8 Dimensions
Connection type flange EN (code 4)
MG DN
20 15
20
25
25 32
40 40
50
Dimensions in mm
MG = diaphragm size
n = number of bolts
1) Connection type
Code 4: Flange EN 1092, PN 10, form B, Overall length FTF EN 558 series 1, ISO 5752, basic series 1
2) Valve body material
Code 1: PVC-U, grey
GEMÜ R647
FTF
1) , body materials PVC-U (code 1)
NPS ød øD
1/2" 34.0 95.0
3/4" 41.0 105.0
1" 50.0 115.0
1¼" 61.0 140.0
1½" 73.0 150.0
2" 90.0 165.0
2)
FTF H
130.0 36.0 10.0
150.0 38.0 12.0
160.0 39.0 13.0
180.0 41.0 15.0
200.0 63.2 23.2
230.0 63.2 23.2
50 / 64
H1 øk øL
65.0 14.0
75.0 14.0
85.0 14.0
100.0 18.0
110.0 18.0
125.0 18.0
www.gemu-group.com
n
4
4
4
4
4
4
