Prepare the workplace where the machine is to be placed.
Insure sufficient room to allow safe work without malfunc-
tions. The machine is designed to operate in closed rooms
and must be placed stabily on firm level ground. Stability
is insured by attachment to the ground with 4 screws (Fig.
14).
Transport
The machine may only be transported with suitable lifting
devices (crane or fork lift). The connection point for the
rope (crane) is on the upper band wheel cabinet.
BASA3 (1901503901) / BASA3 (1901503902)
Scope of delivery
Passage width
Passage height
Table size
Cutting speed
Saw band length
Height up to tab-
letop
Height up to table-
top with
underframe
Overall height with-
out underframe
Overall height with
underframe
Overall width
Overall depth
Slewing range of the
table
Overall weight with-
out underframe
Overall weight with
underframe
Suction connector
Extraction power
stat. under pressure
(20 m/sec)
Drive
Motor
Nominal consump- 0,8kW (S1)
tion P1 (kW)
1,1 kW (S6 40%)
22 GB
Set-up

Band saw

Sawing table
Longitudinal stop
Dust bag connector
Push stick
Accesory Bag
Hexagonal spanner SW 10/13
Hexagonal socket head wrench
SW 4/SW 5
Operating instructions
306 mm
205 mm
400 x 548 mm
370 – 750 m/min
2360 mm
490 mm
1025 mm
1125 mm
1655 mm
900 mm
540 mm
-8° – +45°
69 kg
79 kg
Ø 100 mm
565 m 3 /h
900 Pa
Alternating Rotary current
current 230-240V 400V 3phase
0,7kW (S1)
1,1kW (S6 40%)
Delivery of power P2 0,56 kW (S1)
(kW)
0,74kW (S6 40%)
Noise parameters
The noise emission values determined accordin
g to EN 23746 for the sound level and according to EN
31202 (coefficient of correction k3 calculated according
to Appendix A.2 of EN 31204) for the sound level at the
workplace are as follows, based on the working conditions
listed in ISO 7904 Appendix A:
Sound level in dB
Idle running LWA = 80.3 dB(A)
Operation LWA = 100.2 dB(A)
Sound level at the workplace in dB
Idle running LpAeq = 64.1 dB(A)
Operation LpAeq = 82.9 dB(A)
A measurement uncertainty allowance K = 4 dB applies to
the mentioned emission values.

Machine description

Due to its perfected design, the machine offers a versatile
application for processing wood and plastics in the work-
shop.
The upper and lower bandwheel is protected by a fixed
guard and an articulated cover. Upon opening the cover,
the machine is switched off. Switching on again is only
possible with the cover closed. The non-cutting part of the
sawbelt above the table top is covered by a guard fixed
to the sawbelt guide, the latter being protected against
inadvertant opening by the fixed guard of the upper band
wheel. The non-cutting part of the sawbelt under the table
top is protected by a fixed cover.
The swivelling range of the table from -20° to +47° allows
versatile cutting possibilities (e.g.)
• Longitudinal cuts
• Cross cuts
• Diagonal cuts
• Curved and irregular cuts
• Cuts for dovetails and tenons
• On-edge cuts of squared beams
Please consult also the working hints in the operating in-
structions.
Completion

Assembly tools

1 engineer's wrench SW 10/13
For reasons of packaging technology, the tabletop, the
handle, and the handwheel are not mounted.
Installation of the Underframe, Fig. 1.1
1. Put a wooden block behind the machine, and than
carefully turn over the machine so that the base plate
lies on the floor.
2. Loosely screw the frame feet with 12 screws (M6 x 12)
to the base plate.
0,48 kW (S1)
0,77kW (S6 40%)
