Transfer Video Via Usb; Trouble Shooting - Trotec IC 0120 V Bedienungsanleitung

4. Select [Include this lo-
cation in the search:]
then click [browse].
Locate the directory of
the driver, and click
[OK] to return to the
previous window.
Then click [Next >].
5. Click [Continue Any-
way].
6. Click [Finish] to com-
plete the driver instal-
lation.

Transfer Video via USB

You can transfer infrared video to a computer directly via
the USB by the optional real-time software.
1. Power on the computer.
2. Connect the camera and computer via USB cable.
3. The operation system will recognize the camera as a
mass storage device. The camera will be installed to
you computer without any additional driver.
4. You can see the ther-
mal video, analyze it
realtime and record it
in your CD via the
software.
B - 19

Trouble shooting

If you have any problems connecting the IR camera to
a computer to use optional on-line software, check this
first.
First, check the following:
1. Does your computer comply with these requirements?
Ensure the system has a built-in USB port and comes
with Windows 98 (First or Second Edition), Windows Me,
Windows 2000, or Windows XP/VISTA preinstalled.
The USB interface is not supported by systems not
complying with the conditions above.
2. Is the camera correctly connected to the computer?
See „Connecting to a computer"
3. Is the battery sufficiently charged?
You should use a household power source to power
the camera when it is connected to a computer for a
longer period.
4. If the USB Driver is not correctly installed, it is possible
that Windows doesn´t recognize the Driver. Please
contact your motherboard's manufacturer for the la
test driver.
5. The USB2.0 real-time transmission function may not
properly work under some model of motherboard's
chipset. In this case, connect the IR camera to another
computer based on the chipset in the chipset sup-
porting list and try again.
Using the Bluetooth headset
The camera comes with a Bluetooth module.
You can use the Bluetooth headset (optional)
to record voice memos. Follow the steps to
install the Bluetooth headset (optional).
1. Turn off the camera and Bluetooth head-
set.
2 . Turn on the Bluetooth headset first.
Press and hold the power button (A) for about
10 seconds. You can see the power indicator
begins to flash red then blue. The headset is in pai-
ring mode after 120 seconds.
Operating manual – Infrared camera
