Appendix F Bar Code Quick Reference
P Ratio Width to Thin (default: 0 (2 to 1))
6
P
6
value
0
1
2
3
Code 93, MSI 10/10, Code 128 are fixed 2.0 to 1
Note:
Best results for Code 39, 2 of 5 industrial, 2 of 5 interleaved, and Codabar
with 2.5 to 1
P Uni-directional or bi-directional printing - standard 0 uni-directional
7
values are: 0 or not programmed means no changes
1 uni-directional printing in LQ
2 bi-directional printing in LQ
3 uni-directional printing in NLQ
4 bi-directional printing in NLQ
A switch from uni-directional to bi-directional printing is only possible if the
Note:
parameter UNI-DIRECT.CMD is set to YES via operator panel or
ESC-sequence.
Start Position of Bar Code Printing
The start position for bar code printing is the current print position.
For both horizontal and vertical printing, the print position after printing bar
codes is the same line as the start position next to the bar code printed.
F-4
Code 39
2 of 5 industrial
2 of 5 interleaved
Codabar
Code 93
MSI mod 10/10
Code 128
2.0 to 1
2.5 to 1
3.0 to 1
3.5 to 1
EAN 8
EAN 13
UPC-A
UPC-E
SC3
SC6
SC9
SC3
