2. Technical Data
Connections:
max. permissible temperature:
max. permissible pressure:
Collector surface:
Non-return valves:
Thermometer:
Manometer:
safety valve:
Overall dimensions:
Medium:
15
Solar circuit (primary):
Storage circuit (secondary):
Expansion vessel:
+110 °C, short periods +130 °C (note max. permissible temp. of the pump!)
6 bar (note actuation pressure of the safety valve!)
up to approx.12 m
2
2x 500 mmWs
Display range 20 ... 150 °C
Display range 0 ... 10 bar
Actuation pressure 6 bar
Height:
Width:
Insulation depth:
Axial separation:
Solar circuit (primary):
Storage circuit (secondary):
Volume flow pressure loss diagram
Solar separation system primary side*
Volumetric flow (l/h)
¾" Iint. thread
optionally 1" int. thread or 1" ext.thread
¾"ext. thread
465 mm
320 mm
250 mm
125 mm
suitable approved solar fluid
water
16 heat-exchanger plates
20 heat-exchanger plates
26 heat-exchanger plates
* Flow resistance with brine (propylene glycol 40%)
