Parameters:
<ace_id>
<ace_id_next>
port Port ACE keyword
<port_list> Port list or 'all', default: All ports
policy Policy ACE keyword
<policy> Policy number (0-255)
<policy_bitmask> Policy number bitmask (0x0-0xFF)
<tagged> Tagged of frames: any|enable|disable
<vid>
<tag_prio> VLAN tag priority (0-7) or 'any'
<dmac_type>
etype
<etype>
<smac>
<dmac>
arp
<sip>
<dip>
<arp_opcode>
<arp_flags> ARP flags: request|smac|tmac|len|ip|ether [0|1|any]
ip IP keyword
<protocol> IP protocol number (0-255) or 'any'
<ip_flags> IP flags: ttl|options|fragment [0|1|any]
icmp ICMP keyword
<icmp_type> ICMP type number (0-255) or 'any'
<icmp_code>
udp UDP keyword
<sport>
<dport>
tcp
<tcp_flags> TCP flags: fin|syn|rst|psh|ack|urg [0|1|any]
permit Permit forwarding (default)
Instruction Manual
126
ACE ID (1-256), default: Next available ID
Next ACE ID (1-256), default: Add ACE last
VLAN ID (1-4095) or 'any'
DMAC type: any|unicast|multicast|broadcast
Ethernet Type keyword
Ethernet Type: 0x600 - 0xFFFF or 'any' but excluding
0x800(IPv4) 0x806(ARP) and 0x86DD(IPv6)
Source MAC address ('xx-xx-xx-xx-xx-xx' or 'xx.xx.xx.xx.xx.xx' or
'xxxxxxxxxxxx', x is a hexadecimal digit) or 'any'
Destination MAC address ('xx-xx-xx-xx-xx-xx' or 'xx.xx.xx.xx.xx.xx' or
'xxxxxxxxxxxx', x is a hexadecimal digit) or 'any'
ARP keyword
Source IP address (a.b.c.d/n) or 'any'
Destination IP address (a.b.c.d/n) or 'any'
ARP operation code: any|arp|rarp|other
ICMP code number (0-255) or 'any'
Source UDP/TCP port range (0-65535) or 'any'
Destination UDP/TCP port range (0-65535) or 'any'
TCP keyword
