Overview

1
2
Power Out
Fuse:
5
F 1 A, 250 V
6
7
Power supply:
100 - 240 V AC, 50/60 Hz ~
11
3
4
XLR occupation:
1: Ground
2: Signal (-)
3: Signal (+)
DMX OUT
Mic
DMX IN
MODE UP DOWN ENTER
Safety rope
12 13 14 11
(1) Deflection mirror
(2) Lens with 1x10 W QCL LED
(3) Infrared sensor for the remote
(4) Lenses with 6 x 1 W white LEDs
8
(5) Power out
9
(6) Fuse holder
(7) Power supply
10
(8) DMX out
(9) Microphone
(10) DMX in
(11) Fixation screws
(12) Mounting bracket
(13) Attachment eyelet
(14) LED display with operating buttons
