DMX-CONTROLLED OPERATION

You can control the devices individually via your DMX-controller.

DMX-Mode

The device has two different DMX channel modes. The Control Board allows you, as described below, to
assign the DMX channel mode.
Addressing
The Control Board allows you to assign the DMX fixture address, which is defined as the first channel from
which the device will respond to the controller.
Press the MODE button until the display shows Addr. Press ENTER to confirm.
Select the desired DMX Channel Mode 4CH/10CH and again press ENTER to confirm.
You can now set the desired address via the UP or DOWN buttons. Press ENTER once again to confirm.
Press the MODE button in order to return to the main menu.
Please, be sure that you don't have any overlapping channels in order to control each device correctly and
independently from any other fixture on the DMX-chain.
If several devices are addressed similarly, they will work synchronically.
Controlling:
After having addressed the LED MFE-20 Hybrid Beam Effect, you may now start operating it via your lighting
controller.

DMX protocol

4 channel mode
Channel:
1
2
3
Z-motor rotation
4
Value: Function:
000 - 255 X-scan
000 - 255 Y-scan
000 - 011 Stop
012 - 127 Forward with increasing speed
128 - 139 Stop
140 - 255 Backward with increasing speed
000 - 009 No function
010 - 019 Red
020 - 029 Green
030 - 039 Blue
040 - 049 White
050 - 059 Red + Green + Blue + White
060 - 129 Color change with increasing speed
130 - 139 White LED strobe
140 - 149 Red + White LED strobe
150 - 159 Green + White LED strobe
160 - 169 Blue + White LED strobe
170 - 179 White + White LED strobe
180 - 189 Red + Green + Blue + White + White LED strobe
190 - 255 Color change + White LED strobe with increasing speed
25/28 00094089.DOC, Version 1.1
