Profibusschnittstelle
7.7
Class 2 functionality Commissioning diagnostic Diagnostic information
-
0
1
Octet
1
2
3
4
5 ... 6
7
8
9
10
11 ... 14
15 ... 16
17
optoNCDT ILR 1183

Diagnosedaten

0
1
1
Bit Type
byte
byte
byte
byte
word
byte
byte
0 bool
1 bool
2 bool
3 bool
4 bool
5 bool
6 bool
7 bool
byte
unsigned 32
unsigned 16
0 bool
1 bool
6 byte Normal-Diagnose
16 byte class 1 Diagnose
61 byte class 2 Diagnose
Output
diag state 1
diag state 2
diag state 3
master address
ident number
class 1 diagnostic
group ident
spc3 spec
unused
class 2 functionality on/off
commissioning diagnostic on/off
unused
reserved for future use
reserved for future use
reserved for manufacturer
reserved for manufacturer (operation status: parameter byte 9)
encoder type (=7 absolute linear encoder)
single turn resolution => 100000 nm = 0.1 mm
no. of distinguishable revolutions – unused (=0)
class 2 diagnostic
E98 – Timeout SIO
E99 – unknown Error
(profibus default)
(profibus default)
(profibus default)
(profibus default)
(profibus default)
(profibus default)
(profibus default)
