5.36. How to set the parameters of Sweep

1. When the output signal is Sine, Square or Ramp waveform, press the Mod button,
then press F2 to select Sweep to enter the Sweep mode.
2. Press
instance, press
the parameters, please refer to "To Set signals" on page 67. Press
again to return to the Sweep mode interface.
3. Press F1
Frequency changes from the Start Frequency to Stop Frequency.
4. Press F2 to select the Sweep Type. Linear means setting the Sweep with linear
spacing; Log means setting the Sweep with logarithmic spacing.
5. Use Start Freq and Stop Freq or Center Freq and Freq Span to set the range of the
frequency. Press
value.
6. Press F4 to select StopFreq or FreqSpan, and set the desired value.
7. Press F5 to select NextPage, press it again to enter the next page.
8. Press F1
External means using the Ext Trig/FSK/Burst connector in the rear panel to input
the external signal. Manual means choosing manual trigger; in Sweep interface,
press the knob on the front panel to trigger a Sweep.
, or button to choose the waveforms. Take Sine for
to display the waveform and parameters. You can change
to set Sweep Time, the Time Span of the Sweep for which the
F3 to select Sta_Freq or Cen_Freq, and set the desired
to select the source. Internal means using the internal source.
-86-
