27.7 ProtoVlan Protocol Add Llc

VCL>ProtoVlan Protocol Add Llc ?
Description:
Add VCL protocol-based VLAN LLC protocol to group mapping. The maximum protocol to
group mappings are limited to 128.
Syntax:
VCL ProtoVlan Protocol Add Llc <dsap> <ssap> <group_id>
Parameters:
<dsap>
<ssap>
<group_id>

27.8 ProtoVlan Protocol Delete Eth2

VCL>ProtoVlan Protocol Delete Eth2 ?
Description:
Delete VCL protocol-based VLAN Ethernet-II protocol to group mapping.
Syntax:
VCL ProtoVlan Protocol Delete Eth2 <ether_type>|arp|ip|ipx|at
Parameters:
<ether_type>|arp|ip|ipx|at
Instruction Manual
277
DSAP value (0x00-0xFF)
SSAP value (0x00-0xFF)
Protocol group ID
Ether Type (0x0600 - 0xFFFF)
