Endress+Hauser procom DZL 363 Ex-Dokumentation Zu Den Betriebsanleitungen Seite 20

en
1 +
2
-
20 +
21 -
22
+
23 -
24 +
28
25
-
26 +
27
-
Power supply cable
and signal cable
Power supply
cable
L1/L+
1 +
2
-
N/L-
20 +
21 -
22 +
23 -
24 +
28
25
-
26 +
27 -
Current output
signal cable
Warning!
Fig. 4
Label on the electronics unit of
Promass 63
8
PROMASS 63 with DoS interface to Procom DZL 363
(Promass 63****-**********G)
20 (DoS+) Power supply DC U = 16...62 V
21 (DoS-)
Corresponds with Procom DZL 363
Racksyst and panel mounted housing:
d8 (DoS+) / d10 (DoS-)
Field housing:
80 (DoS+) / 81 (DoS-)
28 Ground connection (signal cable shield)
Terminal no. 1 connected with terminal no. 24
Terminal no. 2 connected with terminal no. 25
PROMASS 63 with Dx interface to Procom DZL 363
(Promass 63****-**********L)
3 Ground connection (protective earth)
3
1
Voltage:
AC 85...260 V
2
L1: 1
N: 2
Power consumption:
22 (Dx+) Corresponds with Procom DZL 363
Racksyst and panel mounted housing:
23 (Dx-)
d2 (Dx+; A data) / d4 (Dx-; B data)
Field housing:
80 (Dx+; A data) / 81 (Dx-; B data)
28 Ground connection (signal cable shield)
Exchange of electronics unit
These four positions must match the last four
positions of the order code (see Fig. 5)
Module designation
63XMOD-
19
A9
1239
GLM9
Possible contents in the order
code
Procom DZL 363 with Promass 63
Functional values
Functional values
AC 20...55 V or DC 16...62 V
L+: 1
L-: 2
35 VA / 15 VA / 15 W
Warning!
The four positions on the electronics unit
label must match the last four positions
of the order code on the Promass 63
electronics housing nameplate
(see Fig. 5), otherwise the electronics
unit may not be installed. Before reapply-
ing power, the housing cover must be
tightly closed.
