OPERATING PRINCIPLE/TECHNICAL DATA
E
D
A
Available power
Power output for water
Power output to room
Overall efficiency
Smoke temperature
Smoke flow
Water content
Fuel consumption max
Minimum draught
Maximum pressure
Klima weight (basic/hotplate) including the packaging
Warm weight (basic/hotplate) including the packaging
Smoke outlet diameter
Heating capacity *
* The heatable room dimensions are calculated assuming the use of wood of the type described in the note, and home insulation
which complies with Italian law No. 10/91, and subsequent changes together with an expected heat output of 33 Kcal/m³ hour.
A LOT DEPENDS ON THE EFFICIENCY OF THE HEAT EMITTING UNITS (RADIATORS).
28
F
H
G
TECHNICAL AND HEATING SPECIFICATIONS
A
Primary air inlet
B
B
Secondary air inlet
C
Secondary air regulation lever
C
D
Cold water inlet
E
Hot water outlet
F
Smoke outlet
G
Ashpan
H
Coil
Klima/Warm
19,7
11,6
8,1
80,7
225
18,2
40
5,5
12
1,5
275/305
250/274
15
515
Klima CS/Warm CS
14
kW
10
kW
4
kW
81,6
%
234
°C
11,3
g/s
40
l
4
kg/h
12
Pa
1,5
bar
278/308
kg
253/276
kg
15
cm
365
m
3
