories

There are two types of remote controls: wired and wireless.
•
Select a remote controller based on customer preferences and requirements and install in an
appropriate place.
Refer to catalogues and technical literature for guidance on selecting a suitable remote controller.
Page 4
ƒ „
ƒPage 4
„
NAME
Soundproof / insulation sheath
Seal sponge (some models)
Orifice (some models)
Drain joint (some models)
Seal ring (some models)
Magnetic ring
(wrap the electric wires S1 & S2 ( P & Q & E )
around the magnetic ring twice)
Magnetic ring
(Hitch on the connective cable between the indoor
unit and outdoor unit after installation.)
Owner's manual
Installation manual
Transfer connector(Φ12.7-Φ15.9)/
( )(Packed with the indoor unit)
Φ0.5in-Φ0.63in
NOTE: Pipe size may differ from appliance to
appliance. To meet different pipe size requirements,
sometimes the pipe connections need a transfer
connector installed on the outdoor unit .
Transfer connector(Φ6.35-Φ9.52)/
( Φ0.25in-Φ0.375in )(Packed with the indoor unit)
NOTE: Pipe size may differ from appliance to
appliance. To meet different pipe size requirements,
sometimes the pipe connections need a transfer
connector installed on the outdoor unit .
Transfer connector(Φ9.52-Φ12.7)/
( ) (Packed with the indoor unit,
Φ0.375in-Φ0.5in
used for multi-type models only)
NOTE: Pipe size may differ from appliance to
appliance. To meet different pipe size requirements,
sometimes the pipe connections need a transfer
connector installed on the outdoor unit .
Connecting wire for display (2m)
Cord protection rubber ring
SHAPE
S1&S2(P&Q&E)
(on some models)
(on some models)
(on some models)
1(on some models)
1(on some models)
1
QUANTITY
2
1
1
1
1
1
1
1
1
1
1
1
