GB
- Wedges should be of wood, light alloy or plastic -
never of steel, which can cause kickback and dam-
age to the chain.
- Always keep to the side of the falling tree when fell-
ing.
- Watch out for falling libs when moving back after a
felling cut.
- When working on a hill make sure to stand on the
up-hill side or beside of the log or lying tree.
- Watch out for rolling logs.
Transport and storage
- When carrying and changing your position
while working with the chain saw the engine
must be stopped or the chain brake has to be
activated to avoid an unintentional running of
the chain.
- Never carry and transport the chain saw when
the chain is running!
- When transporting the saw longer distances the
supllied chain protection cover should be over the
chain in any case.
- Carry the chain saw only by the handle. The guide
bar should be behind you. Avoid touching the ex-
haust muffler (risk of burning).
- When transporting in a vehicle ensure a safe
grounding of the chain saw to prevent fuel or chain
oil spillage.
- Safely store the chain saw in a dry space. The saw
should not be stored outside. Keep the chain saw
out of the reach of children.
- Fuel and oil tank have to be emptied completely
when the chain saw is stored over a long period or
dispatched
Maintenance
- For all maintenance work the chain saw has to
be stopped and the plug connector be switched
off!
- Always check the safe operating condition espe-
cially the function of the chain brake of the chain
saw before each start of work. Always pay spe-
cial attention to a proper sharpend and tensioned
chain.
- Operate the machine so that it works with a min-
imum of noise and emission. Therefor check the
correct settings of the carburettor.
- Clean the chain saw regularly.
- Regularly check the tank caps for tightness.
Note the accident prevention regulations of the
responsible professional association and insur-
ance. Don not make any modifications to the ma-
chine! You may put at risk your personal secu-
rity!
Maintenance and service work can only be per-
formed as far as described in this manual. All further
work has to be assumed by the service center.
40 І 212
 www.scheppach.com  service@scheppach.com  +(49)-08223-4002-99  +(49)-08223-4002-58
Use only original spare parts and accessories. Not
using original spare parts, accessories, guard chain
combinations and lengths will lead to an increased
risk of injuries. In case of accidents or damages
caused by using unauthorised sawing devices or ac-
cessories refuse all liability.
First aid
For potentially occurring accidents, the First Aid kit,
according to DIN 13164, should always be handy at
the work place. Material taken from the First Aid kit
must be replaced immediately.
When you are requesting help, give the following
information:
- Location of accident
- Type of accident
- Number of injured people
- Type of injuries
- Who is reporting
Note
If persons with circulatory disturbance are exposed
to vibrations to often they might get injuries at their
blood vessels or nervous system.
Caused by vibrations following symptoms might oc-
cur at fingers, hands or wrists: Parts of the body fall
asleep, tickle, pain, pricking, change in color or skin.
If experiencing any of these symptoms consult
a doctor.
Remaining risks
m DANGER
RISK OF INJURY !
Contact with the saw-chain can lead to fatal cutting
injuries.
Never put your hands into the running saw-chain.
RISK OF KICKBACK!
Kickback can lead to fatal cutting injuries.
RISK OF BURNING!
The chain and the guide bar heat up during operation.

6. Technical data

Machine length x width x
height
Weight without bar and
chain and empty tank
Weight with bar and chain
and empty tank
Cutting Length
Bar Length
Automatic chain oiling
Chain Oil
Chain oil tank capacity
250 x 230 x 220
mm
3,9 kg
4,5 kg
210 mm
254 mm
yes
specialist chain oil
0,16 l
