Setting Definable Trigger
You can set the definable trigger different function
like saving image, auto adjust, Laser and turning on
illuminator.
1. Press the MENU/EN-
TER key, then press
Up and Down
row on
omni selector
select the [Setup]
menu, and then press
the MENU / ENTER key.
2. Press the Up and
Down arrow on the
omni selector to select
the [Others] menu, and
then press the MENU/
ENTER key.
3 . Press Up and Down
the [Trigger Button] menu, the Press the 3 Left,
Right 4 arrow on the omni selector to select the
function you need.
About the function of the definable trigger
None: No function selected.
Save: Saves the image.
Auto adjust: Corresonds to A key.
Laser on: You can activate the laser pointer by
pressing the trigger.
Lightingon: You can activte/ deactivate the illuminator by
pressing the trigger.
06. PLAYBACK AND DELETE

Opening Images

You can view and analyze the recorded images on the
LCD monitor.
1. Press the MENU/ENTER key.
2. Press the Up and Down arrow on the omni selec-
tor to select the [File] menu.
ar-
the
to
on the selector to select
Operating manual – Infrared camera
3. Press Up and Down
arrow on the omni
selector to select
[Open], the press
the Menu / Enter key.
4. Select an image then
press MENU / ENTER
key to open it.
How to select an image
1. After selecting [Open] or [Delete] option under [File]
menu, a message shown as below will appear in the
lower left of the screen.
<DIR> GZSAT001
Open SAT00001.SAT
2. If the image you wish to open or delete is not in the
current folder, press the [
selector until the following message appear.
.. <DIR>
Enter or cancel
3. Press the C key, then the S key to activate the image.
Select the name of the current folder
1. Press the MENU/ENTER key.
The Folder name
The Image name
Up] arrow on the omni
