8 Dimensions

8 Dimensions

8.1 Actuator dimensions

MG
20 15, 20, 25
25
40 40, 50
Dimensions in mm
* CT = A + H1 (see body dimensions)
GEMÜ R647
B1
G
DN A
50.0
32 54.0
67.0
A1 B1
19.0 64.0
20.0 75.0
24.0 100.0
42 / 64
B2
B2
69.5
85.0
108.0
www.gemu-group.com
G
G 1/4
G 1/4
G 1/4
