6.2 Connecting the Central Control Unit to the net-
work
• First pull the cap up and off the Central Control Unit.
• Connect the Central Control Unit to your DSL router or cable
modem using the network cable supplied (I).
34
J
J
6.3 Connecting the Central Control Unit to the power
supply
For the power supply, only use the CCU2 original power sup-
ply unit (5 V DC/1500 mA) delivered with the device in order
to avoid damaging the device.
• Attach the supplied power supply unit (F) to the Central Control
Unit and plug it into the socket outlet.
The device may only be connected to a freely accessible
power socket outlet. The mains plug must be pulled out if a
hazard occurs.
Your Central Control Unit is now ready for starting up.
7

System requirements

Current version of one of
the following web browsers: Mozilla Firefox®
Data connection:
Screen resolution:
Microsoft® Internet Explorer
Google Chrome
Safari
Ethernet (TCP/IP and DHCP)
USB 1.1 or higher (only with
Microsoft Windows®
XP/Vista™/7 operating system)
1024 x 768 (user websites)
1280 x 1024 (administrator websites)
