CLEAR
At active energy range, press CLEAR
and hold for over 1
second to reset time the zero, then restart the timing.
At all other ranges, press CLEAR and hold for over 1 second to
clear stored readings.
MR
Press once to enter Memory Record mode,
appears and
the Meter beeps.
▼/▲
If the Meter steps through sum of power press ▼/▲ button to
switch display of active power (main display), sum of reactive
power (secondary display) , sum of power factor (main display)
and sum of apparent power.
In the MR mode, press ▼/▲ to select recoded data.
USB
Measurement data will be sent to the PC
Transformer Jaw
Designed to pick up the AC and DC current flowing through the
conductor. It could transfer current to voltage. The tested
conductor must vertically go through the Jaw center.
6. How to make measurements
Before making any measurements read safety precautions.
Always examine the instrument and accessories used with the
instrument for damage, contamination (excessive dirt, grease,
etc) and defects. Examine the test leads for cracked or frayed
insulation and make sure the lead plugs fit properly into the
instrument terminals. If any abnormal conditions exist, do not
attempt to make any measurements.
-42-
