Seite 1 10 Port L2 Managed Gigabit Ethernet Switch with 2 Open SFP Slots ‐ Rack Mountable IES101002SFP DE: Bedienungsanleitung ‐ de.startech.com FR: Guide de l'utilisateur ‐ fr.startech.com ES: Guía del usuario ‐ es.startech.com IT: Guida per l'uso ‐ it.startech.com NL: Gebruiksaanwijzing ‐ nl.startech.com PT: Guia do usuário ‐ pt.startech.com For the latest information, technical specifications, and support for this product, please visit www.startech.com/IES101002SFP. ...
Seite 2 ABOUT THIS MANUAL Purpose This manual gives specific information on how to configure and manage the IES10100S2FP using the terminal console and telnet utility. Audience This manual is intended for use by network administrators who are responsible for operating and maintaining network equipment ; consequently, it assumes a basic network network knowledge of general switch functions, the Internet Protocol (IP), and Standard and Simple Network Management Protocol (SNMP).
Seite 3: Inhaltsverzeichnis
CONTENTS Content 1.GENERAL ............................ 1 3 General Commands .................... 1 3 Command Groups .................... 1 3 2. SYSTEM ............................ 1 5 2.1 Configuration ........................ 1 6 2.2 Log Configuration ....................... 1 6 ...
Seite 4 3.6 DNS_Proxy .......................... 3 0 3.7 IPv6 AUTOCONFIG ...................... 3 1 3.8 IPv6 Setup ........................... 3 2 3.9 IPv6 State .......................... 3 3 3.10 NTP Configuration ...................... 3 3 3.11 NTP Mode .......................... 3 4 3.12 NTP Mode ...
Seite 5 6.6 TX_tag .......................... 5 3 6.7 PortType .......................... 5 3 6.8 EtypeCustomSport ...................... 5 4 6.9 Add 54 6.9 Forbidden Add ........................ 5 5 6.10 Delete .......................... 5 5 6.11 Forbbiden Delete ...................... 5 6 ...
Seite 6 8.3.1 Configuration ...................... 1 43 8.3.2 Timeout ........................ 1 43 8.3.3 Deadtime ........................ 1 44 8.3.4 RADIUS ........................ 1 44 8.3.5 ACCT_RADIUS ..................... 1 45 8.3.6 TACACS+ ....................... 1 46 8.3.7 Statistics ......................... 1 46 9.STP .............................. 1 47 ...
Seite 7 10.1 Configuration ........................ 1 62 10.2 Add 1 62 10.4 Lookup .......................... 1 63 10.5 Mode .......................... 1 64 11.LACP ............................ 1 65 11.1 Configuration ........................ 1 66 11.2 Mode .......................... 1 66 ...
Seite 8 14.1 Configuration ........................ 1 87 14.2 Mode .......................... 1 87 14.3 Urgent_queues ....................... 1 88 15.THERMAL ........................... 1 89 15.1 prio_temp ......................... 1 89 15.2 port_prio ........................... 1 90 15.3 Status .......................... ...
Seite 9 17.24 Port DSCP Translation .................... 2 08 17.25 Port DSCP Classification .................... 2 08 17.26 Port DSCP EgressRemark .................. 2 09 17.27 DSCP Map ........................ 2 10 17.28 DSCP Translation ...................... 2 10 17.29 DSCP Trust ........................ 2 11 ...
Seite 10 22.2 Mode .......................... 2 29 22.3 VLAN Setup ........................ 2 30 22.4 VLAN Mode ........................ 2 30 22.5 VLAN Port ........................ 2 31 22.6 VLAN LLQI ........................ 2 31 22.7 VLAN Channel ........................ 2 32 ...
Seite 11 25.2 Mode .......................... 2 50 25.3 Flooding ........................... 2 51 25.4 Leave Proxy ........................ 2 51 25.5 Proxy .......................... 2 52 25.6 SSM .......................... 2 53 25.7 VLAN Add ........................ 2 53 25.8 VLAN Delete ........................ 2 54 ...
Seite 12 27.6 ProtoVlan Protocol Add Snap .................. 2 76 27.7 ProtoVlan Protocol Add Llc ................... 2 77 27.8 ProtoVlan Protocol Delete Eth2 ................... 2 77 27.9 ProtoVlan Protocol Delete Snap .................. 2 78 27.10 ProtoVlan Protocol Delete Llc .................. 2 78 ...
Seite 13: General
1.GENERAL 1.1 General Commands General Commands Description Help/? Get help on a group or a specific command Move one command level up Logout Exit CLI Command Prompt > You can issue supported command here after login successfully. 1.2 Command Groups Command Groups Description System...
Seite 14 UPnP Universal Plug and Play Multicast VLAN Registration Voice VLAN Specific VLAN for voice traffic Loop Protect Loop Protection IPMC MLD/IGMP Snooping sFlow sFlow Agent VLAN Control List Type '<group>' to enter command group, e.g. 'port'. Type '<group> ?' to get list of group commands, e.g. 'port ?'. Type '<command>...
Seite 15: System
Chapter 2 SYSTEM 2. SYSTEM Available Commands: System Configuration [all | (port <port_list>)] System Log Configuration System Timezone Configuration System Version System Log Server Mode [enable|disable] System Name [<name>] System Timezone Offset [<offset>] System Contact [<contact>] System Log Server Address [<ip_addr_string>] System Timezone Acronym [<acronym>] System DST Configuration System Location [<location>]...
Seite 16: Configuration
2.1 Configuration System>configuration ? Description: Show system configuration. Syntax: System Configuration [all | (port <port_list>)] Parameters: Show all switch configuration, default: Show system configuration port Show switch port configuration <port_list> Port list or 'all', default: All ports 2.2 Log Configuration System>...
Seite 17: Version
System Timezone Configuration 2.4 Version System>version ? Description: Show system version information. Syntax: System Version 2.5 Log Server Mode System>log server mode ? Description: Show or set the system log server mode. Syntax: System Log Server Mode [enable|disable] Parameters: enable Enable system log server mode disable...
Seite 18: Timezone Offset
2.6 Name System>name ? Description: Set or show the system name. Syntax: System Name [<name>] Parameters: <name>: System name string. (1-255) Use "" to clear the string System name is a text string drawn from the alphabet (A-Za-z), digits (0-9), minus sign (-). No blank or space characters are permitted as part of a name.
Seite 19: Contact
2.8 Contact System>contact ? Description: Set or show the system contact. Syntax: System Contact [<contact>] Parameters: <contact> System contact string. (1-255) Use "" to clear the string In CLI, No blank or space characters are permitted as part of a contact.
Seite 20: Timezone Acronym
2.10 Timezone Acronym System>timezone acronym ? Description: Set or show the system timezone acronym. Syntax: System Timezone Acronym [<acronym>] Parameters: <acronym> Time zone acronym ( 0 - 16 characters ) 2.11 DST Configuration System>dst configuration ? Description: Show Daylight Saving Time configuration. Syntax: System DST Configuration ...
Seite 21: Location
2.12 Location System>location ? Description: Set or show the system location. Syntax: System Location [<location>] Parameters: <location> System location string. (1-255) Use "" to clear the string In CLI, no blank or space characters are permitted as part of a location.
Seite 22: Dst Mode
2.14 DST Mode System>dst mode ? Description: Set or show the daylight saving time mode. Syntax: System DST Mode [disable|recurring|non-recurring] Parameters: Disable Disable Daylight Saving Time recurring Enable Daylight Saving Time as recurring mode non-recurring Enable Daylight Saving Time as non-recurring mode 2.15 DST Start System>DST start ? Description:...
Seite 23: Log Lookup
<hour> : Hour (0-23) <minute>: Minutes (0-59) 2.16 Log Lookup System>log lookup ? Description: Show the system log. Syntax: System Log Lookup [<log_id>] [all|info|warning|error] Parameters: <log_id>: System log ID or range (default: All entries) : Show all levels (default) info : Show informations warning : Show warnings...
Seite 24: Log Clear
<date> : Date (1-31), 0: ignored <year> : Year (2000-2097) <hour> : Hour (0-23) <minute>: Minutes (0-59) 2.18 Log Clear System>log clear ? Description: Clear the system log. Syntax: System Log Clear [all|info|warning|error] Parameters: : Show all levels (default) info : Show informations warning : Show warnings...
Seite 25: Dst Offset
2.20 Dst offset System>Dst offset ? Description: Set or show the daylight saving time offset. Syntax: System DST Offset [<dst_offset>] Parameters: <dst_offset>: DST offset in minutes (1 to 1440) 2.21 Restore Default System>Restore Default ? Description: Restore factory default configuration. Syntax: System Restore Default [keep_ip] Parameters:...
Seite 26: Load
2.22 Load System>Load ? Description: Show current CPU load: 100ms, 1s and 10s running average (in percent, zero is idle). Syntax: System Load Instruction Manual 26 ...
Seite 27 Chapter 3 3. IP Available Commands: IP Configuration IP DHCP [enable|disable] IP Setup [<ip_addr>] [<ip_mask>] [<ip_router>] [<vid>] IP Ping <ip_addr_string> [(Length <ping_length>)] [(Count <ping_count>)] [(Interval <ping_interval>)] IP DNS [<ip_addr>] IP DNS_Proxy [enable|disable] IP IPv6 AUTOCONFIG [enable|disable] IP IPv6 Setup [<ipv6_addr>] [<ipv6_prefix>] [<ipv6_router>] IP IPv6 State <ipv6_addr>...
Seite 28: Configuration
3.1 Configuration IP>Configuration ? Description: Show IP configuration. Syntax: IP Configuration 3.2 DHCP IP>DHCP ? Description: Set or show the DHCP client mode. Syntax: IP DHCP [enable|disable] Parameters: enable Enable or renew DHCP client disable Disable DHCP client ...
Seite 29: Setup
3.3 Setup IP>setup ? Description: Set or show the IP setup. Syntax: IP Setup [<ip_addr>] [<ip_mask>] [<ip_router>] [<vid>] Parameters: <ip_addr> : IP address (a.b.c.d), default: Show IP address <ip_mask> : IPv4 subnet mask (a.b.c.d), default: Show IPv4 mask <ip_router>: IPv4 router (a.b.c.d), default: Show IPv4 router <vid>...
Seite 30: Dns
interval PING Interval keyword <ping_interval> Ping interval (0-30; Default is 0) 3.5 DNS IP>DNS ? Description: Set or show the DNS server address. Syntax: IP DNS [<ip_addr>] Parameters: <ip_addr>: IP address (a.b.c.d), default: Show IP address 3.6 DNS_Proxy IP>DNS_Proxy ? Description: Set or show the IP DNS Proxy mode.
Seite 31: Ipv6 Autoconfig
3.7 IPv6 AUTOCONFIG IP>IPv6 AUTOCONFIG ? Description: Set or show the IPv6 AUTOCONFIG mode. Syntax: IP IPv6 AUTOCONFIG [enable|disable] Parameters: enable Enable IPv6 AUTOCONFIG mode disable Disable IPv6 AUTOCONFIG mode Instruction Manual 31 ...
Seite 32: Ipv6 Setup
3.8 IPv6 Setup IP>IPv6 Setup ? Description: Set or show the IPv6 setup. Syntax: IP IPv6 Setup [<ipv6_addr>] [<ipv6_prefix>] [<ipv6_router>] Parameters: <ipv6_addr> IPv6 address is in 128-bit records represented as eight fields of up to four hexadecimal digits with a colon separates each field (:).
Seite 33: Ipv6 State
3.9 IPv6 State IP>IPv6 State ? Description: Set or show the IPv6 Interface operational state. Syntax: IP IPv6 State <ipv6_addr> [enable|disable] Parameters: <ipv6_addr> IPv6 address is in 128-bit records represented as eight fields of up to four hexadecimal digits with a colon separates each field (:).
Seite 34: Ntp Mode
IP NTP Configuration 3.11 NTP Mode IP>NTP Mode ? Description: Set or show the NTP mode. Syntax: IP NTP Mode [enable|disable] Parameters: enable Enable NTP mode disable Disable NTP mode (default: Show NTP mode) 3.12 NTP Mode IP>NTP Server Add ? Description: Add NTP server entry.
Seite 35: Ntp Server Ipv6 Add
3.13 NTP Server IPv6 Add IP>NTP Server IPv6 Add ? Description: Add NTP server IPv6 entry. Syntax: IP NTP Server Ipv6 Add <server_index> <server_ipv6> Parameters: <server_index> The server index (1-5) <server_ipv6> IPv6 server address. IPv6 address is in 128-bit records represented as eight fields of up to four hexadecimal digits with a colon separates each field (:).
Seite 36: Ntp Server Delete
<server_index>: The server index (1-5) 3.15 NTP Server Delete IP>NTP Server Delete ? Description: Delete NTP server entry. Syntax: IP NTP Server Delete <server_index> Parameters: <server_index>: The server index (1-5) Instruction Manual 36 ...
Seite 37: Port
Chapter 4 PORT 4. PORT Available Commands: Port Configuration [<port_list>] [up|down] Port Mode [<port_list>] [auto|10hdx|10fdx|100hdx|100fdx|1000fdx|sfp_auto_ams] Port Flow Control [<port_list>] [enable|disable] Port State [<port_list>] [enable|disable] Port MaxFrame [<port_list>] [<max_frame>] Port Power [<port_list>] [enable|disable|actiphy|dynamic] Port Excessive [<port_list>] [discard|restart] Port Statistics [<port_list>] [<command>] [up|down] Port VeriPHY [<port_list>] Port SFP [<port_list>] ...
Seite 38: Configuration
4.1 Configuration Port>Configuration ? Description: Show port configuration. Syntax: Port Configuration [<port_list>] [up|down] Parameters: <port_list>: Port list or 'all', default: All ports : Show ports, which are up down : Show ports, which are down 4.2 Mode Port>Mode ? Description: Set or show the port speed and duplex mode.
Seite 39: Flow Control
100fdx 100 Mbps, full duplex 1000fdx 1 Gbps, full duplex sfp_auto_ams Auto detection of SFP (default: Show configured and current mode) 4.3 Flow Control Port>Flow Control ? Description: Set or show the port flow control mode. Syntax: Port Flow Control [<port_list>] [enable|disable] Parameters: <port_list>...
Seite 40: Maxframe
disable Disable port (default: Show administrative mode) 4.5 MaxFrame Port>MaxFrame ? Description: Set or show the port maximum frame size. Syntax: Port MaxFrame [<port_list>] [<max_frame>] Parameters: <port_list> Port list or 'all', default: All ports <max_frame> Port maximum frame size (1518-9600), default: Show maximum frame size 4.6 Power Port>Power ? Description:...
Seite 41: Excessive
4.7 Excessive Port>Excessive ? Description: Set or show the port excessive collision mode. Syntax: Port Excessive [<port_list>] [discard|restart] Parameters: <port_list> Port list or 'all', default: All ports discard Discard frame after 16 collisions restart Restart backoff algorithm after 16 collisions (default: Show mode) ...
Seite 42: Statistics
4.8 Statistics Port>Statistics ? Description: Show port statistics. Syntax: Port Statistics [<port_list>] [<command>] [up|down] Parameters: <port_list> Port list or 'all', default: All ports <command> The command parameter takes the following values: clear Clear port statistics packets Show packet statistics bytes Show byte statistics errors...
Seite 43: Sfp
Parameters: <port_list> Port list or 'all', default: All ports 4.10 SFP Port>SFP ? Description: Show the detected sfp type. Syntax: Port SFP [<port_list>] Parameters: <port_list> Port list or 'all', default: All ports Instruction Manual 43 ...
Seite 44: Mac
Chapter 5 5.MAC Available Commands: MAC Configuration [<port_list>] MAC Add <mac_addr> <port_list> [<vid>] MAC Delete <mac_addr> [<vid>] MAC Lookup <mac_addr> [<vid>] MAC Agetime [<age_time>] MAC Learning [<port_list>] [auto|disable|secure] MAC Dump [<mac_max>] [<mac_addr>] [<vid>] MAC Statistics [<port_list>] MAC Flush ...
Seite 45: Configuration
5.1 Configuration MAC>configuration ? Description: Show MAC address table configuration. Syntax: MAC Configuration [<port_list>] Parameters: <port_list>: Port list or 'all', default: All ports 5.2 Add MAC>Add ? Description: Add MAC address table entry. Syntax: MAC Add <mac_addr> <port_list> [<vid>] Parameters: <mac_addr>...
Seite 46: Delete
5.3 Delete MAC>delete ? Description: Delete MAC address entry. Syntax: MAC Delete <mac_addr> [<vid>] Parameters: <mac_addr> MAC address ('xx-xx-xx-xx-xx-xx' or 'xx.xx.xx.xx.xx.xx' or 'xxxxxxxxxxxx', x is a hexadecimal digit) <vid> VLAN ID (1-4095), default: 1 5.4 Lookup MAC>Lookup ? Description: Lookup MAC address entry.
Seite 47: Agetime
5.5 Agetime MAC>Agetime ? Description: Set or show the MAC address age timer. Syntax: MAC Agetime [<age_time>] Parameters: <age_time>: MAC address age time (0,10-1000000) 0=disable, default: Show age time 5.6 Learning MAC>Learning ? Description: Set or show the port learn mode. Syntax: MAC Learning [<port_list>] [auto|disable|secure] Parameters:...
Seite 48: Dump
5.7 Dump MAC>Dump ? Description: Show sorted list of MAC address entries. Syntax: MAC Dump [<mac_max>] [<mac_addr>] [<vid>] Parameters: <mac_max> Maximum number of MAC addresses, default: Show all addresses <mac_addr> First MAC address ('xx-xx-xx-xx-xx-xx' or 'xx.xx.xx.xx.xx.xx' or 'xxxxxxxxxxxx', x is a hexadecimal digit), default: MAC address zero <vid>...
Seite 49: Flush
5.9 Flush MAC>flush ? Description: Flush all learned entries. Syntax: MAC Flush Instruction Manual 49 ...
Seite 50: Vlan
Chapter 6 VLAN 6.VLAN Available Commands: VLAN Configuration [<port_list>] VLAN PVID [<port_list>] [<vid>|none] VLAN FrameType [<port_list>] [all|tagged|untagged] VLAN IngressFilter [<port_list>] [enable|disable] VLAN tx_tag [<port_list>] [untag_pvid|untag_all|tag_all] VLAN PortType [<port_list>] [unaware|c-port|s-port|s-custom-port] VLAN EtypeCustomSport [<etype>] VLAN Add <vid>|<name> [<ports_list>] VLAN Forbidden Add <vid>|<name> [<port_list>] VLAN Delete <vid>|<name>...
Seite 51: Configuration
6.1 Configuration VLAN>Configuration ? Description: Show VLAN configuration. Syntax: VLAN Configuration [<port_list>] Parameters: <port_list> Port list or 'all', default: All ports 6.2 PVID VLAN>PVID ? Description: Set or show the port VLAN ID. Syntax: VLAN PVID [<port_list>] [<vid>|none] Parameters: <port_list>...
Seite 52: Frametype
6.4 FrameType VLAN>FrameType ? Description: Set or show the port VLAN frame type. Syntax: VLAN FrameType [<port_list>] [all|tagged|untagged] Parameters: <port_list>: Port list or 'all', default: All ports : Allow tagged and untagged frames tagged : Allow tagged frames only untagged : Allow untagged frames only (default: Show accepted frame types)
Seite 53: Tx_Tag
(default: Show VLAN ingress filtering) 6.6 TX_tag VLAN>tx_tag ? Description: Set or show the port egress tagging. Syntax: VLAN tx_tag [<port_list>] [untag_pvid|untag_all|tag_all] Parameters: <port_list> Port list or 'all', default: All ports Tx tag (Egress tagging) untag_pvid All VLANs except pvid will be tagged untag_all All VLANs will be untagged tag_all...
Seite 54: Etypecustomsport
6.8 EtypeCustomSport VLAN>EtypeCustomSport ? Description: Set or show the Custom S-port EtherType. Syntax: VLAN EtypeCustomSport [<etype>] Parameters: Ether Type (0x0600-0xFFFF) 6.9 Add VLAN>Add ? Description: Add or modify VLAN entry. Syntax: VLAN Add <vid>|<name> [<ports_list>] Parameters: <vid>|<name> VLAN ID (1-4095) or VLAN Name <ports_list>...
Seite 55: Forbidden Add
6.9 Forbidden Add VLAN>Forbidden Add ? Description: Add or modify VLAN entry in forbidden table. Syntax: VLAN Forbidden Add <vid>|<name> [<port_list>] Parameters: <vid>|<name> VLAN ID (1-4095) or VLAN Name <port_list> Port list or 'all', default: All ports 6.10 Delete VLAN>Delete ? Description: Delete VLAN entry.
Seite 56: Forbbiden Delete
6.11 Forbbiden Delete VLAN>Forbidden Delete ? Description: Delete VLAN entry. Syntax: VLAN Forbidden Delete <vid>|<name> Parameters: <vid>|<name> VLAN ID (1-4095) or VLAN Name 6.12 Forbbiden Lookup VLAN>Forbidden Lookup ? Description: Lookup VLAN Forbidden port entry. Syntax: VLAN Forbidden Lookup [<vid>] [(name <name>)] Parameters: <vid>...
Seite 57: Lookup
6.13 Lookup VLAN>Lookup ? Description: Lookup VLAN entry. Syntax: VLAN Lookup [<vid>] [(name <name>)] [combined|static|nas|mvr|voice_vlan|all] Parameters: <vid> VLAN ID (1-4095), default: Show all VLANs name VLAN name string <name> VLAN name - Maximum of 32 characters. VLAN Name can only contain alphabets or numbers.
Seite 58: Name Add
6.14 Name Add VLAN>Name Add ? Description: Add VLAN Name to a VLAN ID Mapping. Syntax: VLAN Name Add <name> <vid> Parameters: <name> VLAN name - Maximum of 32 characters. VLAN Name can only contain alphabets or numbers. VLAN name should contain at least one alphabet. <vid>...
Seite 59: Name Lookup
6.16 Name Lookup VLAN>Name Lookup ? Description: Show VLAN Name table. Syntax: VLAN Name Lookup [<name>] Parameters: <name>: VLAN name - Maximum of 32 characters. VLAN Name can only contain alphabets or numbers. VLAN name should contain at least one alphabet. 6.17 Status VLAN>Status ? Description:...
Seite 60: Pvlan
mstp MSTP port configuration VCL port configuration All VLAN Users configuration (default: all VLAN Users configuration) Chapter 7 PVLAN 7.PVLAN Available Commands: PVLAN Configuration [<port_list>] PVLAN Add <pvlan_id> [<port_list>] PVLAN Delete <pvlan_id> PVLAN Lookup [<pvlan_id>] PVLAN Isolate [<port_list>] [enable|disable] ...
Seite 61: Configuration
7.1 Configuration PVLAN>Configuration ? Description: Show Private VLAN configuration. Syntax: PVLAN Configuration [<port_list>] Parameters: <port_list> Port list or 'all', default: All ports 7.2 Add PVLAN>Add ? Description: Add or modify Private VLAN entry. Syntax: PVLAN Add <pvlan_id> [<port_list>] Parameters: <pvlan_id>...
Seite 62: Delete
7.3 Delete PVLAN>Delete ? Description: Delete Private VLAN entry. Syntax: PVLAN Delete <pvlan_id> Parameters: <pvlan_id> Private VLAN ID. The allowed range for a Private VLAN ID is the same as the switch port number range. 7.4 Lookup PVLAN>Lookup ? Description: Lookup Private VLAN entry.
Seite 63: Isolate
7.5 Isolate PVLAN>Isolate ? Description: Set or show the port isolation mode. Syntax: PVLAN Isolate [<port_list>] [enable|disable] Parameters: <port_list> Port list or 'all', default: All ports enable Enable port isolation disable Disable port isolation (default: Show port isolation port list) ...
Seite 64: Security
Chapter 8 SECURITY 8.SECURITY Command Groups: Switch : Switch security Network : Network security : Authentication, Authorization and Accounting 8.1 Switch Command Groups: Security Switch Users User management Security Switch Privilege Privilege level Security Switch Auth Authentication Security Switch SSH Secure Shell Security Switch HTTPS...
Seite 65: Switch Users
8.1.1 Switch Users Available Commands: Security Switch Users Configuration Security Switch Users Add <user_name> <password> <privilege_level> Security Switch Users Delete <user_name> 8.1.1.1 Configuration Security/Switch/Users>Configuration ? Description: Show users configuration. Syntax: Security Switch Users Configuration Instruction Manual 65 ...
Seite 66 8.1.1.2 Add Security/Switch/Users>Add ? Description: Add or modify users entry. Syntax: Security Switch Users Add <user_name> <password> <privilege_level> Parameters: <user_name> A string identifying the user name that this entry should belong to. The allowed string length is (1-31). The valid user name is a combination of letters, numbers and underscores <password>...
Seite 67: Switch Privilege
user name is a combination of letters, numbers and underscores 8.1.2 Switch Privilege Available Commands: Security Switch Privilege Level Configuration Security Switch Privilege Level Group <group_name> [<cro>] [<crw>] [<sro>] [<srw>] Security Switch Privilege Level Current 8.1.2.1 Level Configuration Security/Switch/Privilege>Level Configuration ? Description: Show privilege configuration.
Seite 68 8.1.2.2 Level Group Security/Switch/Privilege>Level Group ? Description: Configure a privilege level group. Syntax: Security Switch Privilege Level Group <group_name> [<cro>] [<crw>] [<sro>] [<srw>] Parameters: <group_name> Privilege group name <cro> Configuration read-only privilege level (1-15) <crw> Configuration/Execute read-write privilege level (1-15) <sro>...
Seite 69: Switch Auth
8.1.3 Switch Auth Available Commands: Security Switch Auth Configuration Security Switch Auth Method [console|telnet|ssh|web] [none|local|radius|tacacs+] [enable|disable] 8.1.3.1 Configuration Security/Switch/Auth>Configuration ? Description: Show Auth configuration. Syntax: Security Switch Auth Configuration Instruction Manual 69 ...
Seite 70 8.1.3.2 Method Security/Switch/Auth>Method ? Description: Set or show Auth method. (default: Show Auth method). Syntax: Security Switch Auth Method [console|telnet|ssh|web] [none|local|radius|tacacs+] [enable|disable] Parameters: console Settings for console telnet Settings for telnet Settings for ssh Settings for web (default: Set or show the specific client authentication method) none Authentication disabled local...
Seite 71 8.1.4 Switch SSH Available Commands: Security Switch SSH Configuration Security Switch SSH Mode [enable|disable] 8.1.4.1 Configuration Security/Switch/SSH>Configuration ? Description: Show SSH configuration. Syntax: Security Switch SSH Configuration 8.1.4.2 Mode Security/Switch/SSH>Mode ? Description: Set or show the SSH mode. Syntax: Security Switch SSH Mode [enable|disable] Parameters: enable : Enable SSH...
Seite 72 (default: Show SSH mode) 8.1.5 Switch HTTPS Available Commands: Security Switch HTTPS Configuration Security Switch HTTPS Mode [enable|disable] Security Switch HTTPS Redirect [enable|disable] 8.1.5.1 Configuration Security/Switch/HTTPS>Configuration ? Description: Show HTTPS configuration. Syntax: Security Switch HTTPS Configuration 8.1.5.2 Mode Security/Switch/HTTPS>Mode ? Description: Set or show the HTTPS mode.
Seite 73: Switch Access
disable: Disable HTTPS (default: Show HTTPS mode) 8.1.5.3 Redirect Security/Switch/HTTPS>Redirect ? Description: Set or show the HTTPS redirect mode. Automatic redirect web browser to HTTPS during HTTPS mode enabled. Syntax: Security Switch HTTPS Redirect [enable|disable] Parameters: enable Enable HTTPS redirect disable Disable HTTPS redirect (default: Show HTTPS redirect mode)
Seite 74 Security Switch Access Clear Security Switch Access Statistics [clear] 8.1.6.1 Configuration Security/Switch/Access>Configuration ? Description: Show access management configuration. Syntax: Security Switch Access Configuration 8.1.6.2 Mode Security/Switch/Access>Mode ? Description: Set or show the access management mode. Syntax: Security Switch Access Mode [enable|disable] Parameters: enable Enable access management...
Seite 75 8.1.6.3 Add Security/Switch/Access>Add ? Description: Add access management entry, default: Add all supported protocols. Syntax: Security Switch Access Add <access_id> <start_ip_addr> <end_ip_addr> [web] [snmp] [telnet] Parameters: <access_id> entry index (1-16) <start_ip_addr> Start IP address (a.b.c.d) <end_ip_addr> End IP address (a.b.c.d) Indicates that the host can access the switch from HTTP/HTTPS snmp Indicates that the host can access the switch from SNMP...
Seite 76 8.1.6.4 IPv6 Add Security/Switch/Access>IPv6 Add ? Description: Add access management IPv6 entry, default: Add all supported protocols. Syntax: Security Switch Access Ipv6 Add <access_id> <start_ipv6_addr> <end_ipv6_addr> [web] [snmp] [telnet] Parameters: <access_id> entry index (1-16) <start_ipv6_addr> Start IPv6 address. IPv6 address is in 128-bit records represented as eight fields of up to four hexadecimal digits with a colon separates each field (:).
Seite 77 8.1.6.5 Delete Security/Switch/Access>Delete ? Description: Delete access management entry. Syntax: Security Switch Access Delete <access_id> Parameters: <access_id>: entry index (1-16) 8.1.6.6 Lookup Security/Switch/Access>Lookup ? Description: Lookup access management entry. Syntax: Security Switch Access Lookup [<access_id>] Parameters: <access_id>: entry index (1-16) ...
Seite 78 8.1.6.7 Clear Security/Switch/Access>Clear ? Description: Clear access management entry. Syntax: Security Switch Access Clear 8.1.6.8 Statistics Security/Switch/Access>Statistics ? Description: Show or clear access management statistics. Syntax: Security Switch Access Statistics [clear] Parameters: clear Clear access management statistics Instruction Manual ...
Seite 79: Switch Snmp
8.1.7 Switch SNMP Available Commands: Security Switch SNMP Configuration Security Switch SNMP Mode [enable|disable] Security Switch SNMP Version [1|2c|3] Security Switch SNMP Read Community [<community>] Security Switch SNMP Write Community [<community>] Security Switch SNMP Trap Mode [enable|disable] Security Switch SNMP Trap Version [1|2c|3] Security Switch SNMP Trap Community [<community>] Security Switch SNMP Trap Destination [<ip_addr_string>] Security Switch SNMP Trap IPv6 Destination [<ipv6_addr>]...
Seite 80 Security Switch SNMP Group Lookup [<index>] Security Switch SNMP View Add <view_name> [included|excluded] <oid_subtree> Security Switch SNMP View Delete <index> Security Switch SNMP View Lookup [<index>] Security Switch SNMP Access Add <group_name> <security_model> <security_level> [<read_view_name>] [<write_view_name>] Security Switch SNMP Access Delete <index> Security Switch SNMP Access Lookup [<index>] 8.1.7.1 Configuration Security/Switch/SNMP>Configuration ?
Seite 81 (default: Show SNMP mode) 8.1.7.3 Version Security/Switch/SNMP>Version ? Description: Set or show the SNMP protocol version. Syntax: Security Switch SNMP Version [1|2c|3] Parameters: SNMP version 1 SNMP version 2c SNMP version 3 (default: Show SNMP version) 8.1.7.4 Read Community Security/Switch/SNMP>Read Community ? Description: Set or show the community string for SNMP read access.
Seite 82 8.1.7.5 Write Community Security/Switch/SNMP>Write Community ? Description: Set or show the community string for SNMP write access. Syntax: Security Switch SNMP Write Community [<community>] Parameters: <community>: Community string. Use 'clear' or "" to clear the string Maximum length allowed is upto 256 characters. (default: Show SNMP write community) 8.1.7.6 Trap Mode Security/Switch/SNMP>Trap Mode ?
Seite 83 8.1.7.7 Trap Version Security/Switch/SNMP>Trap Version ? Description: Set or show the SNMP trap protocol version. Syntax: Security Switch SNMP Trap Version [1|2c|3] Parameters: SNMP version 1 SNMP version 2c SNMP version 3 (default: Show SNMP trap version) 8.1.7.8 Trap Community Security/Switch/SNMP>Trap community ? Description: Set or show the community string for SNMP traps.
Seite 84 8.1.7.9 Trap Destination Security/Switch/SNMP>Trap Destination ? Description: Set or Show the SNMP trap destination address. Syntax: Security Switch SNMP Trap Destination [<ip_addr_string>] Parameters: <ip_addr_string>: IP host address (a.b.c.d) or a host name string 8.1.7.10 Trap IPv6 Destination Security/Switch/SNMP>Trap IPv6 Destination ? Description: Set or Show the SNMP trap destination IPv6 address.
Seite 85 appear once. It also used a following legally IPv4 address. For example,'::192.1.2.34'. 8.1.7.11 Trap Authentication Failure Security/Switch/SNMP>Trap Authentication Failure ? Description: Set or show the SNMP authentication failure trap mode. Syntax: Security Switch SNMP Trap Authentication Failure [enable|disable] Parameters: enable Enable SNMP trap authentication failure disable...
Seite 86 8.1.7.13 Trap Inform Mode Security/Switch/SNMP>Trap Inform Mode ? Description: Set or show the SNMP trap inform mode. Syntax: Security Switch SNMP Trap Inform Mode [enable|disable] Parameters: Enable Enable SNMP trap inform Disable Disable SNMP trap inform (default: Show SNMP inform mode) 8.1.7.14 Trap Inform Timeout Security/Switch/SNMP>Trap Inform Timeout ? Description:...
Seite 87 8.1.7.15 Trap Inform Retry Times Security/Switch/SNMP>Trap inform Retry Times ? Description: Set or show the SNMP trap inform retry times. Syntax: Security Switch SNMP Trap Inform Retry Times [<retries>] Parameters: <retries> SNMP trap inform retransmited times (0-255) (default: Show SNMP trap inform retry times) 8.1.7.16 Trap Probe Security Engine ID Security/Switch/SNMP>Trap Probe Security Engine ID ? Description:...
Seite 88 8.1.7.17 Trap Security Engine ID Security/Switch/SNMP>Trap Security Engine ID ? Description: Set or show SNMP trap security engine ID. Syntax: Security Switch SNMP Trap Security Engine ID [<engineid>] Parameters: <engineid>: Engine ID, the format may not be all zeros or all 'ff'H and is restricted to 5 - 32 octet string 8.1.7.18 Trap Security Name Security/Switch/SNMP>Trap Security Name ?
Seite 89 8.1.7.19 Engine ID Security/Switch/SNMP>Engine ID ? Description: Set or show SNMPv3 local engine ID. Syntax: Security Switch SNMP Engine ID [<engineid>] Parameters: <engineid> Engine ID, the format may not be all zeros or all 'ff'H and is restricted to 5 - 32 octet string 8.1.7.20 Community Add Security/Switch/SNMP>Community Add ? Description:...
Seite 90 8.1.7.21 Community Delete Security/Switch/SNMP>Community Delete ? Description: Delete SNMPv3 community entry. Syntax: Security Switch SNMP Community Delete <index> Parameters: <index> entry index (1-64) 8.1.7.22 Community Lookup Security/Switch/SNMP>Community Lookup ? Description: Lookup SNMPv3 community entry. Syntax: Security Switch SNMP Community Lookup [<index>] Parameters: <index>...
Seite 91 8.1.7.23 User Add Security/Switch/SNMP>User Add ? Description: Add SNMPv3 user entry. The entry index key are <engineid> and <user_name> and it doesn't allow modify. Syntax: Security Switch SNMP User Add <engineid> <user_name> [MD5|SHA] [<auth_password>] [DES] [<priv_password>] Parameters: <engineid> Engine ID, the format may not be all zeros or all 'ff'H and is restricted to 5 - 32 octet string <user_name>...
Seite 92 8.1.7.24 User Delete Security/Switch/SNMP>User Delete ? Description: Delete SNMPv3 user entry. Syntax: Security Switch SNMP User Delete <index> Parameters: <index> entry index (1-64) 8.1.7.25 User Changekey Security/Switch/SNMP>User Changekey ? Description: Change SNMPv3 user password. Syntax: Security Switch SNMP User Changekey <engineid> <user_name> <auth_password>...
Seite 93 <auth_password> A string identifying the authentication pass phrase <priv_password> A string identifying the privacy pass phrase. The allowed string length is (8-40), and the allowed content is ASCII characters from 33 to 126 8.1.7.26 User Lookup Security/Switch/SNMP>User Lookup ? Description: Lookup SNMPv3 user entry.
Seite 94 <group_name> A string identifying the group name that this entry should belong to. The allowed string length is (1-32), and the allowed content is ASCII characters from 33 to 126 8.1.7.28 Group Delete Security/Switch/SNMP>Group Delete ? Description: Delete SNMPv3 group entry. Syntax: Security Switch SNMP Group Delete <index>...
Seite 95 8.1.7.30 View Add Security/Switch/SNMP>View Add ? Description: Add or modify SNMPv3 view entry. The entry index key are <view_name> and <oid_subtree>. Syntax: Security Switch SNMP View Add <view_name> [included|excluded] <oid_subtree> Parameters: <view_name> A string identifying the view name that this entry should belong to.
Seite 96 Parameters: <index> entry index (1-64) 8.1.7.32 View Lookup Security/Switch/SNMP>View Lookup ? Description: Lookup SNMPv3 view entry. Syntax: Security Switch SNMP View Lookup [<index>] Parameters: <index> entry index (1-64) Instruction Manual 96 ...
Seite 97 8.1.7.33 Access Add Security/Switch/SNMP>Access Add ? Description: Add or modify SNMPv3 access entry. The entry index key are <group_name>, <security_model> and <security_level>. Syntax: Security Switch SNMP Access Add <group_name> <security_model> <security_level> [<read_view_name>] [<write_view_name>] Parameters: <group_name> A string identifying the group name that this entry should belong to.
Seite 98 8.1.7.34 Access Delete Security/Switch/SNMP>Access Delete ? Description: Delete SNMPv3 access entry. Syntax: Security Switch SNMP Access Delete <index> Parameters: <index> entry index (1-64) 8.1.7.35 Access Lookup Security/Switch/SNMP>Access Lookup ? Description: Lookup SNMPv3 access entry. Syntax: Security Switch SNMP Access Lookup [<index>] Parameters: <index>...
Seite 99: Switch Rmon
8.1.8 Switch RMON Available Commands: Security Switch RMON Statistics Add <stats_id> <data_source> Security Switch RMON Statistics Delete <stats_id> Security Switch RMON Statistics Lookup [<stats_id>] Security Switch RMON History Add <history_id> <data_source> [<interval>] [<buckets>] Security Switch RMON History Delete <history_id> Security Switch RMON History Lookup [<history_id>] Security Switch RMON Alarm Add <alarm_id>...
Seite 100 8.1.8.1 Statistics Add Security/Switch/RMON>Statistics Add ? Description: Add or modify RMON Statistics entry. The entry index key is <stats_id>. Syntax: Security Switch RMON Statistics Add <stats_id> <data_source> Parameters: <stats_id> Statistics ID (1-65535). <data_source> The OID that indicates that the ifIndex in ifEntry. The value should be like .1.3.6.1.2.1.2.2.1.1.xxx.
Seite 101 8.1.8.3 Statistics Lookup Security/Switch/RMON>Statistics Lookup ? Description: Show RMON Statistics entries. Syntax: Security Switch RMON Statistics Lookup [<stats_id>] Parameters: <stats_id> Statistics ID (1-65535). 8.1.8.4 History Add Security/Switch/RMON>History Add ? Description: Add or modify RMON Hisotry entry. The entry index key is <history_id>. Syntax: Security Switch RMON History Add <history_id>...
Seite 102 8.1.8.5 History Delete Security/Switch/RMON>History Delete ? Description: Delete RMON Hisotry entry. The entry index key is <history_id>. Syntax: Security Switch RMON History Delete <history_id> Parameters: <history_id>: History ID (1-65535). 8.1.8.6 History Lookup Security/Switch/RMON>History Lookup ? Description: Show RMON History entries. Syntax: Security Switch RMON History Lookup [<history_id>] Parameters:...
Seite 103 8.1.8.7 Alarm Add Security/Switch/RMON>Alarm Add ? Description: Add or modify RMON Alarm entry. The entry index key is <alarm_id>. Syntax: Security Switch RMON Alarm Add <alarm_id> <interval> <alarm_variable> [absolute|delta] <rising_threshold> <rising_event_index> <falling_threshold> <falling_event_index> [rising|falling|both] Parameters: <alarm_id> Alarm ID (1-65535). <interval>...
Seite 104 <falling_threshold> Falling threshold value (-2147483648–2147483647). <falling_event_index> Falling event index (1-65535). rising Trigger alarm when the first value is larger than the rising threshold. falling Trigger alarm when the first value is less than the falling threshold. both Trigger alarm when the first value is larger than the rising threshold or less than the falling threshold (default) 8.1.8.8 Alarm Delete Security/Switch/RMON>Alarm Delete ?
Seite 105 <alarm_id> Alarm ID (1-65535). 8.1.8.10 Event Add Security/Switch/RMON>Event Add ? Description: Add or modify RMON Event entry. The entry index key is <event_id>. Syntax: Security Switch RMON Event Add <event_id> [none|log|trap|log_trap] [<community>] [<description>] Parameters: <event_id> Event ID (1-65535). none Get the sample directly.
Seite 106 Security Switch RMON Event Delete <event_id> Parameters: <event_id>: Event ID (1-65535). 8.1.8.12 Event Lookup Security/Switch/RMON>Event Lookup ? Description: Show RMON Event entries. Syntax: Security Switch RMON Event Lookup [<event_id>] Parameters: <event_id>: Event ID (1-65535). Instruction Manual 106 ...
Seite 107: Network
8.2 NETWORK Command Groups: Security Network Psec : Port Security Status Security Network Limit : Port Security Limit Control Security Network NAS : Network Access Server (IEEE 802.1X) Security Network ACL : Access Control List Security Network DHCP : Dynamic Host Configuration Protocol Security Network IP : IP Source Guard Security Network ARP...
Seite 108: Network Limit
<port_list> Port list or 'all', default: All ports 8.2.1.2 Port Security/Network/Psec>Port ? Description: Show MAC Addresses learned by Port Security. Syntax: Security Network Psec Port [<port_list>] Parameters: <port_list> Port list or 'all', default: All ports 8.2.2 Network Limit Available Commands: Security Network Limit Configuration [<port_list>] Security Network Limit Mode [enable|disable] Security Network Limit Aging [enable|disable]...
Seite 109: Configuration
8.2.2.1 Configuration Security/Network/Limit>configuration ? Description: Show Limit Control configuration. Syntax: Security Network Limit Configuration [<port_list>] Parameters: <port_list> Port list or 'all', default: All ports 8.2.2.2 Mode Security/Network/Limit>Mode ? Description: Set or show global state. Syntax: Security Network Limit Mode [enable|disable] Parameters: enable Globally enable port security...
Seite 110 8.2.2.3 Aging Security/Network/Limit>Aging ? Description: Set or show aging state. Syntax: Security Network Limit Aging [enable|disable] Parameters: enable Enable aging disable Disable aging (default: Show current state of aging) 8.2.2.4 Agetime Security/Network/Limit>agetime ? Description: Time in seconds between check for activity on learned MAC addresses. Syntax: Security Network Limit Agetime [<age_time>] Parameters:...
Seite 111 8.2.2.5 Port Security/Network/Limit>Port ? Description: Set or show per-port state. Syntax: Security Network Limit Port [<port_list>] [enable|disable] Parameters: <port_list> Port list or 'all', default: All ports enable Enable port security on this port disable Disable port security on this port (default: Show current port state of port security limit control) 8.2.2.6 Port Security/Network/Limit>Limit ?
Seite 112 8.2.2.7 Action Security/Network/Limit>Action ? Description: Set or show the action involved with exceeding the limit. Syntax: Security Network Limit Action [<port_list>] [none|trap|shut|trap_shut] Parameters: <port_list> Port list or 'all', default: All ports none|trap|shut|trap_shut: Action to be taken in case the number of MAC addresses exceeds the limit none Don't do anything...
Seite 113: Network Nas
Parameters: <port_list> Port list or 'all', default: All ports 8.2.3 Network NAS Available Commands: Security Network NAS Configuration [<port_list>] Security Network NAS Mode [enable|disable] Security Network NAS State [<port_list>] [auto|authorized|unauthorized|single|multi|macbased] Security Network NAS Reauthentication [enable|disable] Security Network NAS ReauthPeriod [<reauth_period>] Security Network NAS EapolTimeout [<eapol_timeout>] Security Network NAS Agetime [<age_time>] Security Network NAS Holdtime [<hold_time>]...
Seite 114 8.2.3.1 Configuration Security/Network/NAS>Configuration ? Description: Show 802.1X configuration. Syntax: Security Network NAS Configuration [<port_list>] Parameters: <port_list> Port list or 'all', default: All ports 8.2.3.2 Mode Security/Network/NAS>Mode ? Description: Set or show the global NAS state. Syntax: Security Network NAS Mode [enable|disable] Parameters: enable Globally enable 802.1X...
Seite 115 8.2.3.3 State Security/Network/NAS>State ? Description: Set or show the port security state. Syntax: Security Network NAS State [<port_list>] [auto|authorized|unauthorized|single|multi|macbased] Parameters: <port_list> Port list or 'all', default: All ports auto Port-based 802.1X Authentication authorized Port access is allowed unauthorized Port access is not allowed single Single Host 802.1X Authentication multi...
Seite 116 Parameters: enable Enable reauthentication disable Disable reauthentication (default: Show current reauthentication mode) 8.2.3.5 ReauthPeriod Security/Network/NAS>ReauthPeriod ? Description: Set or show the period between reauthentication attempts. Syntax: Security Network NAS ReauthPeriod [<reauth_period>] Parameters: <reauth_period> Period between reauthentication attempts (1-3600 seconds) (default: Show current reauthentication period) 8.2.3.6 EapolTimeout Security/Network/NAS>EapolTimeout ?
Seite 117 8.2.3.7 Agetime Security/Network/NAS>Agetime ? Description: Time in seconds between check for activity on successfully authenticated MAC addresses. Syntax: Security Network NAS Agetime [<age_time>] Parameters: <age_time> Time between checks (10-1000000 seconds) (default: Show current age time) 8.2.3.8 Holdtime Security/Network/NAS>Holdtime ? Description: Time in seconds before a MAC-address that failed authentication gets a new authentication chance.
Seite 118 8.2.3.9 RADIUS_QoS Security/Network/NAS>RADIUS_QoS ? Description: Set or show either global state (use the global keyword) or per-port state of RADIUS-assigned QoS. Syntax: Security Network NAS RADIUS_QoS [global|<port_list>] [enable|disable] Parameters: global Select the global RADIUS-assigned QoS setting <port_list> Select the per-port RADIUS-assigned QoS setting (default: Show current per-port RADIUS-assigned QoS state) enable Enable RADIUS-assigned QoS either globally or on one or more ports...
Seite 119 8.2.3.10 RADIUS_VLAN Security/Network/NAS>RADIUS_VLAN ? Description: Set or show either global state (use the global keyword) or per-port state of RADIUS-assigned VLAN. Syntax: Security Network NAS RADIUS_VLAN [global|<port_list>] [enable|disable] Parameters: global : Select the global RADIUS-assigned VLAN setting <port_list>: Select the per-port RADIUS-assigned VLAN setting (default: Show current per-port RADIUS-assigned VLAN state) enable : Enable RADIUS-assigned VLAN either globally or on one or more ports disable: Disable RADIUS-assigned VLAN either globally or on one or more ports...
Seite 120 8.2.3.11 Guest_VLAN Security/Network/NAS>Guest_VLAN ? Description: Set or show either global state and parameters (use the global keyword) or per-port state of Guest VLAN Unless the 'global' keyword is used, the <reauth_max> and <allow_if_eapol_seen> parameters will not be unused.. Syntax: Security Network NAS Guest_VLAN [global|<port_list>] [enable|disable] [<vid>] [<reauth_max>] [<allow_if_eapol_seen>] Parameters:...
Seite 121 been received during the lifetime of the port (default: Show current setting) 8.2.3.12 Authenticate Security/Network/NAS>Authenticate ? Description: Refresh (restart) 802.1X authentication process. Syntax: Security Network NAS Authenticate [<port_list>] [now] Parameters: <port_list> Port list or 'all', default: All ports Force reauthentication immediately (default: Schedule a reauthentication) 8.2.3.13 Statistics Security/Network/NAS>Statistics ?
Seite 122: Network Acl
8.2.4 Network ACL Available Commands: Security Network ACL Configuration [<port_list>] Security Network ACL Action [<port_list>] [permit|deny] [<rate_limiter>] [<port_redirect>] [<mirror>] [<logging>] [<shutdown>] Security Network ACL Policy [<port_list>] [<policy>] Security Network ACL Rate [<rate_limiter_list>] [<rate_unit>] [<rate>] Security Network ACL Add [<ace_id>] [<ace_id_next>] [(port <port_list>)] [(policy <policy>...
Seite 123 8.2.4.1 Configuration Security/Network/ACL>Configuration ? Description: Show ACL Configuration. Syntax: Security Network ACL Configuration [<port_list>] Parameters: <port_list> Port list or 'all', default: All ports 8.2.4.2 Action Security/Network/ACL>Action ? Description: Set or show the ACL port default action. Syntax: Security Network ACL Action [<port_list>] [permit|deny] [<rate_limiter>] [<port_redirect>] [<mirror>] [<logging>] [<shutdown>] Parameters: <port_list>...
Seite 124 <logging> System logging of frames: log|log_disable <shutdown> Shut down ingress port: shut|shut_disable 8.2.4.3 Policy Security/Network/ACL>Policy ? Description: Set or show the ACL port policy. Syntax: Security Network ACL Policy [<port_list>] [<policy>] Parameters: <port_list> Port list or 'all', default: All ports <policy>...
Seite 125 8.2.4.5 Add Security/Network/ACL>Add ? Description: Add or modify Access Control Entry (ACE). If the ACE ID parameter <ace_id> is specified and an entry with this ACE ID already exists, the ACE will be modified. Otherwise, a new ACE will be added. If the ACE ID is not specified, the next available ACE ID will be used.
Seite 126 Parameters: <ace_id> ACE ID (1-256), default: Next available ID <ace_id_next> Next ACE ID (1-256), default: Add ACE last port Port ACE keyword <port_list> Port list or 'all', default: All ports policy Policy ACE keyword <policy> Policy number (0-255) <policy_bitmask> Policy number bitmask (0x0-0xFF) <tagged>...
Seite 127 deny Deny forwarding <rate_limiter> Rate limiter number (1-15) or 'disable' <port_redirect> Port list for copy of frames or 'disable' <mirror> Mirror of frames: enable|disable <logging> System logging of frames: log|log_disable <shutdown> Shut down ingress port: shut|shut_disable 8.2.4.6 Delete Security/Network/ACL>Delete ? Description: Delete ACE.
Seite 128 8.2.4.8 Clear Security/Network/ACL>Clear ? Description: Clear all ACL counters. Syntax: Security Network ACL Clear 8.2.4.9 Status Security/Network/ACL>Status ? Description: Show ACL status. Syntax: Security Network ACL Status [combined|static|loop_protect|dhcp|upnp|arp_inspection|ipmc|ip_source_guard|conflicts] Parameters: combined Show combined status static Show static user configured status loop_protect Shows the status by Loop Protect dhcp...
Seite 129: Network Acl
ip_source_guard Show IP Source Guard status conflicts Show conflict status (default : Show combined status) 8.2.4.10 Port State Security/Network/ACL>Port State ? Description: Set or show the ACL port state. Syntax: Security Network ACL Port State [<port_list>] [enable|disable] Parameters: <port_list> Port list or 'all', default: All ports enable|disable: ACL port state 8.2.5 Network ACL...
Seite 130: Relay Mode
8.2.5.1 Relay Configuration Security/Network/DHCP>Relay Configuration ? Description: Show DHCP relay configuration. Syntax: Security Network DHCP Relay Configuration 8.2.5.2 Relay Mode Security/Network/DHCP>Relay Mode ? Description: Set or show the DHCP relay mode. Syntax: Security Network DHCP Relay Mode [enable|disable] Parameters: enable Enable DHCP relaly mode.
Seite 131 8.2.5.3 Relay Server Security/Network/DHCP>Relay Server ? Description: Show or set DHCP relay server. Syntax: Security Network DHCP Relay Server [<ip_addr>] Parameters: <ip_addr> IP address (a.b.c.d), default: Show IP address 8.2.5.4 Relay Information Mode Security/Network/DHCP>Relay Information Mode ? Description: Set or show DHCP relay agent information option mode. When enable DHCP relay information mode operation, the agent insert specific information (option 82) into a DHCP message when forwarding to DHCP server and remote it from...
Seite 132 (default: Show DHCP relay agent information option mode) 8.2.5.5 Relay Information Policy Security/Network/DHCP>Relay Information Policy ? Description: Set or show the DHCP relay mode. When enable DHCP relay information mode operation, if agent receive a DHCP message that already contains relay agent information.
Seite 133 Parameters: clear Clear DHCP relay statistics 8.2.5.7 Snooping Configuration Security/Network/DHCP>Snooping Configuration ? Description: Show DHCP snooping configuration. Syntax: Security Network DHCP Snooping Configuration 8.2.5.8 Snooping Mode Security/Network/DHCP>Snooping Mode ? Description: Set or show the DHCP snooping mode. Syntax: Security Network DHCP Snooping Mode [enable|disable] Parameters: Enable Enable DHCP snooping mode.
Seite 134 8.2.5.9 Snooping Port Mode Security/Network/DHCP>Snooping Port Mode ? Description: Set or show the DHCP snooping port mode. Syntax: Security Network DHCP Snooping Port Mode [<port_list>] [trusted|untrusted] Parameters: <port_list> Port list or 'all', default: All ports Trusted Configures the port as trusted sources of the DHCP message untrusted Configures the port as untrusted sources of the DHCP message (default: Show flow DHCP snooping port mode)
Seite 135: Network Ip
8.2.6 Network IP Available Commands: Security Network IP Source Guard Configuration Security Network IP Source Guard Mode [enable|disable] Security Network IP Source Guard Port Mode [<port_list>] [enable|disable] Security Network IP Source Guard limit [<port_list>] [<dynamic_entry_limit>|unlimited] Security Network IP Source Guard Entry [<port_list>] add|delete <vid>...
Seite 136 Security Network IP Source Guard Configuration 8.2.6.2 Source Guard Mode Security/Network/IP>Source Guard Mode ? Description: Set or show IP source guard mode. Syntax: Security Network IP Source Guard Mode [enable|disable] Parameters: Enable Enable IP Source Guard disable Disable IP Source Guard 8.2.6.3 Source Guard Port Mode Security/Network/IP>Source Guard Port Mode ? Description:...
Seite 137 8.2.6.4 Source Guard Limit Security/Network/IP>Source Guard Limit ? Description: Set or show the IP Source Guard port limitation for dynamic entries. Syntax: Security Network IP Source Guard limit [<port_list>] [<dynamic_entry_limit>|unlimited] Parameters: <port_list> Port list or 'all', default: All ports <dynamic_entry_limit>|unlimited dynamic entry limit (0-2) or unlimited 8.2.6.5 Source Guard Entry...
Seite 138 <allowed_ip> IPv4 address (a.b.c.d), IP address allowed for doing IP source guard <allowed_mac> MAC address ('xx-xx-xx-xx-xx-xx' or 'xx.xx.xx.xx.xx.xx' or 'xxxxxxxxxxxx', x is a hexadecimal digit), MAC address allowed for doing IP source guard 8.2.6.6 Source Guard Status Security/Network/IP>Source Guard Status ? Description: Show IP source guard static and dynamic entries.
Seite 139: Network Arp
8.2.7 Network ARP Available Commands: Security Network ARP Inspection Configuration Security Network ARP Inspection Mode [enable|disable] Security Network ARP Inspection Port Mode [<port_list>] [enable|disable] Security Network ARP Inspection Entry [<port_list>] add|delete <vid> <allowed_mac> <allowed_ip> Security Network ARP Inspection Status [<port_list>] Security Network ARP Inspection Translation 8.2.7.1 Inspection Configuration Security/Network/ARP>Inspection Configuration ?
Seite 140 Security Network ARP Inspection Configuration 8.2.7.2 Inspection Mode Security/Network/ARP>Inspection Mode ? Description: Set or show ARP inspection mode. Syntax: Security Network ARP Inspection Mode [enable|disable] Parameters: enable Enable ARP Inspection disable Disable ARP Inspection 8.2.7.3 Inspection Port Mode Security/Network/ARP>Inspection Port Mode ? Description: Set or show the ARP Inspection port mode.
Seite 141 8.2.7.4 Inspection Entry Security/Network/ARP>Inspection Entry ? Description: Add or delete ARP inspection static entry. Syntax: Security Network ARP Inspection Entry [<port_list>] add|delete <vid> <allowed_mac> <allowed_ip> Parameters: <port_list> Port list or 'all', default: All ports Add new port ARP inspection static entry delete Delete existing port ARP inspection static entry <vid>...
Seite 142: Aaa
Parameters: <port_list>: Port list or 'all', default: All ports 8.2.7.6 Inspection Translation Security/Network/ARP>Inspection Translation ? Description: Translate ARP inspection dynamic entries into static entries. Syntax: Security Network ARP Inspection Translation 8.3 AAA Available Commands: Security AAA Configuration Security AAA Timeout [<timeout>] Security AAA Deadtime [<dead_time>] Security AAA RADIUS [<server_index>] [enable|disable] [<ip_addr_string>] [<secret>] [<server_port>]...
Seite 143: Configuration
Security AAA TACACS+ [<server_index>] [enable|disable] [<ip_addr_string>] [<secret>] [<server_port>] Security AAA Statistics [<server_index>] 8.3.1 Configuration Security/AAA>Configuration ? Description: Show Auth configuration. Syntax: Security AAA Configuration 8.3.2 Timeout Security/AAA>Timeout ? Description: Set or show server timeout. Syntax: Security AAA Timeout [<timeout>] Parameters: <timeout>...
Seite 144: Deadtime
8.3.3 Deadtime Security/AAA>Deadtime ? Description: Set or show server dead time. Syntax: Security AAA Deadtime [<dead_time>] Parameters: <dead_time> Time that a server is considered dead if it doesn't answer a request (0-3600 seconds) (default: Show server dead time configuration) 8.3.4 RADIUS Security/AAA>RADIUS ? Description:...
Seite 145: Acct_Radius
<secret> Secret shared with external authentication server. To use spaces in secret, enquote the secret. Quotes in the secret are not allowed. <server_port> Server UDP port. Use 0 to use the default RADIUS port (1812) 8.3.5 ACCT_RADIUS Security/AAA>ACCT_RADIUS ? Description: Set or show RADIUS accounting server setup.
Seite 146: Tacacs
8.3.6 TACACS+ Security/AAA>TACACS+ ? Description: Set or show TACACS+ authentication server setup. Syntax: Security AAA TACACS+ [<server_index>] [enable|disable] [<ip_addr_string>] [<secret>] [<server_port>] Parameters: The server index (1-5) (default: Show TACACS+ authentication server configuration) enable Enable TACACS+ authentication server disable Disable TACACS+ authentication server (default: Show TACACS+ server mode) <ip_addr_string>...
Seite 147: Stp
Parameters: The server index (1-5) (default: Show statistics for all servers) Chapter 9 9.STP Available Commands: STP Configuration STP Version [<stp_version>] STP Txhold [<holdcount>] STP MaxHops [<maxhops>] STP MaxAge [<max_age>] STP FwdDelay [<delay>] STP CName [<config-name>] [<integer>] STP bpduFilter [enable|disable] STP bpduGuard [enable|disable] STP recovery [<timeout>]...
Seite 148: Configuration
STP Port RestrictedTcn [<stp_port_list>] [enable|disable] STP Port bpduGuard [<stp_port_list>] [enable|disable] STP Port Statistics [<stp_port_list>] [clear] STP Port Mcheck [<stp_port_list>] STP Msti Port Configuration [<msti>] [<stp_port_list>] STP Msti Port Cost [<msti>] [<stp_port_list>] [<path_cost>] STP Msti Port Priority [<msti>] [<stp_port_list>] [<priority>] 9.1 Configuration STP>Configuration ? Description:...
Seite 149: Maxhops
Description: Set or show the STP Bridge Transmit Hold Count parameter. Syntax: STP Txhold [<holdcount>] Parameters: <holdcount>: STP Transmit Hold Count (1-10) 9.4 MaxHops STP>MaxHops ? Description: Set or show the MSTP Bridge Max Hop Count parameter. Syntax: STP MaxHops [<maxhops>] Parameters: <maxhops>...
Seite 150: Fwddelay
<max_age>: STP maximum age time (6-40, and max_age <= (forward_delay-1)*2) 9.6 FwdDelay STP>FwdDelay ? Description: Set or show the bridge instance forward delay. Syntax: STP FwdDelay [<delay>] Parameters: <delay> MSTP forward delay (4-30, and max_age <= (forward_delay-1)*2)) 9.7 CName STP>CName ? Description: Set or Show MSTP configuration name and revision.
Seite 151: Bpdufilter
9.8 bpduFilter STP>bpduFilter ? Description: Set or show edge port BPDU Filtering. Syntax: STP bpduFilter [enable|disable] Parameters: enable|disable enable or disable BPDU Filtering for Edge ports 9.9 bpduGuard STP>bpduGuard ? Description: Set or show edge port BPDU Guard. Syntax: STP bpduGuard [enable|disable] Parameters: enable|disable...
Seite 152: Recovery
9.10 recovery STP>recovery ? Description: Set or show edge port error recovery timeout. Syntax: STP recovery [<timeout>] Parameters: <timeout>: Time before error-disabled ports are reenabled (30-86400 seconds, 0 disables) (default: Show recovery timeout) 9.11 Status STP>Status ? Description: Show STP Bridge status. Syntax: STP Status [<msti>] [<stp_port_list>] Parameters:...
Seite 153: Msti Priority
9.12 Msti Priority STP>Msti Priority ? Description: Set or show the bridge instance priority. Syntax: STP Msti Priority [<msti>] [<priority>] Parameters: <msti> STP bridge instance no (0-7, CIST=0, MSTI1=1, ...) <priority> STP bridge priority (0/4096/8192/12288/.../53248/57344/61440) 9.13 Msti Map STP>MSti Map ? Description: Show or clear MSTP MSTI VLAN mapping configuration.
Seite 154: Msti Add
9.14 Msti Add STP>Msti Add ? Description: Add a VLAN (single or range) to a MSTI. Syntax: STP Msti Add <msti> <vid-range> Parameters: <msti> STP bridge instance no (0-7, CIST=0, MSTI1=1, ...) <vid-range> Single VLAN ID (1-4094) or 'xx-yy' VLAN ID range 9.15 Port Configuration STP>Port Configuration ? Description:...
Seite 155: Port Mode
9.16 Port Mode STP>Port Mode ? Description: Set or show the STP enabling for a port. Syntax: STP Port Mode [<stp_port_list>] [enable|disable] Parameters: <stp_port_list> Port list or 'all'. Port zero means aggregations. enable Enable MSTP protocol disable Disable MSTP protocol 9.17 Port Edge STP>Port Edge ? Description:...
Seite 156: Port Autoedge
9.18 Port AutoEdge STP>Port AutoEdge ? Description: Set or show the STP autoEdge port parameter. Syntax: STP Port AutoEdge [<stp_port_list>] [enable|disable] Parameters: <stp_port_list> Port list or 'all'. Port zero means aggregations. enable Enable MSTP autoEdge disable Disable MSTP autoEdge 9.19 Port P2P STP>Port P2P ? Description:...
Seite 157: Port Restrictedrole
9.20 Port RestrictedRole STP>Port RestrictedRole ? Description: Set or show the MSTP restrictedRole port parameter. Syntax: STP Port RestrictedRole [<stp_port_list>] [enable|disable] Parameters: <stp_port_list> Port list or 'all'. Port zero means aggregations. enable Enable MSTP restricted role disable Disable MSTP restricted role 9.21 Port RestrictedTcn STP>Port RestrictedTcn ? Description:...
Seite 158: Bpduguard
9.22 bpduGuard STP>bpduGuard ? Description: Set or show edge port BPDU Guard. Syntax: STP bpduGuard [enable|disable] Parameters: enable|disable enable or disable BPDU Guard for Edge ports 9.23 Port Statistics STP>Port Statistics ? Description: Show STP port statistics. Syntax: STP Port Statistics [<stp_port_list>] [clear] Parameters: <stp_port_list>...
Seite 159: Port Mcheck
9.24 Port Mcheck STP>Port Mcheck ? Description: Set the STP mCheck (Migration Check) variable for ports. Syntax: STP Port Mcheck [<stp_port_list>] Parameters: <stp_port_list>: Port list or 'all'. Port zero means aggregations. 9.25 Msti Port Configuration STP>Msti Port Configuration ? Description: Show the STP port instance configuration.
Seite 160: Msti Port Cost
9.26 Msti Port Cost STP>Msti Port Cost ? Description: Set or show the STP port instance path cost. Syntax: STP Msti Port Cost [<msti>] [<stp_port_list>] [<path_cost>] Parameters: <msti> STP bridge instance no (0-7, CIST=0, MSTI1=1, ...) <stp_port_list> Port list or 'all'. Port zero means aggregations. <path_cost>...
Seite 161: Aggregation
Chapter 10 AGGREGATION 10.AGGREGATION Available Commands: Aggr Configuration Aggr Add <port_list> [<aggr_id>] Aggr Delete <aggr_id> Aggr Lookup [<aggr_id>] Aggr Mode [smac|dmac|ip|port] [enable|disable] Instruction Manual 161 ...
Seite 162: Configuration
10.1 Configuration Aggr>Configuration ? Description: Show link aggregation configuration. Syntax: Aggr Configuration 10.2 Add Aggr>Add ? Description: Add or modify link aggregation. Syntax: Aggr Add <port_list> [<aggr_id>] Parameters: <port_list> Port list or 'all', default: All ports <aggr_id> Aggregation ID: 1-5 ...
Seite 163: Lookup
10.3 Delete Aggr>Delete ? Description: Delete link aggregation. Syntax: Aggr Delete <aggr_id> Parameters: <aggr_id>: Aggregation ID: 1-5 10.4 Lookup Aggr>Lookup ? Description: Lookup link aggregation. Syntax: Aggr Lookup [<aggr_id>] Parameters: <aggr_id>: Aggregation ID: 1-5 Instruction Manual 163 ...
Seite 164: Mode
10.5 Mode Aggr>Mode ? Description: Set or show the link aggregation traffic distribution mode. Syntax: Aggr Mode [smac|dmac|ip|port] [enable|disable] Parameters: smac Source MAC address dmac Destination MAC address Source and destination IP address port Source and destination UDP/TCP port enable Enable field in traffic distribution disable...
Seite 165: Lacp
Chapter 11 LACP 11.LACP Available Commands: LACP Configuration [<port_list>] LACP Mode [<port_list>] [enable|disable] LACP Key [<port_list>] [<key>] LACP Prio [<port_list>] [<prio>] LACP System Prio [<sysprio>] LACP Role [<port_list>] [active|passive] LACP Status [<port_list>] LACP Statistics [<port_list>] [clear] LACP Timeout [<port_list>] [fast|slow] ...
Seite 166: Configuration
11.1 Configuration LACP>Configuration ? Description: Show LACP configuration. Syntax: LACP Configuration [<port_list>] Parameters: <port_list> Port list or 'all', default: All ports 11.2 Mode LACP>Mode ? Description: Set or show LACP mode. Syntax: LACP Mode [<port_list>] [enable|disable] Parameters: <port_list> Port list or 'all', default: All ports enable Enable LACP protocol disable...
Seite 167: Key
11.3 Key LACP>Key ? Description: Set or show the LACP key. Syntax: LACP Key [<port_list>] [<key>] Parameters: <port_list> Port list or 'all', default: All ports <key> LACP key (1-65535) or 'auto' 11.4 Prio LACP>Prio ? Description: Set or show the LACP prio. Syntax: LACP Prio [<port_list>] [<prio>] Parameters:...
Seite 168: System Prio
11.5 System Prio LACP>System Prio ? Description: Set or show the LACP System prio. Syntax: LACP System Prio [<sysprio>] Parameters: <sysprio> LACP System Prio (0-65535) 11.6 Role LACP>Role ? Description: Set or show the LACP role. Syntax: LACP Role [<port_list>] [active|passive] Parameters: <port_list>...
Seite 169: Status
11.7 Status LACP>Status ? Description: Show LACP Status. Syntax: LACP Status [<port_list>] Parameters: <port_list> Port list or 'all', default: All ports 11.8 Statistics LACP>Statistics ? Description: Show LACP Statistics. Syntax: LACP Statistics [<port_list>] [clear] Parameters: <port_list> Port list or 'all', default: All ports clear Clear LACP statistics ...
Seite 170: Timeout
11.9 Timeout LACP>Timeout ? Description: Set or show the LACP timeout. Syntax: LACP Timeout [<port_list>] [fast|slow] Parameters: <port_list> Port list or 'all', default: All ports fast Fast PDU transmissions (fast timeout) slow Slow PDU transmissions (slow timeout) (default: Show LACP timeout) ...
Seite 171: Lldp
Chapter 12 LLDP 12.LLDP Available Commands: LLDP Configuration [<port_list>] LLDP Mode [<port_list>] [enable|disable|rx|tx] LLDP Optional_TLV [<port_list>] [port_descr|sys_name|sys_descr|sys_capa|mgmt_addr] [enable|disable] LLDP Interval [<interval>] LLDP Hold [<hold>] LLDP Delay [<delay>] LLDP Reinit [<reinit>] LLDP Statistics [<port_list>] [clear] LLDP Info [<port_list>] LLDP cdp_aware [<port_list>] [enable|disable] ...
Seite 172: Configuration
12.1 Configuration LLDP>Configuration ? Description: Show LLDP configuration. Syntax: LLDP Configuration [<port_list>] Parameters: <port_list> Port list or 'all', default: All ports 12.2 Mode LLDP>Mode ? Description: Set or show LLDP mode. Syntax: LLDP Mode [<port_list>] [enable|disable|rx|tx] Parameters: <port_list> Port list or 'all', default: All ports enable Enable LLDP reception and transmission disable...
Seite 173: Interval
12.3 Optional_TLV LLDP>Optional_TLV ? Description: Set or show LLDP Optional TLVs. Syntax: LLDP Optional_TLV [<port_list>] [port_descr|sys_name|sys_descr|sys_capa|mgmt_addr] [enable|disable] Parameters: <port_list> Port list or 'all', default: All ports port_descr Description of the port sysm_name System name sys_descr Description of the system sys_capa System capabilities mgmt_addr...
Seite 174: Hold
LLDP Interval [<interval>] Parameters: <interval> LLDP transmission interval (5-32768) 12.5 Hold LLDP>Hold ? Description: Set or show LLDP Tx hold value. Syntax: LLDP Hold [<hold>] Parameters: <hold> LLDP hold value (2-10) 12.6 Delay LLDP>Delay ? Description: Set or show LLDP Tx delay. Syntax: LLDP Delay [<delay>] Parameters:...
Seite 175: Reinit
12.7 Reinit LLDP>Reinit ? Description: Set or show LLDP reinit delay. Syntax: LLDP Reinit [<reinit>] Parameters: <reinit>: LLDP reinit delay (1-10) 12.8 Statistics LLDP>Statistics ? Description: Show LLDP Statistics. Syntax: LLDP Statistics [<port_list>] [clear] Parameters: <port_list> Port list or 'all', default: All ports clear Clear LLDP statistics ...
Seite 176: Info
12.9 Info LLDP>Info ? Description: Show LLDP neighbor device information. Syntax: LLDP Info [<port_list>] Parameters: <port_list> Port list or 'all', default: All ports 12.10 cdp_aware LLDP>cdp_aware ? Description: Set or show if discovery information from received CDP ( Cisco Discovery Protocol ) frames is added to the LLDP neighbor table.
Seite 177: Lldpmed
Chapter 13 LLDPMED 13.LLDPMED Available Commands: LLDPMED Configuration [<port_list>] LLDPMED Civic [country|state|county|city|district|block|street|leading_street_direction|trailing_street_suffix|st r_suf|house_no|house_no_suffix|landmark|additional_info|name|zip_code|building|apartme nt|floor|room_number|place_type|postal_com_name|p_o_box|additional_code] [<civic_value>] LLDPMED ecs [<ecs_value>] LLDPMED policy delete <policy_list> LLDPMED policy add <policy_type> [tagged|untagged] [<vlan_id>] [<l2_priority>] [<dscp>] LLDPMED port policies [<port_list>] [<policy_list>] LLDPMED Coordinates [<tude_type>] [<direction>] [coordinate_value] LLDPMED Datum [<datum_type>] LLDPMED Fast [<count>] LLDPMED Info [<port_list>]...
Seite 178: Configuration
13.1 Configuration LLDPMED>Configuration ? Description: Show LLDP-MED configuration. Syntax: LLDPMED Configuration [<port_list>] Parameters: <port_list> Port list or 'all', default: All ports Instruction Manual 178 ...
Seite 179: Civic
13.2 Civic LLDPMED>Civic ? Description: Set or show LLDP-MED Civic Address Location. Syntax: LLDPMED Civic [country|state|county|city|district|block|street|leading_street_direction|trailing_street_suffix|st r_suf|house_no|house_no_suffix|landmark|additional_info|name|zip_code|building|apartme nt|floor|room_number|place_type|postal_com_name|p_o_box|additional_code] [<civic_value>] Parameters: country Country state National subdivisions (state, caton, region, province, prefecture) county County, parish,gun (JP), district(IN) city City, townchip, shi (JP) district City division,borough, city, district, ward,chou (JP) block...
Seite 180: Ecs
floor Floor room_number Room number place_type Placetype postal_com_name Postal community name p_o_box Post office box (P.O. Box) additional_code Additional code (default: Show Civic Address Location configuration) <civic_value> lldpmed The value for the Civic Address Location entry. 13.3 ecs LLDPMED>ecs ? Description: Set or show LLDP-MED Emergency Call Service.
Seite 181: Policy Add
<policy_list> List of policies to delete 13.5 policy add LLDPMED>policy add ? Description: Adds a policy to the list of polices. Syntax: LLDPMED policy add <policy_type> [tagged|untagged] [<vlan_id>] [<l2_priority>] [<dscp>] Parameters: <policy_type> The policy_type parameter takes the following values: voice Voice for use by dedicated IP Telephony handsets and other similar appliances supporting interactive voice services.
Seite 182: Port Policies
equipment and other similar appliances supporting real-time interactive video/audio services. streaming_video Streaming Video for use by broadcast or multicast based video content distribution and other similar applications supporting streaming video services that require specific network policy treatment. Video applications relying on TCP with buffering would not be an intended use of this application type.
Seite 183: Coordinates
13.7 Coordinates LLDPMED>Coordinates ? Description: Set or show LLDP-MED Location. Syntax: LLDPMED Coordinates [<tude_type>] [<direction>] [coordinate_value] Parameters: <tude_type> The tude_type parameter takes the following values: latitude Latitude, 0 to 90 degrees with max. 4 digits (Positive numbers are north of the equator and negative numbers are south of the equator). Longitude Longitude, 0 to 180 degrees with max.
Seite 184: Datum
13.8 Datum LLDPMED>Datum ? Description: Set or show LLDP-MED Coordinates map datum. Syntax: LLDPMED Datum [<datum_type>] Parameters: <datum_type> The datum_type parameter takes the following values: wgs84 WGS84 nad83_navd88 NAD83_NAVD88 nad83_mllw NAD83_MLLW 13.9 Fast LLDPMED>Fast ? Description: Set or show LLDP-MED Fast Start Repeat Count. Syntax: LLDPMED Fast [<count>]...
Seite 185: Info
13.10 Info LLDPMED>Info ? Description: Show LLDP-MED neighbor device information. Syntax: LLDPMED Info [<port_list>] Parameters: <port_list> Port list or 'all', default: All ports Instruction Manual 185 ...
Seite 186: Eee
Chapter 14 14.EEE Available Commands: EEE Configuration [<port_list>] EEE Mode [<port_list>] [enable|disable] EEE Urgent_queues [<port_list>] [<queue_list>] Instruction Manual 186 ...
Seite 187: Configuration
14.1 Configuration EEE>Configuration ? Description: Show EEE configuration. Syntax: EEE Configuration [<port_list>] Parameters: <port_list> Port list or 'all', default: All ports 14.2 Mode EEE>Mode ? Description: Set or show the EEE mode. Syntax: EEE Mode [<port_list>] [enable|disable] Parameters: <port_list> Port list or 'all', default: All ports enable Enable EEE...
Seite 188: Urgent_Queues
disable Disable EEE (default: Show eee mode) 14.3 Urgent_queues EEE>Urgent_queues ? Description: Set or show EEE Urgent queues. Syntax: EEE Urgent_queues [<port_list>] [<queue_list>] Parameters: <port_list> Port list or 'all', default: All ports <queue_list> List of queues to configure as urgent queues (1-8 or none) ...
Seite 189: Thermal
Chapter 15 THERMAL 15.THERMAL Available Commands: Thermal prio_temp [<prio_list>] [<shut_down_temp>] Thermal port_prio [<port_list>] [<prio>] Thermal status Thermal configuration 15.1 prio_temp Thermal>prio_temp ? Description: Set or show the temperature at which the ports shall be shut down. Syntax: Thermal prio_temp [<prio_list>] [<shut_down_temp>] ...
Seite 190: Port_Prio
Parameters: <prio_list> List of priorities (0-3) <shut_down_temp> Temperature at which ports shall be shut down (0-255 degree C) 15.2 port_prio Thermal>port_prio ? Description: Set or show the ports priority. Syntax: Thermal port_prio [<port_list>] [<prio>] Parameters: <port_list> Port list or 'all', default: All ports <prio>...
Seite 191: Led_Power
Description: Show thermal_protect configuration. Syntax: Thermal configuration Chapter 16 LED_POWER 16.LED_POWER Available Commands: led_power timers [<hour>] [<intensity>] led_power delete_timer <hour> led_power maintenance [<maintenance_time>] [on_at_errors|leave_at_errors] led_power configuration 16.1 timers led_power>timers ? Description: Instruction Manual 191 ...
Seite 192: Delete_Timer
Set or show the time and intensity for the LEDs. Syntax: led_power timers [<hour>] [<intensity>] Parameters: <hour> The hour (0-23) at which to change LEDs intensity <intensity> The LED intensity in % (0-100) 16.2 delete_timer led_power>delete_timer ? Description: Deletes a timer. Syntax: led_power delete_timer <hour>...
Seite 193: Configuration
<maintenance_time> Time in seconds (0-65535) that the LEDs shall be turned on, when any port changes link state on_at_errors|leave_at_errors on_at_error if LEDs shall be turned on if any errors has been detected. leave_at_errors if no LED change shall happen when errors have been detected 16.4 configuration led_power>configuration ? Description:...
Seite 194: Qos
Chapter 17 17.QoS Available Commands: QoS Configuration [<port_list>] QoS Port Classification Class [<port_list>] [<class>] QoS Port Classification DPL [<port_list>] [<dpl>] QoS Port Classification PCP [<port_list>] [<pcp>] QoS Port Classification DEI [<port_list>] [<dei>] QoS Port Classification Tag [<port_list>] [enable|disable] QoS Port Classification Map [<port_list>] [<pcp_list>] [<dei_list>] [<class>] [<dpl>] QoS Port Classification DSCP [<port_list>] [enable|disable] QoS Port Policer Mode [<port_list>] [enable|disable]...
Seite 195 QoS Port DSCP Translation [<port_list>] [enable|disable] QoS Port DSCP Classification [<port_list>] [none|zero|selected|all] QoS Port DSCP EgressRemark [<port_list>] [disable|enable|remap_dp_unaware|remap_dp_aware] QoS DSCP Map [<dscp_list>] [<class>] [<dpl>] QoS DSCP Translation [<dscp_list>] [<trans_dscp>] QoS DSCP Trust [<dscp_list>] [enable|disable] QoS DSCP Classification Mode [<dscp_list>] [enable|disable] QoS DSCP Classification Map [<class_list>] [<dpl_list>] [<dscp>] QoS DSCP EgressRemap [<dscp_list>] [<dpl_list>] [<dscp>] QoS Storm Unicast [enable|disable] [<packet_rate>]...
Seite 196: Configuration
17.1 Configuration QoS>Configuration ? Description: Show QoS Configuration. Syntax: QoS Configuration [<port_list>] Parameters: <port_list> Port list or 'all', default: All ports 17.2 Port Classification Class QoS>Port Classification Class ? Description: Set or show the default QoS class. If the QoS class has been dynamically changed, then the actual QoS class is shown in parentheses after the configured QoS class.
Seite 197: Port Classification Dpl
17.3 Port Classification DPL QoS>Port Classification DPL ? Description: Set or show the default Drop Precedence Level. Syntax: QoS Port Classification DPL [<port_list>] [<dpl>] Parameters: <port_list> Port list or 'all', default: All ports <dpl> Drop Precedence Level (0-1) 17.4 Port Classification PCP QoS>Port Classification PCP ? Description: Set or show the default PCP for an untagged frame.
Seite 198: Port Classification Dei
17.5 Port Classification DEI QoS>Port Classification DEI ? Description: Set or show the default DEI for an untagged frame. Syntax: QoS Port Classification DEI [<port_list>] [<dei>] Parameters: <port_list> Port list or 'all', default: All ports <dei> Drop Eligible Indicator (0-1) 17.6 Port Classification Tag QoS>Port Classification Tag ? Description:...
Seite 199: Port Classification Map
17.7 Port Classification Map QoS>Port Classification Map ? Description: Set or show the port classification map. This map is used when port classification tag is enabled, and the purpose is to translate the Priority Code Point (PCP) and Drop Eligible Indicator (DEI) from a tagged frame to QoS class and DP level.
Seite 200: Port Classification Dscp
17.8 Port Classification DSCP QoS>Port Classification DSCP ? Description: Set or show if the classification is based on DSCP value in IP frames. Syntax: QoS Port Classification DSCP [<port_list>] [enable|disable] Parameters: <port_list> Port list or 'all', default: All ports enable Enable DSCP based classification disable...
Seite 201: Port Policer Rate
(default: Show port policer mode) 17.10 Port Policer Rate QoS>Port Policer Rate ? Description: Set or show the port policer rate. Syntax: QoS Port Policer Rate [<port_list>] [<rate>] Parameters: <port_list> Port list or 'all', default: All ports <rate> Rate in kbps or fps (100-3300000) 17.11 Port Policer Unit QoS>Port Policer Unit ? Description:...
Seite 202: Port Policer Flowcontrol
kbps Unit is kilo bits per second Unit is frames per second (default: Show port policer unit) 17.12 Port Policer FlowControl QoS>Port Policer FlowControl ? Description: Set or show the port policer flow control. If policer flow control is enabled and the port is in flow control mode, then pause frames are sent instead of discarding frames.
Seite 203: Port Scheduler Weight
strict Strict mode weighted Weighted mode (default: Show port scheduler mode) 17.14 Port Scheduler Weight QoS>Port Scheduler Weight ? Description: Set or show the port scheduler weight. Syntax: QoS Port Scheduler Weight [<port_list>] [<queue_list>] [<weight>] Parameters: <port_list> Port list or 'all', default: All ports <queue_list>...
Seite 204: Port Shaper Rate
(default: Show port shaper mode) 17.16 Port Shaper Rate QoS>Port Shaper Rate ? Description: Set or show the port shaper rate. Syntax: QoS Port Shaper Rate [<port_list>] [<bit_rate>] Parameters: <port_list> Port list or 'all', default: All ports <bit_rate> Rate in kilo bits per second (100-3300000) 17.17 Port QueueShaper Mode QoS>Port QueueShaper Mode ? Description:...
Seite 205: Port Queueshaper Rate
17.18 Port QueueShaper Rate QoS>Port QueueShaper Rate ? Description: Set or show the port queue shaper rate. Syntax: QoS Port QueueShaper Rate [<port_list>] [<queue_list>] [<bit_rate>] Parameters: <port_list> Port list or 'all', default: All ports <queue_list> Queue list or 'all', default: All queues (0-7) <bit_rate>...
Seite 206: Port Tagremarking Mode
17.20 Port TagRemarking Mode QoS>Port TagRemarking Mode ? Description: Set or show the port tag remarking mode. Syntax: QoS Port TagRemarking Mode [<port_list>] [classified|default|mapped] Parameters: <port_list> Port list or 'all', default: All ports classified Use classified PCP/DEI values default Use default PCP/DEI values mapped Use mapped versions of QoS class and DP level...
Seite 207: Port Tagremarking Dei
17.22 Port TagRemarking DEI QoS>Port TagRemarking DEI ? Description: Set or show the default DEI. This value is used when port tag remarking mode is set to 'default'. Syntax: QoS Port TagRemarking DEI [<port_list>] [<dei>] Parameters: <port_list> Port list or 'all', default: All ports <dei>...
Seite 208: Port Dscp Translation
<dpl_list> DP level list or 'all', default: All DP levels (0-1) <pcp> Priority Code Point (0-7) <dei> Drop Eligible Indicator (0-1) 17.24 Port DSCP Translation QoS>Port DSCP Translation ? Description: Set or show DSCP ingress translation mode. If translation is enabled for a port, incoming frame DSCP value is translated and translated value is used for QoS classification.
Seite 209: Port Dscp Egressremark
<port_list> Port list or 'all', default: All ports none No DSCP ingress classification zero Classify DSCP if DSCP = 0 selected Classify DSCP for which class. mode is 'enable' Classify all DSCP (default: Show port DSCP ingress classification mode) 17.26 Port DSCP EgressRemark QoS>Port DSCP EgressRemark ? Description:...
Seite 210: Dscp Map
17.27 DSCP Map QoS>DSCP Map ? Description: Set or show DSCP mapping table. This table is used to map QoS class and DP level based on DSCP value. DSCP value used to map QoS class and DPL is either translated DSCP value or incoming frame DSCP value.
Seite 211: Dscp Trust
Parameters: <dscp_list> DSCP (0-63) list or 'all' (default: Show DSCP translation table) <trans_dscp> Translated DSCP: 0-63, BE, CS1-CS7, EF or AF11-AF43 17.29 DSCP Trust QoS>DSCP Trust ? Description: Set or show whether a specific DSCP value is trusted. Only frames with trusted DSCP values are mapped to a specific QoS class and DPL. Frames with untrusted DSCP values are treated as a non-IP frame.
Seite 212: Dscp Classification Mode
17.30 DSCP Classification Mode QoS>DSCP Classification Mode ? Description: Set or show DSCP ingress classification mode. If port DSCP classification is 'selected', DSCP will be classified based on QoS class and DP level only for DSCP value with classification mode 'enabled'.
Seite 213: Dscp Classification Map
17.31 DSCP Classification Map QoS>DSCP Classification Map ? Description: Set or show DSCP ingress classification table. This table is used to map DSCP from QoS class and DP level. The DSCP which needs to be classified depends on port DSCP classification and DSCP classification mode.
Seite 214: Storm Unicast
Parameters: <dscp_list> DSCP (0-63) list or 'all' <dpl_list> DP level list or 'all', default: All DP levels (0-1) <dscp> Egress remapped DSCP: 0-63, BE, CS1-CS7, EF or AF11-AF43 17.33 Storm Unicast QoS>Storm Unicast ? Description: Set or show the unicast storm rate limiter. The limiter will only affect flooded frames, i.e.
Seite 215: Storm Broadcast
Parameters: enable Enable multicast storm control disable Disable multicast storm control <packet_rate> Rate in fps (1, 2, 4, ..., 512, 1k, 2k, 4k, ..., 1024k) 17.35 Storm Broadcast QoS>Storm Broadcast ? Description: Set or show the broadcast storm rate limiter. The limiter will only affect flooded frames, i.e.
Seite 216 before this QCE in the list. If the next QCE ID is not specified and if it is a new entry added, the QCE will be placed last in the list. Otherwise if the next QCE ID is not specified and if existing QCE is modified, QCE will be in the same location in the list.
Seite 217: Qcl Delete
ipv4 IPv4 keyowrd <protocol> IP protocol number: (0-255, TCP or UDP) or 'any' <sip> Source IP address: (a.b.c.d/n) or 'any' <dscp> DSCP: (0-63,BE,CS1-CS7,EF or AF11-AF43) or 'any', specific or range <fragment> IPv4 frame fragmented: yes|no|any <sport> Source TCP/UDP port:(0-65535) or 'any', specific or port range <dport>...
Seite 218: Qcl Status
Syntax: QoS QCL Lookup [<qce_id>] Parameters: <qce_id>: QCE ID (1-256), default: Next available ID 17.39 QCL Status QoS>QCL Status ? Description: Show QCL status. This can be used to display if there is any conflict in QCE for differnet user types. Syntax: QoS QCL Status [combined|static|voice_vlan|conflicts] Parameters:...
Seite 219: Mirror
Resolve QCE conflict status. Same H/W resource is shared by multiple applications and it may not be available even before MAX QCE entry. So user can release the resource in use by other applications and use this command to acquire the resource. Syntax: QoS QCL Refresh Chapter 18...
Seite 220: Port
Mirror Configuration [<port_list>] Parameters: <port_list> Port list or 'all', default: All ports 18.2 Port Mirror>Port ? Description: Set or show the mirror port. Syntax: Mirror Port [<port>|disable] Parameters: <port>|disable Mirror port or 'disable', default: Show port 18.3 Port Mirror>Mode ? Description: Set or show the mirror mode.
Seite 221: Config
Chapter 19 CONFIG 19.CONFIG Available Commands: Config Save <ip_server> <file_name> Config Load <ip_server> <file_name> [check] 19.1 Save Config>Save ? Description: Save configuration to TFTP server. Syntax: Config Save <ip_server> <file_name> Parameters: <ip_server> TFTP server IPv4 address (a.b.c.d) <file_name>...
Seite 222: Load
19.2 Load Config>Load ? Description: Load configuration from TFTP server. Syntax: Config Load <ip_server> <file_name> [check] Parameters: <ip_server> TFTP server IPv4 address (a.b.c.d) <file_name> Configuration file name check Check configuration file only, default: Check and apply file Instruction Manual ...
Seite 223: Firmware
Chapter 20 FIRMWARE 20.FIRMWARE Available Commands: Firmware Load <ip_addr_string> <file_name> Firmware IPv6 Load <ipv6_server> <file_name> Firmware Information Firmware Swap 20.1 Load Firmware>Load ? Description: Load new firmware from TFTP server. Syntax: Instruction Manual 223 ...
Seite 224: Ipv6 Load
Firmware Load <ip_addr_string> <file_name> Parameters: <ip_addr_string> IP host address (a.b.c.d) or a host name string <file_name> Firmware file name 20.2 IPv6 Load Firmware>IPv6 LOad ? Description: Load new firmware from IPv6 TFTP server. Syntax: Firmware IPv6 Load <ipv6_server> <file_name> Parameters: <ipv6_server>...
Seite 225: Upnp
Activate the alternate firmware image.. Syntax: Firmware Swap Chapter 21 UPnP 21.UPnP Available Commands: UPnP Configuration UPnP Mode [enable|disable] UPnP TTL [<ttl>] UPnP AdvertisingDuration [<duration>] Instruction Manual 225 ...
Seite 226: Configuration
21.1 Configuration UPnP>Configuration ? Description: Show UPnP configuration. Syntax: UPnP Configuration 21.2 Mode UPnP>Mode ? Description: Set or show the UPnP mode. Syntax: UPnP Mode [enable|disable] Parameters: enable Enable UPnP disable Disable UPnP (default: Show UPnP mode) 21.3 TTL UPnP>TTL ? Description: Set or show the TTL value of the IP header in SSDP messages.
Seite 227: Advertisingduration
UPnP TTL [<ttl>] Parameters: <ttl> ttl range (1..255), default: Show UPnP TTL 21.4 AdvertisingDuration UPnP>AdvertisingDuration ? Description: Set or show UPnP Advertising Duration. Syntax: UPnP AdvertisingDuration [<duration>] Parameters: <duration> duration range (100..86400), default: Show UPnP duration range Instruction Manual ...
Seite 228: Mvr
Chapter 22 22.MVR Available Commands: MVR Configuration MVR Mode [enable|disable] MVR VLAN Setup [<mvid>] [add|del|upd] [(Name <mvr_name>)] MVR VLAN Mode [<vid>|<mvr_name>] [dynamic|compatible] MVR VLAN Port [<vid>|<mvr_name>] [<port_list>] [source|receiver|inactive] MVR VLAN LLQI [<vid>|<mvr_name>] [mvr_param_llqi] MVR VLAN Channel [<vid>|<mvr_name>] [add|del|upd] [channel] [channel_bound] [(Name <grp_name>)] MVR VLAN Priority [<vid>|<mvr_name>] [priority] [tagged|untagged] MVR Immediate Leave [<port_list>] [enable|disable]...
Seite 229: Configuration
22.1 Configuration MVR>Configuration ? Description: Show MVR configuration. Syntax: MVR Configuration 22.2 Mode MVR>Mode ? Description: Set or show system MVR mode. Syntax: MVR Mode [enable|disable] Parameters: enable : Enable MVR Mode disable : Disable MVR Mode (default: Show MVR mode) ...
Seite 230: Vlan Setup
22.3 VLAN Setup MVR>VLAN Setup ? Description: Set or show per MVR VLAN configuration. Syntax: MVR VLAN Setup [<mvid>] [add|del|upd] [(Name <mvr_name>)] Parameters: <mvid> MVR VLAN ID (1-4095) Add operation Delete operation Update operation name MVR Name keyword <mvr_name> MVR VLAN name (Maximum of 32 characters) 22.4 VLAN Mode MVR>VLAN Mode ?
Seite 231: Vlan Port
compatible Compatible MVR mode (default: Show MVR VLAN mode) 22.5 VLAN Port MVR>VLAN Port ? Description: Set or show per MVR VLAN port role. Syntax: MVR VLAN Port [<vid>|<mvr_name>] [<port_list>] [source|receiver|inactive] Parameters: <vid>|<mvr_name>: MVR VLAN ID (1-4095) or Name (Maximum of 32 characters) <port_list>...
Seite 232: Vlan Channel
Default Value (5) 0~31744 Last Listener Query Interval in tenths of seconds (default: Show MVR Interface Last Listener Query Interval 22.7 VLAN Channel MVR>VLAN Channel ? Description: Set or show per MVR VLAN channel. Syntax: MVR VLAN Channel [<vid>|<mvr_name>] [add|del|upd] [channel] [channel_bound] [(Name <grp_name>)] Parameters: <vid>|<mvr_name>...
Seite 233: Immediate Leave
Parameters: <vid>|<mvr_name> MVR VLAN ID (1-4095) or Name (Maximum of 32 characters) priority CoS priority value ranges from 0 ~ 7 tagged Tagged IGMP/MLD frames will be sent untagged Untagged IGMP/MLD frames will be sent 22.9 Immediate Leave MVR>Immediate Leave ? Description: Set or show MVR immediate leave per port.
Seite 234: Groups
<vid> VLAN ID (1-4095) clear Clear log 22.11 Groups MVR>Groups ? Description: Show MVR group addresses. Syntax: MVR Groups [<vid>] Parameters: <vid> VLAN ID (1-4095) 22.12 SFM MVR>SFM ? Description: Show SFM (including SSM) related information for MVR. Syntax: MVR SFM [<vid>] [<port_list>] Parameters: <vid>...
Seite 235: Voice Vlan
Chapter 23 VOICE VLAN 23.VOICE VLAN Available Commands: Voice VLAN Configuration Voice VLAN Mode [enable|disable] Voice VLAN ID [<vid>] Voice VLAN Agetime [<age_time>] Voice VLAN Traffic Class [<class>] Voice VLAN OUI Add <oui_addr> [<description>] Voice VLAN OUI Delete <oui_addr> Voice VLAN OUI Clear Voice VLAN OUI Lookup [<oui_addr>] Voice VLAN Port Mode [<port_list>] [disable|auto|force]...
Seite 236: Configuration
23.1 Configuration Voice/VLAN>Configuration ? Description: Show Voice VLAN configuration. Syntax: Voice VLAN Configuration 23.2 Mode Voice/VLAN>Mode ? Description: Set or show the Voice VLAN mode. We must disable MSTP feature before we enable Voice VLAN. It can avoid the conflict of ingress filter. Syntax: Voice VLAN Mode [enable|disable] Parameters:...
Seite 237: Agetime
23.3 ID Voice/VLAN>ID ? Description: Set or show Voice VLAN ID. Syntax: Voice VLAN ID [<vid>] Parameters: <vid>: VLAN ID (1-4095) 23.4 Agetime Voice/VLAN>Agetime ? Description: Set or show Voice VLAN age time. Syntax: Voice VLAN Agetime [<age_time>] Parameters: <age_time>...
Seite 238: Traffic Class
23.5 Traffic Class Voice/VLAN>Traffic Class ? Description: Set or show Voice VLAN ID. Syntax: Voice VLAN Traffic Class [<class>] Parameters: <class> Traffic class (0-7) 23.6 OUI Add Voice/VLAN>OUI Add ? Description: Add Voice VLAN OUI entry. Modify OUI table will restart auto detect OUI process. The maximum entry number is (16).
Seite 239: Oui Delete
23.7 OUI Delete Voice/VLAN>OUI Delete ? Description: Delete Voice VLAN OUI entry. Modify OUI table will restart auto detect OUI process. Syntax: Voice VLAN OUI Delete <oui_addr> Parameters: <oui_addr> OUI address (xx-xx-xx). The null OUI address isn't allowed 23.8 OUI Clear Voice/VLAN>OUI Clear ? Description: Clear Voice VLAN OUI entry.
Seite 240: Oui Lookup
23.9 OUI Lookup Voice/VLAN>OUI Lookup ? Description: Lookup Voice VLAN OUI entry. Syntax: Voice VLAN OUI Lookup [<oui_addr>] Parameters: <oui_addr> OUI address (xx-xx-xx), default: Show OUI address 23.10 Port Mode Voice/VLAN>Port Mode ? Description: Set or show the Voice VLAN port mode. When the port mode isn't disabled, we must disable MSTP feature before we enable Voice VLAN.
Seite 241: Security
force Forced join to Voice VLAN. (default: Show Voice VLAN port mode) 23.11 Security Voice/VLAN>Security ? Description: Set or show the Voice VLAN port security mode. When the function is enabled, all non-telephone MAC address in Voice VLAN will be blocked 10 seconds. Syntax: Voice VLAN Security [<port_list>] [enable|disable]...
Seite 242: Discovery Protocol
23.12 Discovery Protocol Voice/VLAN>Discovery Protocol ? Description: Set or show the Voice VLAN port discovery protocol mode. It only work under auto detect mode is enabled. We should enable LLDP feature before configure discovery protocol to 'LLDP' or 'Both'. Change discovery protocol to 'OUI' or 'LLDP' will restart auto detect process.
Seite 243: Loop Protect
Chapter 24 LOOP PROTECT 24.LOOP PROTECT Available Commands: Loop Protect Configuration Loop Protect Mode [enable|disable] Loop Protect Transmit [<transmit-time>] Loop Protect Shutdown [<shutdown-time>] Loop Protect Port Configuration [<port_list>] Loop Protect Port Mode [<port_list>] [enable|disable] Loop Protect Port Action [<port_list>] [shutdown|shut_log|log] Loop Protect Port Transmit [<port_list>] [enable|disable] Loop Protect Status [<port_list>] ...
Seite 244: Configuration
24.1 Configuration Loop/Protect>Configuration ? Description: Show Loop Protection configuration. Syntax: Loop Protect Configuration 24.2 Mode Loop/Protect>Mode ? Description: Set or show the Loop Protection mode. Syntax: Loop Protect Mode [enable|disable] Parameters: enable Enable Loop Protection disable Disable Loop Protection ...
Seite 245: Transmit
24.3 Transmit Loop/Protect>Transmit ? Description: Set or show the Loop Protection transmit interval. Syntax: Loop Protect Transmit [<transmit-time>] Parameters: Transmit time interval (1-10 seconds) 24.4 Shutdown Loop/Protect>Shutdown ? Description: Set or show the Loop Protection shutdown time. Syntax: Loop Protect Shutdown [<shutdown-time>] Parameters: Shutdown time interval (0-604800 seconds) A value of zero disables re-enabling the port...
Seite 246: Port Configuration
24.5 Port Configuration Loop/Protect>Port Configuration ? Description: Show Loop Protection port configuration. Syntax: Loop Protect Port Configuration [<port_list>] Parameters: <port_list> Port list or 'all', default: All ports 24.6 Port Mode Loop/Protect>Port Mode ? Description: Set or show the Loop Protection port mode. Syntax: Loop Protect Port Mode [<port_list>] [enable|disable] Parameters:...
Seite 247: Port Action
24.7 Port Action Loop/Protect>Port Action ? Description: Set or show the Loop Protection port action. Syntax: Loop Protect Port Action [<port_list>] [shutdown|shut_log|log] Parameters: <port_list> Port list or 'all', default: All ports shutdown Shutdown the port shut_log Shutdown the port and Log event (Only) Log the event 24.8 Port Transmit Loop/Protect>Port Transmit ?
Seite 248: Status
24.9 Status Loop/Protect>Status ? Description: Show the Loop Protection status. Syntax: Loop Protect Status [<port_list>] Parameters: <port_list> Port list or 'all', default: All ports Instruction Manual 248 ...
Seite 249: Ipmc
Chapter 25 IPMC 25.IPMC Available Commands: IPMC Configuration [mld|igmp] IPMC Mode [mld|igmp] [enable|disable] IPMC Flooding [mld|igmp] [enable|disable] IPMC Leave Proxy [mld|igmp] [enable|disable] IPMC Proxy [mld|igmp] [enable|disable] IPMC SSM [mld|igmp] [(Range <prefix> <mask_len>)] IPMC VLAN Add [mld|igmp] <vid> IPMC VLAN Delete [mld|igmp] <vid>...
Seite 250: Configuration
25.1 Configuration IPMC>Configuration ? Description: Show IPMC snooping configuration. Syntax: IPMC Configuration [mld|igmp] Parameters: mld|igmp: IPMC for IPv6 MLD igmp IPMC for IPv4 IGMP 25.2 Mode IPMC>Mode ? Description: Set or show the IPMC snooping mode. Syntax: IPMC Mode [mld|igmp] [enable|disable] Parameters: mld|igmp: IPMC for IPv6 MLD...
Seite 251: Flooding
disable Disable IPMC snooping (default: Show global IPMC snooping mode) 25.3 Flooding IPMC>Flooding ? Description: Set or show the IPMC unregistered addresses flooding operation. Syntax: IPMC Flooding [mld|igmp] [enable|disable] Parameters: mld|igmp: IPMC for IPv6 MLD igmp IPMC for IPv4 IGMP enable Enable IPMC flooding disable...
Seite 252: Proxy
igmp IPMC for IPv4 IGMP enable Enable IPMC Leave Proxy disable Disable IPMC Leave Proxy (default: Show IPMC Leave Proxy mode) 25.5 Proxy IPMC>Proxy ? Description: Set or show the mode of IPMC Proxy. Syntax: IPMC Proxy [mld|igmp] [enable|disable] Parameters: mld|igmp: IPMC for IPv6 MLD...
Seite 253: Ssm
25.6 SSM IPMC>SSM ? Description: Set or show the IPMC SSM Range. Syntax: IPMC SSM [mld|igmp] [(Range <prefix> <mask_len>)] Parameters: mld|igmp : IPMC for IPv6 MLD igmp IPMC for IPv4 IGMP range SSM Range keyword <prefix> IPv4/IPv6 multicast group address, accordingly <mask_len>...
Seite 254: Vlan Delete
IPMC for IPv6 MLD igmp IPMC for IPv4 IGMP <vid> VLAN ID (1-4095) 25.8 VLAN Delete IPMC>VLAN Delete ? Description: Delete the IPMC snooping VLAN interface. Syntax: IPMC VLAN Delete [mld|igmp] <vid> Parameters: mld|igmp: IPMC for IPv6 MLD igmp IPMC for IPv4 IGMP <vid>...
Seite 255: Querier
<vid> VLAN ID (1-4095) or 'any', default: Show all VLANs enable Enable MLD snooping disable Disable MLD snooping 25.10 Querier IPMC>Querier ? Description: Set or show the IPMC snooping querier mode for VLAN. Syntax: IPMC Querier [mld|igmp] [<vid>] [enable|disable] Parameters: mld|igmp: IPMC for IPv6 MLD...
Seite 256: Compatibility
25.11 Compatibility IPMC>Compatibility ? Description: Set or show the IPMC Compatibility. Syntax: IPMC Compatibility [mld|igmp] [<vid>] [auto|v1|v2|v3] Parameters: mld|igmp : IPMC for IPv6 MLD igmp IPMC for IPv4 IGMP <vid> VLAN ID (1-4095) or 'any', default: Show all VLANs auto|v1|v2|v3: auto Auto Compatibility (Default Value)
Seite 257: Fastleave
25.12 Fastleave IPMC>Fastleave ? Description: Set or show the IPMC snooping fast leave port mode. Syntax: IPMC Fastleave [mld|igmp] [<port_list>] [enable|disable] Parameters: mld|igmp IPMC for IPv6 MLD igmp IPMC for IPv4 IGMP <port_list> Port list or 'all', default: All ports enable Enable IPMC fast leave disable...
Seite 258: Throttling
25.13 Throttling IPMC>Throttling ? Description: Set or show the IPMC port throttling status. Syntax: IPMC Throttling [mld|igmp] [<port_list>] [limit_group_number] Parameters: mld|igmp : IPMC for IPv6 MLD igmp IPMC for IPv4 IGMP <port_list> Port list or 'all', default: All ports No limit 1~10 Group learn limit...
Seite 259: Filtering
25.14 Filtering IPMC>Filtering ? Description: Set or show the IPMC port group filtering list. Syntax: IPMC Filtering [mld|igmp] [<port_list>] [add|del] [group_addr] Parameters: mld|igmp : IPMC for IPv6 MLD igmp IPMC for IPv4 IGMP <port_list> Port list or 'all', default: All ports Add new port group filtering entry Del existing port group filtering entry (default: Show IPMC port group filtering list)
Seite 260: Router
25.15 Router IPMC>Router ? Description: Set or show the IPMC snooping router port mode. Syntax: IPMC Router [mld|igmp] [<port_list>] [enable|disable] Parameters: mld|igmp : IPMC for IPv6 MLD igmp IPMC for IPv4 IGMP <port_list> Port list or 'all', default: All ports enable Enable IPMC router port disable...
Seite 261: Groups
IPMC for IPv6 MLD igmp IPMC for IPv4 IGMP <vid> VLAN ID (1-4095) or 'any', default: Show all VLANs 25.17 Groups IPMC>Groups ? Description: Show IPMC group addresses, accordingly. Syntax: IPMC Groups [mld|igmp] [<vid>] Parameters: mld|igmp: IPMC for IPv6 MLD igmp IPMC for IPv4 IGMP <vid>...
Seite 262: Sfm
<vid> VLAN ID (1-4095) or 'any', default: Show all VLANs 25.19 SFM IPMC>SFM ? Description: Show SFM (including SSM) related information for IPMC. Syntax: IPMC SFM [mld|igmp] [<vid>] [<port_list>] Parameters: mld|igmp IPMC for IPv6 MLD igmp IPMC for IPv4 IGMP <vid>...
Seite 263: Parameter Rv
25.20 Parameter RV IPMC>Parameter RV ? Description: Set or show the IPMC Robustness Variable. Syntax: IPMC Parameter RV [mld|igmp] [<vid>] [ipmc_param_rv] Parameters: mld|igmp : IPMC for IPv6 MLD igmp IPMC for IPv4 IGMP <vid> VLAN ID (1-4095) or 'any', default: Show all VLANs ipmc_param_rv: Default Value (2) 1~255...
Seite 264: Parameter Qi
25.21 Parameter QI IPMC>Parameter QI ? Description: Set or show the IPMC Query Interval. Syntax: IPMC Parameter QI [mld|igmp] [<vid>] [ipmc_param_qi] Parameters: mld|igmp : IPMC for IPv6 MLD igmp IPMC for IPv4 IGMP <vid> VLAN ID (1-4095) or 'any', default: Show all VLANs ipmc_param_qi: Default Value (125) 1~31744...
Seite 265: Parameter Qri
25.22 Parameter QRI IPMC>Parameter QRI ? Description: Set or show the IPMC Query Response Interval. Syntax: IPMC Parameter QRI [mld|igmp] [<vid>] [ipmc_param_qri] Parameters: mld|igmp : IPMC for IPv6 MLD igmp IPMC for IPv4 IGMP <vid> VLAN ID (1-4095) or 'any', default: Show all VLANs ipmc_param_qri: Default Value (100) 0~31744...
Seite 266: Parameter Llqi
25.23 Parameter LLQI IPMC>Parameter LLQI ? Description: Set or show the IPMC Last Listener Query Interval. Syntax: IPMC Parameter LLQI [mld|igmp] [<vid>] [ipmc_param_llqi] Parameters: mld|igmp : IPMC for IPv6 MLD igmp IPMC for IPv4 IGMP <vid> VLAN ID (1-4095) or 'any', default: Show all VLANs ipmc_param_llqi: Default Value (10) 0~31744...
Seite 267: Parameter Uri
25.24 Parameter URI IPMC>Parameter URI ? Description: Set or show the IPMC Unsolicited Report Interval. Syntax: IPMC Parameter URI [mld|igmp] [<vid>] [ipmc_param_uri] Parameters: mld|igmp : IPMC for IPv6 MLD igmp IPMC for IPv4 IGMP <vid> VLAN ID (1-4095) or 'any', default: Show all VLANs ipmc_param_uri: Default Value (1) 0~31744...
Seite 268: Sflow
Chapter 26 sFlow 26.sFLOW Available Commands: sFlow Configuration sFlow Receiver [release] [<timeout>] [<ip_addr_host>] [<udp_port>] [<datagram_size>] sFlow FlowSampler [<port_list>] [<sampling_rate>] [<max_hdr_size>] sFlow CounterPoller [<port_list>] [<interval>] sFlow Statistics Receiver [clear] sFlow Statistics Samplers [<port_list>] [clear] 26.1 Configuration sFlow>Configuration ? Description: Show global and per port sFlow configuration.
Seite 269: Receiver
Syntax: sFlow Configuration 26.2 Receiver sFlow>Receiver ? Description: Set or show the sFlow receiver timeout, IP address, and UDP port. Syntax: sFlow Receiver [release] [<timeout>] [<ip_addr_host>] [<udp_port>] [<datagram_size>] Parameters: release Release the current owner of the receiver. The owner can either be "<none>" if the receiver is not currently owned by anyone, it can be "<Configured through local management>"...
Seite 270: Flowsampler
26.3 FlowSampler sFlow>FlowSampler ? Description: Set or show flow sampler configuration per port. When operational,the sampling rate 'N' is rounded off to the nearest supported value. Syntax: sFlow FlowSampler [<port_list>] [<sampling_rate>] [<max_hdr_size>] Parameters: <port_list> Port list or 'all'. Default: All ports. <sampling_rate>...
Seite 271: Counterpoller
26.4 CounterPoller sFlow>CounterPoller ? Description: Set or show counter polling interval configuration per port. Syntax: sFlow CounterPoller [<port_list>] [<interval>] Parameters: <port_list> Port list or 'all'. Default: All ports. <interval> Polling interval in range 0 - 3600. Set to 0 to release this port's resources. 26.5 Statistics Receiver sFlow>Statistics Receiver ? Description:...
Seite 272: Statistics Samplers
26.6 Statistics Samplers sFlow>Statistics Samplers ? Description: Get or clear per-port statistics. Syntax: sFlow Statistics Samplers [<port_list>] [clear] Parameters: <port_list> Port list or 'all'. Default: All ports. clear Clear statistics. Instruction Manual 272 ...
Seite 273: Vcl
Chapter 27 27.VCL Available Commands: VCL Macvlan Configuration VCL Macvlan Add <mac_addr> <vid> [<port_list>] VCL Macvlan Del <mac_addr> VCL Status [combined|static|nas|all] VCL ProtoVlan Protocol Add Eth2 <ether_type>|arp|ip|ipx|at <group_id> VCL ProtoVlan Protocol Add Snap <oui>|rfc_1042|snap_8021h <pid> <group_id> VCL ProtoVlan Protocol Add Llc <dsap> <ssap> <group_id> VCL ProtoVlan Protocol Delete Eth2 <ether_type>|arp|ip|ipx|at VCL ProtoVlan Protocol Delete Snap <oui>|rfc_1042|snap_8021h <pid>...
Seite 274: Macvlan Configuration
27.1 Macvlan Configuration VCL>Macvlan Configuration ? Description: Show VCL MAC-based VLAN configuration. Syntax: VCL Macvlan Configuration 27.2 Macvlan Add VCL>Macvlan Add ? Description: Add or modify VCL MAC-based VLAN entry. The maximum Macvlan entries are limited to 256. Syntax: VCL Macvlan Add <mac_addr>...
Seite 275: Macvlan Del
27.3 Macvlan Del VCL>Macvlan Del ? Description: Delete VCL MAC-based VLAN entry. Syntax: VCL Macvlan Del <mac_addr> Parameters: <mac_addr> MAC address ('xx-xx-xx-xx-xx-xx' or 'xx.xx.xx.xx.xx.xx' or 'xxxxxxxxxxxx', x is a hexadecimal digit) 27.4 Status VCL>Status ? Description: Show VCL MAC-based VLAN users configuration. Syntax: VCL Status [combined|static|nas|all] Parameters:...
Seite 276: Protovlan Protocol Add Eth2
27.5 ProtoVlan Protocol Add Eth2 VCL>ProtoVlan Protocol Add Eth2 ? Description: Add VCL protocol-based VLAN Ethernet-II protocol to group mapping. The maximum protocol to group mappings are limited to 128. Syntax: VCL ProtoVlan Protocol Add Eth2 <ether_type>|arp|ip|ipx|at <group_id> Parameters: <ether_type>|arp|ip|ipx|at Ether Type (0x0600 - 0xFFFF) <group_id>...
Seite 277: Protovlan Protocol Add Llc
27.7 ProtoVlan Protocol Add Llc VCL>ProtoVlan Protocol Add Llc ? Description: Add VCL protocol-based VLAN LLC protocol to group mapping. The maximum protocol to group mappings are limited to 128. Syntax: VCL ProtoVlan Protocol Add Llc <dsap> <ssap> <group_id> Parameters: <dsap>...
Seite 278: Protovlan Protocol Delete Snap
27.9 ProtoVlan Protocol Delete Snap VCL>ProtoVlan Protocol Delete Snap ? Description: Delete VCL protocol-based VLAN SNAP protocol to group mapping. Syntax: VCL ProtoVlan Protocol Delete Snap <oui>|rfc_1042|snap_8021h <pid> Parameters: <oui>|rfc_1042|snap_8021h OUI value (Hexadecimal 00-00-00 to FF-FF-FF). <pid> PID value (0x0-0xFFFF). If OUI is 00-00-00, valid range of PID is from 0x0600-0xFFFF.
Seite 279: Protovlan Vlan Add
27.11 ProtoVlan Vlan Add VCL>ProtoVlan Vlan Add ? Description: Add VCL protocol-based VLAN group to VLAN mapping. The maximum group to VLAN mappings are limited to 64. Syntax: VCL ProtoVlan Vlan Add [<port_list>] <group_id> <vid> Parameters: <port_list> Port list or 'all', default: All ports <group_id>...
Seite 280: Protovlan Conf
27.13 ProtoVlan Conf VCL>ProtoVlan Conf ? Description: Show VCL protocol-based VLAN entries. Syntax: VCL ProtoVlan Conf 27.14 IPVlan Configuration VCL>IPVlan Configuration ? Description: Show VCL IP Subnet-based VLAN configuration. Syntax: VCL IPVlan Configuration [<vce_id>] Parameters: <vce_id> Unique VCE ID (1-128) for each VCL entry ...
Seite 281: Ipvlan Add
27.15 IPVlan Add VCL>IPVlan Add ? Description: Add or modify VCL IP Subnet-based VLAN entry. The maximum IPVlan entries are limited to 128. Syntax: VCL IPVlan Add [<vce_id>] <ip_addr_mask> <vid> [<port_list>] Parameters: <vce_id> Unique VCE ID (1-128) for each VCL entry <ip_addr_mask>...

StarTech.com IES101002SFP Bedienungsanleitung

1 General

2 System

3 Ip

4 Port

5 Mac

6 Vlan

7 Pvlan

8 Security

9 Stp

10 Aggregation

11 Lacp

12 Lldp

13 Lldpmed

14 Eee

15 Thermal

16 Led_Power

17 Qos

18 Mirror

19 Config

20 Firmware

21 Upnp

22 Mvr

23 Voice Vlan

24 Loop Protect

25 Ipmc

26 Sflow

Quicklinks

Verwandte Anleitungen für StarTech.com IES101002SFP

Inhaltszusammenfassung für StarTech.com IES101002SFP
