17.7 Port Classification Map

QoS>Port Classification Map ?
Description:
Set or show the port classification map.
This map is used when port classification tag is enabled,
and the purpose is to translate the Priority Code Point (PCP) and
Drop Eligible Indicator (DEI) from a tagged frame to QoS class
and DP level.
Syntax:
QoS Port Classification Map [<port_list>] [<pcp_list>] [<dei_list>] [<class>] [<dpl>]
Parameters:
<port_list>
<pcp_list>
<dei_list>
<class>
<dpl>
Instruction Manual
199
Port list or 'all', default: All ports
PCP list or 'all', default: All PCPs (0-7)
DEI list or 'all', default: All DEIs (0-1)
QoS class (0-7)
Drop Precedence Level (0-1)
