The Operating Instructions must always be near the ma-
chine. Put them in a plastic folder to protect them from
dirt and humidity. They must be read by every operator
before beginning work and observed conscientiously. Only
persons who have been trained in the use of the machine
and have been informed of the various dangers may work
with the machine. The required minimum age must be ob-
served.

General notes

• After unpacking, check all parts for any transport dam-
age. Inform the supplier immediately of any faults. Lat-
er complaints cannot be considered.
• Make sure the delivery is complete.
• Before putting into operation, familiarize yourself with
the machine by carefully reading these instructions.
• Use only original accessories, wearing or replacement
parts. You can find replacement parts at your Wood-
ster dealer.
• When ordering, include our item number and the type
and year of construction of the machine.
HC24
Extent of delivery
Technical data
Maximum operating
pressure, bars
Maximum working
pressure, bars
Oil quantity, litres
Free air displacement
(FAD) l/min.
Air replacement, (PD)
l/min.
Weight kg
Drive
Motor in V/Hz
Input W
Output W
Speed 1/min.
L
Sound pressure level
pA
L
Sound power level
Subject to technical changes.
Compressor HC24
2 wheels
1 air filter
1 accessory bag
Operating Instructions
8,9
8,0
0,3
160
220
25,5
230/50
1500
1050
2850
: 73,8 dB(A), K : 3 dB(A)
pA
: 97 dB(A), K : 3 dB(A)
wA wA
