VOLT WATT
IP
230V~50Hz 1.5 kW
20
GB English
Product: Ferm saw-bench
Type FZT-250, Art. nr. 420085
Ferm, Genemuiden, the Netherlands
Sound pressure level (L pa ) 85 dB(A)
Acoustic capacity level (L wa ) 99 dB(A)
Measurements of bench 685 x 430 mm
Suction mouth Ø 30 (22) mm
SERIAL NUMBER
The serial number on the machine is composed as fol-
lows:
Serial nr.
ORDER NUMBER / CONSTRUCTION YEAR
READ THESE INSTRUCTIONS FOR USE
PROPERLY BEFORE YOU USE THE SAW-
BENCH!
1. SPECIAL SAFETY
INSTRUCTIONS
1. When using the saw blades with hard metal teeth
(widia) it is advisable to use blades with a negative
or slightly positive cutting angle. Do not use any
saw blades with deeply cut teeth. They can grip the
protective cap.
2. Attention: First carefully assemble all the parts be-
fore starting work. Follow the procedure as indica-
ted.
3. If you are not familiar with using such a machine,
you would be better to be informed first by a pro-
fessional, an instructor or by a technician.
4. Always clamp or press the workpiece firmly
against the saw guide, before you carry out the
process. The use of all possible clamping set-ups is
preferable to using your hands.
5. Important: If you are holding the workpiece by
hand for the process to be carried out, keep a mini-
mum distance of 100 mm from the saw blade.
6. Always press the workpiece against the bench.
7. Keep the saw blade sharp and check regularly
whether it rotates freely without abnormal vibra-
tions. Replace the saw blade if necessary.
2
45°
90°
1 '
MM MM
RPM mm mm mm
4500 55 80 Ø 254 x 1,6 x 16 22
40 Teeth
8. Allow the machine to rotate freely until it reaches
the maximum number of revolutions, before you
start the process.
9. Maintain the air inlets at the back and the bottom of
the bench saw machine and electric engine for a
longer machine life. Dust piles must be removed.
10. Always lock the different degree set-ups before
you start processing.
11. Only buy suitable saw blades with a number of re-
volutions of at least 6000 revolutions per minute.
12. Only use the correct saw blade. Too small or too
big saw blades are extremely dangerous.
13. Regularly inspect the saw blade for any faults. Re-
place the saw blade if necessary.
14. Grease the new saw blade and clean the flanges be-
fore you assemble the new blade. Then assemble
the blade in the correct direction and pull the flan-
ges firmly using the central bolt (left thread!)
15. Only use original flanges. All other types are not
suitable.
16. Never work without the protective cap of the saw
blade.
17. The moving part of the protective cap must also re-
main assembled.
18. Never grease the saw blade while it is rotating.
19. Always keep your hands removed from the track
of the saw blades.
20. Never pick up the workpiece by grasping with your
hands along or behind the saw blade.
21. Ensure that the workpiece never touches the saw
blade, before the machine has been switched on.
22. Never process metal or stone sorts with this ma-
chine.
23. Use support aids in order to support long work-
pieces.
24. Never use the machine in a dangerous environ-
ment, where inflammable gases or fluids are pre-
sent.
25. Never leave the machine unattended without first
disconnecting it from the mains voltage.
26. If you hear abnormal noises, try to trace them or
take the machine to a recognized fitter, or repair
company.
27. If a part is broken or damaged, replace it or repair it
immediately.
28. Never stand in the track of the saw blade but stand
to the left or the right of the saw bench.
29. Your hands must likewise be placed next to the
track of the saw blade.
30. Never use a wooden pole instead of your hands to
push the wood through the saw.
31. Always place the wood at the front of the saw ben-
ch and then push it further back.
kg.
EXPLODED VIEW 1
kg
REF.NR.
1/2/3
13-18
19/20
22-35
45
46
47
54
56
59/60/61
81
82
83
83
84
103
111
115/116
Ferm Ferm
AVAILABLE SPARE PARTS FOR FZT-250
DESCRIPTION
SAWBLADE COVER COMPLETE
ANGLE GAUGE COMPLETE
TABLE INSERT
SAWGUIDE COMPLETE
GEAR SHAFT
KEY
GEAR
ROTOR
STATOR
CARBON BRUSH + HOLDER
HEX. NUT M16 x 1.5
OUTSIDE FLANGE
HARD METAL SAW BLADE 250 x 30 x16, T36
HARD METAL SAW BLADE 250 x 30 x 16, T30
INSIDE FLANGE
CRANK
MAGNETIC SWITCH
FIXED BRACKET + RING
FERM NR.
407460
407461
407462
407463
407464
407465
407466
407467
407468
407469
407472
407470
327252
310360
407471
407473
407474
407475
