before this QCE in the list. If the next QCE ID is not specified and if it
is a new entry added, the QCE will be placed last in the list. Otherwise if
the next QCE ID is not specified and if existing QCE is modified, QCE will
be in the same location in the list. To modify and move the entry to last in
the list, use the word 'last' for <qce_id_next>.
Syntax:
QoS QCL Add [<qce_id>] [<qce_id_next>] [<port_list>] [<tag>] [<vid>] [<pcp>] [<dei>]
[<smac>] [<dmac_type>] [(etype [<etype>]) |
(LLC [<DSAP>] [<SSAP>] [<control>]) |
(SNAP [<PID>]) |
(ipv4 [<protocol>] [<sip>] [<dscp>] [<fragment>] [<sport>] [<dport>]) |
(ipv6 [<protocol>] [<sip_v6>] [<dscp>] [<sport>] [<dport>])]
[<class>] [<dp>] [<classified_dscp>]
Parameters:
<qce_id>
<qce_id_next>
<port_list>
<tag>
<vid>
<pcp>
<dei>
<smac>
<dmac_type>
etype
<etype>
llc
<dsap>
<ssap>
<control>
snap
<pid>
Instruction Manual
216
QCE ID (1-256), default: Next available ID
Next QCE ID: "next_id (1-256) or 'last'"
Port List: "port <port_list> or 'all'", default: All ports
Frame tag: untag|tag|any
VID: 1-4095 or 'any', either a specific VID or range of VIDs
Priority Code Point: specific(0, 1, 2, 3, 4, 5, 6, 7) or
range(0-1, 2-3, 4-5, 6-7, 0-3, 4-7) or 'any'
Drop Eligible Indicator: 0-1 or 'any'
Source MAC address: (xx-xx-xx) or 'any', 24 MS bits (OUI)
Destination MAC type: unicast|multicast|broadcast|any
Ethernet Type keyword
Ethernet Type: 0x600-0xFFFF or 'any' but excluding 0x800(IPv4)
and 0x86DD(IPv6)
LLC keyword
Destination Service Access Point: 0x00-0xFF or 'any'
Source Service Access Point: 0x00-0xFF or 'any'
LLC control: 0x00-0xFF or 'any'
SNAP keyword
Protocol ID (EtherType) or 'any'
