Requirements
The CP 1512 is installed in the computer.
Installing the CP automatically starts the Wizard that looks for new hardware. The
dialog of this wizard is displayed on your screen.
Insert the CD supplied with the CP 1512 in your CD drive.
If you have a SIMATIC NET PC Software CD please use this if it contains a newer
driver than the one on the CD supplied with the CP 1512
(..\cp1512_cp1612\cp1512).
To install the CP 1512 driver manually, follow the steps outlined below:
Step
1
2
3
4
5
6
76
Click the "Next" button.
Reaction
The wizard displays a dialog in which you can decide whether to look
for the driver files or whether the system should display a list of
Windows drivers.
The default is the option of looking for the driver files. Use this option.
Click the "Next" button.
Reaction
In the next dialog, you can select the drive in which you inserted the
driver CD.
Select the option "CD-ROM" and click the "Next" button.
Reaction
The hardware wizard displays the drivers it has selected for installation.
Click the "Next" button.
Reaction
The next dialog reports the absence of a digital signature.
Click the "Yes" button to continue the installation.
Reaction
The final dialog box confirms successful installation of the driver.
Click the "Finish" button.
