1) RIGHT-HAND FRONT TURN INDICATOR (12V-10W BULB)
2) FRONT BRAKE LIGHT BUTTON
3) RIGHT-HAND CONTROL SET
4) ENGINE STOP BUTTON
5) START BUTTON
6) WHEEL REVOLUTION SENSOR
7) HIGH BEAM WARNING LIGHT
8) TURN INDICATOR WARNING LIGHT
9) DISPLAY
10) NEUTRAL WARNING LIGHT
11) STAND WARNING LIGHT
12) SCROLL BUTTON
13) HORN BUTTON
14) LIGHTS SELECTOR SWITCH
15) HIGH-BEAM FLASH
16) TURN INDICATOR SWITCH
17) LEFT-HAND CONTROL SET
18) CLUTCH BUTTON
19) CAPACITOR 4700 ?F - 25V
20) HV COIL
21) LEFT-HAND FRONT TURN INDICATOR (12V-10W BULB)
22) 12V DC REGULATOR
23) STARTING RELAY
24) ENGINE EARTH CONNECTION
25) STARTER MOTOR
26) 6A DIODE CLUSTER
27) DIODE CLUSTER
28) SEALED BATTERY
29) 20A FUSE
30) ENGINE EARTH CONNECTION - BATTERY
31) LEFT-HAND REAR TURN INDICATOR (12V-10W BULB)
32) NUMBER-PLATE LIGHT (12V-5W BULB)
33) BLACK WIRE CONNECTOR
34) REAR LIGHT (12V-5/21W BULB)
35) RIGHT-HAND REAR TURN INDICATOR (12V-10W BULB)
36) FLASHER UNIT
37) BUTTERFLY
38) FUEL COCK
39) REAR BRAKE LIGHT BUTTON
40) RESERVE FUEL WARNING LIGHT DELAY UNIT
41) GEARSHIFT SENSOR
42) NEUTRAL POSITION SWITCH
43) SIDE STAND
44) PICK-UP
45) PICK-UP
46) GENERATOR
47) ELECTRONIC CONTROL UNIT
48) IGNITION SWITCH
49) STAND RELAY
50) HEADLIGHT WITH 12V-55/60W BULB AND 12V-5W PARKING LIGHT BULB
51) 12V HORN
Key to colours
Bi = White
Ve = Green
Ma = Brown
Vi = Purple
WIRING DIAGRAM
Bl = Blue
Ne = Black
Gi = Yellow
Rs = Red
107
1
Ar = Orange
Az = Sky-blue
Ro = Pink
Gr = Grey
