DNP 3.0 device profile of REF 610
DNP V3.00
DEVICE PROFILE DOCUMENT
Vendor Name: ABB Oy, Distribution Automation
Device Name: REF 610
Highest DNP Level Supported
For Requests
For Responses
Notable objects, functions, and/or qualifiers supported in addition to the Highest DNP Levels
Supported (the complete list is described in the attached table):
Additions to level 2 are marked as shaded in the implementation table.
Maximum Data Link Frame Size (octets)
Transmitted
Received
Maximum Data Link Re-tries:
Configurable, range from 0 to 255 with
primary data link layer retransmission count
Requires Data Link Layer Confirmation:
Configurable, with confirmation type selector, default NO ACK
Requires Application Layer Confirmation
Configurable with confirmation type selector when reporting Ereignis Data (Slave devices
only)
Always after response to reset request
Always when sending multi-fragment responses (Slave devices only)
Configurable, with confirmation type selector
Timeouts while waiting for
Data Link Confirm
Complete Appl. Fragment
Application Confirm
Complete Appl. Response
Sends/Executes Control Operations
WRITE Binary Outputs
SELECT/OPERATE
DIRECT OPERATE
DIRECT OPERATE - NO ACK
Count
Code
Trip/Close
Pulse On
Queue
Clear Queue
Device Function
L2
Slave
L2
Maximum Application Fragment Size (octets)
292 Transmitted
292 Received
Maximum Application Layer Re-tries:
Configurable, range from 0 to 255 with
application layer retransmission count
Configurable with primary data link layer
timeout, not relevant when NO ACK
No, multi-fragment application frames not
supported
Configurable with application layer timeout
No, not relevant in slave
Never
Never
Never
Never
Never
Never
Never
Never
Never
Never
1MRS756033
2048
2048
