12. SPECIFICATION
Technical data
Article no.
Measurement Temperaturerange
Accuracy
Detector type
Detector resolution
Spectral range
Field Of View (FOV)
Image output Geometric resolution
radiometric
Thermal sensitivity
Image refresh rate
Focus
Min. focussing distance
Image perfor-
digital photo camera
mance visual
Video norm
Image repre-
Image display
sentation
Image display options
Measuring point
Isotherm
Measuring Emission factor
functions
Measurement correction
Storage medium
Data format radiometric
Image storage
Data format visual
Voice recording
V Series
IC 080 V: 3.110.003.011
IC 0120 V: 3.110.003.019
-20 °C to +600 °C
-20 °C to +1.500 °C
Focal Plane Array (FPA), uncooled microbolometer
160 x 120 pixels
8 to 14 µm
20 °C x 15 °C
2,2 mrad
0,1 °C at 30 °C
Colour depiction 680 x 480 Pixel, integrated photo lamp
2.5" LCD, pseudo colours, 6 colour palettes
IR-image, digital-image, 4 DuoVision-combinations
Up to four moveable measuring points (3 x manual and 1 x
Yes (between the upper and lower limit values)
Variably adjustable from 0.01 to 1.0
Automatic on the basis of user-defined specifications for
environmental temperature, distance, relative humidity
interchangeable memory card slot for mini-SD card
Comments can be stored with each IR image (optional Bluetooth
expansion kit and Bluetooth headset necessary)
Operating manual – Infrared camera
IC 080 LV: 3.110.003.012
IC 0120 LV: 3.110.003.020
±2 °C, ±2% of the measured value
50/60 Hz
manuel
0,10 m
PAL/NTSC
of IR- and digital image
automatic)
14-bit radiometric IR format
CCD
LV Series
-20 °C to +600 °C
-20 °C to +1.500 °C
384 x 288 pixels
7,5 to 14 µm
24 °C x 21 °C
1,1 mrad
0,08 °C at 30 °C
B - 24
