ENGLISH
7. PARTS LIST
(Ref. to Fig. 12)
Code N°
Item
DESCRIPTION
6800040
01 RESERVOIR CAP
6720020
02 OIL RESERVOIR
6480055
03 MAIN HANDLE ASSY
6900601
04 COMPLTE SUCTION SCREW
6360250 ★ 05 O-RING
6641020 ★ 06 M 6 COPPER WASHER
6740100 ★ 07 5/32" BALL
6520160 ★ 08 SUCTION SPRING
6740120 ★ 09 7/32" BALL
6520200 ★ 10 SPRING
6340590
11 BALL POSITIONING DOWEL
6160070 12 BODY
6060060
13 METAL CUP
6360268 ★ 14 O-RING
6040422 15 ø 20 ELASTIC RING
6650078
16 COUPLER
6890026
17 FLEXIBLE HOSE
6120174
18 CUP
6360268 ★ 19 O-RING
★ 20 O-RING
▲
6040240 ★ 21 BACK-UP RING
6340060 22 M 6x6 GRUB SCREW
23 METAL LABEL
▲
6650118
24 ø 2,5x3,5 RIVET
25 CYLINDER
▲
6520341
26 RAM RETURN SPRING
6620226
27 RAM
28 WASHER
▲
6900670 29 SCREW
6040160 ★ 30 BACK-UP RING
6360240 ★ 31 O-RING
The items marked (★) are those Cembre recommend replacing if the tool is disassembled.
These items are supplied on request in the "HTEP-S Spare Parts Package".
The guarantee is void if parts used are not
Item ▲ Code N° in the varius versions of the tool
HTEP-S
HTEPF-S
HTEPN-S
20
6360320
6360320
6360300
23
6232190
6232188
6232189
25
6120175
6120181
6120175
28
6641042
6641042
6641044
200
6760810
6760813
6760812
Qty
Code N°
Item
DESCRIPTION
6040100 ★ 32 BACK-UP RING
1
1
6360161 ★ 33 O-RING
1
6560262
34 MOVEABLE HANDLE PIVOT
6700060 ★ 35 CIRCLIP
1
6620102
36 PUMPING RAM
1
6360161 ★ 37 O-RING
1
6080040
38 RAM GUIDE BUSH
1
6480909
39 MOVEABLE HANDLE
1
6380200
40 MOVEABLE HANDLE GRIP
1
6895020
41 MAX PRESSURE VALVE
1
6040080 ★ 42 BACK-UP RING
1
6360140 ★ 43 O-RING
1
6360022 ★ 44 O-RING
1
1
6800020
45 PRESSURE TESTING CAP
1
6740120 ★ 46 7/32" BALL
6520520 ★ 47 SPRING
1
6600100 48 BALL SUPPORT
1
6360140 ★ 49 O-RING
1
6040080 ★ 50 BACK-UP RING
1
6440085
51 PRESSURE RELEASE LEVER
1
6760100 52 SPRING PIN Ø 3x16
1
6361881 ★ 53 O-RING
1
6020020 54 PRESSURE RELEASE PIN
1
2
6360120 ★ 55 O-RING
1
6900640
56 PRESSURE RELEASE PIN GUIDE
1
6600020
57 SPRING LOADED PIN
6520280 ★ 58 SPRING
1
6232001
59 (TG. 0350) LABEL
1
6232178
60 (TG. 0378) LABEL
2
1
200 HEAD ASSY
▲
1
6000036
SPARE PARTS PACKAGE
★
original spares.
Cembre
When ordering spare parts always specify the
following:
- code number of item
- name of item
- type of tool
- tool serial number
Qty
2
1
2
4
1
1
1
1
1
1
FIG. 1
1
1
1
1
1
1
1
1
1
1
1
1
FIG. 3
1
1
1
1
1
1
1
FIG. 5
FIG. 6
5
22
OK
FIG. 2
FIG. 4
FIG. 7
NO
