and is installed in a distance of 0.5 meters between smoke machine and device. The room must only be
saturated with an amount of smoke that the visibility will always be more than 10 meters.
The ambient temperature must always be between -5° C and +45° C. Keep away from direct insulation
(particularly in cars) and heaters.
The relative humidity must not exceed 50 % with an ambient temperature of 45° C.
This device must only be operated in an altitude between -20 and 2000 m over NN.
Never use the device during thunderstorms. Over voltage could destroy the device. Always disconnect the
device during thunderstorms.
The F-symbol means: this device can be installed on normal inflammable surfaces.
- - -m
The symbol
between light-output and the illuminated surface must be more than the given value.
This device is only allowed for an installation via the mounting bracket. In order to safeguard sufficient
ventilation, leave 50 cm of free space around the device.
The housing must never touch surrounding surfaces or objects.
Make sure that the area below the installation place is blocked when rigging, derigging or servicing the
fixture.
Always fix the fixture with an appropriate safety bond.
The maximum ambient temperature T
Operate the device only after having become familiarized with its functions. Do not permit operation by
persons not qualified for operating the device. Most damages are the result of unprofessional operation!
Never use solvents or aggressive detergents in order to clean the device! Rather use a soft and damp cloth.
Please use the original packaging if the device is to be transported. Make sure that you pack the device in
the original state.
Please consider that unauthorized modifications on the device are forbidden due to safety reasons!
If this device will be operated in any way different to the one described in this manual, the product may suffer
damages and the guarantee becomes void. Furthermore, any other operation may lead to dangers like short-
circuit, burns, electric shock, crash etc.
DESCRIPTION OF THE DEVICE
Features
Powerful LED hybrid beam effect
•
Scanner with adjustable mirror
A bright QCL (R, G, B, W) LED is located behind the main lens; white 1 W LEDs are found on the
•
underside of the device
Operable in stand-alone mode or via DMX interface
•
DMX512 control possible via any commercial DMX controller (occupies max.13 channels)
•
4 or 13 DMX channels selectable for numerous applications
•
Sound-control via built-in microphone
•
Adjustable microphone sensitivity via control board
•
The colorful beams change their direction of movement at every bass-beat in sound controlled mode
•
Comfortable addressing and setting via control panel with LED display and four operating buttons
•
Functions: Static colors, RGBW color blend, auto mode, sound control, internal programs, strobe
•
settings via DMX, Pan/Tilt settings via DMX
Master/Slave function for synchronous operation with several devices
•
Equipped with 1 x 10 W RGBW LED and 6 x 1 W LEDs in white
•
Locking possibility at the mounting bracket
•
Feed-through output allows to power up to 8 devices
•
Switch-mode power supply for operation between 100 and 240 Volts
•
Ready for connection via included IEC power cord with safety power plug
•
determines the minimum distance from lighted objects. The minimum distance
= 45° C must never be exceeded.
a
