Technical data

MTC 32 F
Weight including 10 m
connecting cable
Pressure port
Free ball passage
Operating mode:
immersed
Operating mode: surfaced
Operating mode:
short-term operation
Intermittent operation
PTB test certificate
Identification marking
Motor power P1
Voltage
Frequency
Rated current
cos phi
Oil filling
Oil type
* Example: S3 30% = 3 min. operation + 7 min. interval (run time 10 min.)

5.3 Accessories

Accessories must be ordered separately
(see catalogue)

6 Description of the pump

6.1 Description of MTC 32 F 39 (Fig. 1)
Item no. Description of component
1 Motor housing
2 Upper roller bearing
3 Rotor
4 Stator
5 Electrical connection cable
6 Seals
7 Lower roller bearing
8 Rotary shaft seal
9 Seal housing
10 Mechanical seal
11 Impeller
12 Pump housing
13 Macerator
14
39.16/30/3-400-50-2(Ex)
kg 43
PN 6 DN 32
mm 7
S1/S3-40%
--
S2 27 min.
S3* 40%
PTB 08 ATEX 1005 X
Ex d IIB T4
kW See name plate
V See name plate
Hz See name plate
A See name plate
See name plate
L 0,52
Use mineral oil of viscosity class 22 to 46
e.g. Spinesso or Nuto from ESSO or similar
49.17/66/3-400-50-2(Ex)
90
DN 32
8
S1/S3-30%
--
27 min.
30%
PTB 08 ATEX 1006 X
Ex d IIB T4
See name plate
See name plate
See name plate
See name plate
See name plate
2,6
6.2 Description of MTC 32 F 49 / MTC 32 F 55 (Fig. 2)
Item no. Description of component
1 Motor housing
2 Upper roller bearing
3 Rotor
4 Stator
5 Electrical connection cable
6 Seals
7 Lower roller bearing
8 Mechanical seal
9 Seal housing
10 Mechanical seal
11 Impeller
12 Pump housing
13 Macerator
7 Installation and electrical connection
DANGER! Risk of fatal injury!
Incorrect installation and improper electrical
connections can be life-threatening.
• The installation and electrical connection must
be carried out only by qualified personnel in
accordance with applicable regulations.
• Observe the accident prevention regulations.
55.13/66/3-400-50-2(Ex)
90
DN 32
8
S1/S3-30%
--
27 min.
30%
PTB 08 ATEX 1006 X
Ex d IIB T4
See name plate
See name plate
See name plate
See name plate
See name plate
2,6
