5. Versions

Accessories:

Solar regulator
Version
Energy Pro
Digital differential temperature controller for thermal solar systems; operation via rotary/pressure adjuster and ESC key with fully graphic,
dimmable, backlighted colour screen; 4 inputs for PT 1000 sensors; 2 triac outputs; floating contact; flow rate measurement function; SD-card
reader; USB connection; 20 preconfigured hydraulic schemes; 2 collector fields and 1 accumulator or 1 collector field and 2 accumulators;
solar heating support; remote access; soft charging; disable recharge function; thermostat and temperature comparison function; accumulator
priority charging; holiday function; anti-legionella function; heating return increase; bypass function and charge zone control; analog or PWM
output for high-efficiency pumps; speed control; fault monitoring; manual mode possible; collector safety shut-down; Closed-circuit cooling;
commissioning/service assistant; fixed-T and delta-T control; tube-collector function; after-run time for outputs; frost protection; sensor
monitoring; monitoring of output parameters; hour counter for outputs; solar yield measurement for pump control incl. data output; solar
yield measurement without flow rate meter possible; scope of delivery incl. 2 universal temperature sensors PT 1000 and analyzing software;
control secondary pump with separating systems; swimming pool heating
Pumpensteuerung über Blockmodulation,
PWM- oder 0-10 V Signal
Maximal Pro
with solar controller Energy Pro, however with 10 inputs for PT 1000 sensors; 4 triac outputs; 4 outputs 0-10 V or PWM with high-efficiency-
pump; radiation sensor; 30 pre-configured hydraulic schemes; 2 collector fields and 2 accumulators and circulation function; scope of delivery
incl. 4 Universal temperature sensors PT 1000 and analyzer software
Pump control via block modulation,
PWM or 0-10 V signal
Flow sensor for solar regulator Energy Pro / Maximal Pro (Option)
Installation length 110 mm; connecting thread ¾" MT; operating temperature max. +130 °C; nominal flow Qn 1.5; pulse sequence 1 pulse/litre;
incl. 1 temperature sensor PT1000
Nominal flow rate Qn 1.5
Nominal flow rate Qn 2.5
Smart Box (optional for Energy Pro / Maximal Pro)
for remote access to the measured data; for evaluation; analysis as well as optimization; for message display and parameterization; for
software updates and for visualization of the system status; interface for possible building management system; with 6 USB 2.0 connections;
SD card slot and VGA connection
Art. no.
45111.76
45111.96
45111.72
45111.73
45111.001
22
