27.5 ProtoVlan Protocol Add Eth2

VCL>ProtoVlan Protocol Add Eth2 ?
Description:
Add VCL protocol-based VLAN Ethernet-II protocol to group mapping. The maximum
protocol to group mappings are limited to 128.
Syntax:
VCL ProtoVlan Protocol Add Eth2 <ether_type>|arp|ip|ipx|at <group_id>
Parameters:
<ether_type>|arp|ip|ipx|at
<group_id>

27.6 ProtoVlan Protocol Add Snap

VCL>ProtoVlan Protocol Add Snap ?
Description:
Add VCL protocol-based VLAN SNAP protocol to group mapping. The maximum protocol to
group mappings are limited to 128.
Syntax:
VCL ProtoVlan Protocol Add Snap <oui>|rfc_1042|snap_8021h <pid> <group_id>
Parameters:
<oui>|rfc_1042|snap_8021h OUI value (Hexadecimal 00-00-00 to FF-FF-FF).
<pid>
<group_id>
Instruction Manual
276
Ether Type (0x0600 - 0xFFFF)
Protocol group ID
PID value (0x0-0xFFFF). If OUI is 00-00-00, valid range of
PID is from 0x0600-0xFFFF.
Protocol group ID
