CP 1512 Installation Instructions
4.3.2

Changing the Connection Type

Description
In Windows 2000, you can change the connection type. We, however, recommend
that you retain the factory default setting "AutoSense".
Procedure
Follow the steps outlined below, to change the connection type:
Step
1
2
3
4
5
6
7
CP 1512 Installation Instructions
C79000-N8974-C001-02
Open "System" in the Control Panel of Windows 2000 (taskbar Start
Settings Control Panel
Click on "Device Manager" in the "Hardware" tab.
Open "Network Adapters" and double-click on the "Siemens CP1512"
adapter.
Select the "Advanced" tab.
Select the "Connection Type" property in the list box.
In the list box with the title "Value", select the mode you require (data
transmission rate 10 or 100 Mbps, full or half duplex).
Complete the changes with "OK".
Description
System).
77
