Installing the LCD monitor

7 Installing the LCD monitor
7.1 Tools required (fig. 1, page 3)
For installation and assembly you will need the following tools:
 Measuring ruler (4)
 Centre punch (5)
 Hammer (6)
 Drill head set (7)
 Drill (8)
 Screwdriver (9)
To establish and test the electrical connection, the following tools are required:
 Diode test lamp (1) or voltmeter (2)
 Insulating tape (10)
 Heat shrinking sleeve
 Hot air blower (11)
 Crimping tool (12)
 Soldering iron (optional) (13)
 Solder (optional) (14)
 Cable bushing sleeves (optional)
To fasten the cables, you may require additional cable binders.
