17.31 DSCP Classification Map

QoS>DSCP Classification Map ?
Description:
Set or show DSCP ingress classification table.
This table is used to map DSCP from QoS class and DP level. The DSCP
which needs to be classified depends on port DSCP classification and
DSCP classification mode. Incoming frame DSCP may be translated beforeusing the value
for classification.
Syntax:
QoS DSCP Classification Map [<class_list>] [<dpl_list>] [<dscp>]
Parameters:
<class_list>
<dpl_list>
<dscp>

17.32 DSCP EgressRemap

QoS>DSCP EgressRemap ?
Description:
Set or show DSCP egress remap table. This table is used if the port
egress remarking mode is 'remap' and the purpose is to map the
DSCP and DP level to a new DSCP value.
Syntax:
QoS DSCP EgressRemap [<dscp_list>] [<dpl_list>] [<dscp>]
Instruction Manual
213
QoS class list or 'all', default: All QoS classes (0-7)
DP level list or 'all', default: All DP levels (0-1)
Mapped DSCP: 0-63, BE, CS1-CS7, EF or AF11-AF43
