streaming_video
video_signaling
tagged
<vlan_id>
<l2_priority>
<dscp>
13.6 port policies
LLDPMED>port policies ?
Description:
Set or show LLDP-MED port policies.
Syntax:
LLDPMED port policies [<port_list>] [<policy_list>]
Parameters:
<port_list>
<policy_list>
Instruction Manual
182
equipment and other similar appliances supporting real-time
interactive video/audio services.
Streaming Video for use by broadcast or multicast based video
content distribution and other similar applications supporting
streaming video services that require specific network policy
treatment. Video applications relying on TCP with buffering would
not be an intended use of this application type.
Video Signaling (conditional) for use in network topologies that
require a separate policy for the video signaling than for the video
media.
The device is using tagged framesunragged
is using untagged frames
VLAN id
This field may specify one of eight priority levels (0 through 7), as
defined by IEEE 802.1D-2004 [3].
This field shall contain the DSCP value to be used to provide
Diffserv node behavior for the specified application type as
defined in IETF RFC 2474 [5]. This 6 bit field may contain one
of 64 code point values (0 through 63). A value of 0
represents use of the default DSCP value as defined in RFC
2475.
Port list or 'all', default: All ports
List of policies to delete
: The device
